- Page 1 T-Series charging station Installation & Operating manual - EN T-Series Electric vehicle charging station Installation & Operating manual | EN | 2020-08-14 ©...
-
Page 2: Table Of Contents
T-Series charging station Installation & Operating manual - EN CONTENTS Kempower T-Series ........................ 3 Equipment parts ........................4 Safety ............................6 Installation ..........................7 4.1. Fixed installation (optional) ..................9 Operation ..........................12 Maintenance......................... 14 6.1. Troubleshooting and error codes ................15 Technical data ........................ -
Page 3: Kempower T-Series
Read the instructions through carefully. Pay particular attention to the safety instructions. Items in the manual that require particular attention in order to minimize damage and harm are indicated with the below symbols. Read these sections carefully and follow their instructions. T-series package – see appendix 1 Note: Gives the user a useful piece of information. -
Page 4: Equipment Parts
T-Series charging station Installation & Operating manual - EN 2. EQUIPMENT PARTS Charging connectors RFID reader (RFID = Radio Frequency Identification) Function button 7" touch screen ON/OFF start switch Charge level indicator Rear support Front support Rating plate. * Connector types: ** Charge level indicator logic: •... - Page 5 T-Series charging station Installation & Operating manual - EN This equipment complies with IEC 61851-21-2. According to the electromagnetic compatibility classification (EMC Class A), the equipment is not intended for use in residential locations where the electrical power is provided by a public low-voltage supply system. In those locations it may be difficult to ensure the electromagnetic compatibility due to conducted and radiated disturbances.
-
Page 6: Safety
Never pull or move the machine by the cables. Always use the handles designed for that purpose. • Use special caution when moving and handling the equipment. The T-Series charging trolley equipment weighs approximately 135 kg, depending on the current setup. -
Page 7: Installation
T-Series charging station Installation & Operating manual - EN 4. INSTALLATION This section describes how to take the T-Series charging trolley into use. Use caution when moving the equipment. This equipment weighs approximately 135 kg, depending on the current setup. - Page 8 T-Series charging station Installation & Operating manual - EN Wireless mobile data network and internet connectivity rely on your local service provider's network and its settings. For network specifications, refer to "Technical data" on page 16. By the time unit is ready to use, please select from the trolley touch screen power supply source 32 A or 63 A, accordingly to the site.
-
Page 9: Fixed Installation (Optional)
Installation & Operating manual - EN 4.1. Fixed installation (optional) The T-Series charging trolley can be fixed in place by securing it with bolts to a mounting pad or other suitable fixing surface. Fixed installation requires the removal of the wheels. Site-specific variations in the fixing method may occur. - Page 10 T-Series charging station Installation & Operating manual - EN Release the front support securing screws behind the hatch edge on both sides. Flip the front support down. Fix the front support securing screws behind the hatch edge on both sides.
- Page 11 T-Series charging station Installation & Operating manual - EN On the first side, insert and secure a dedicated bolt and nut (delivered with the device) into the axle rod hole. Remove the axle rod fully. On the second side, insert and secure a dedicated bolt and nut (delivered with the device) into the axle rod hole.
-
Page 12: Operation
T-Series charging station Installation & Operating manual - EN 5. OPERATION This section describes how to start using the T-Series charging trolley once the installation and initial setup are completed. For using the charging device, follow the device's on-screen instructions. Start-up "Installation"... - Page 13 In case of charging device malfunction or other unrecognized error, please disconnect the charging device from the mains and contact your Kempower service workshop or Kempower sales representative. For service contact information, refer to the Kempower website (www.kempower.com).
-
Page 14: Maintenance
Before opening or removing hatches or cover plates, disconnect the charging device from the mains and wait for about 2 minutes before continuing. Kempower service workshops complete the charging system maintenance according to the Kempower service agreement. The main aspects in the service workshop maintenance procedure are: •... -
Page 15: Troubleshooting And Error Codes
6.1. Troubleshooting and error codes In case of charging device malfunction or other unrecognized error, please disconnect the charging device from the mains and contact your Kempower service workshop or Kempower sales representative. For service contact information, refer to the Kempower website (www.kempower.com). -
Page 16: Technical Data
T-Series charging station Installation & Operating manual - EN 7. TECHNICAL DATA Kempower T-Series Feature Description Value 3~, 380...480 V (+/-10%) Input AC power connection 63 A Nominal input current 50...60 Hz Input frequency 0.94 Power factor (@ full load) - Page 17 T-Series charging station Installation & Operating manual - EN RFID = Radio Frequency Identification. Single Line Drawing of Trolley DC charging station T-series overall measures Appendix 1 Installation & Operating manual | EN | 2020-08-14 ©...
- Page 18 T-Series charging station Installation & Operating manual - EN Package information T-series charging station is delivered on a palette. Installation & Operating manual | EN | 2020-08-14 ©...
- Page 19 Electromechanical design is waterproof, IP classification according to IP54 Mechanical design is according to IK08 and it withstands heavy use User interface provides selection of current according to available power supply source on T-series Electrical safety internal over leak DC current monitoring according to IEC 61851-1, -23...
