- Page 1 Value Regulated Sealed Lead-acid Battery Power Storage Solutions Battery Installation & Operation Guide 12MQ100 - 620 (Reserve Power Batteries) AGM VRLA...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction …………………………………………………………………………….3 2. Safety Precaution and Protection Equipment...…………………………………..3 3. Battery Storage ……………………………..………………………………………..4 4. Battery System Installation Considerations…………………………………..…..4 5. Installation of Batteries ………………………………………………………...….. 6. Operation …………………………………………………...….…...…...10 of Battery 7. Battery Maintenance ………………………………………………….…..……...…12 8. Exchange of Batteries …………...…..……………………………….…..………17 9. Maintenance Records and Forms ……………………………………..…………..18... -
Page 3: Introduction
1. Introduction Power Storage Solutions private label batteries technology is based on years of research and development. Our products are manufactured under the guidelines of ISO9001 quality system. Each battery undergoes a series of strict manufacturing and quality control processes before shipment. -
Page 4: Battery Storage
Limited current ≤0.30C 10, voltage 2.23~2.30V/cell Float Charge (25°C) Cyclic Charge (25°C) Limited current ≤0.30C 10 , voltage 2.30~2.40V/cell Do not mix new and old batteries, batteries of different capacity or manufacturers. Mixing Batteries If required, please consult with Power Storage Solutions technical support. pg.4... -
Page 5: Installation Of Batteries
5. Installation of batteries 5.1 Unpack and Check Check the packaging for signs of shipping damage. Unpack and check the appearance of battery for signs of damage or unidentified fluid. Check parts list ensuring all accessories are included. Read through the operation guide before handling the battery. Handle the battery with caution: Avoid any impact or force on the battery terminals! Avoid any impact to the battery! - Page 6 5.3 Pre Installation Rack/Enclosure Location Check Floor loading: Since batteries are heavy, check the floor loading is not exceeded. Check rack / enclosure complies with any load spreading, and seismic zone requirements of the installed area. To assemble a battery rack/enclosure, please see rack installation instructions. 5.4 Battery Installation and connection Use insulated tools only;...
- Page 7 To assemble a battery rack, see rack and/or cabinet enclosure installation instructions. 5.6 Batteries mounting on racks Rack mounted Power Storage Solutions batteries follow the procedures below: If batteries are small they can easily be lifted into place. If batteries are large special caution should be used.
- Page 8 Remove all poly-foams out from the bottom of the battery. Step 2. Lift with two people if weight requires. Place on battery rack or in battery cabinet. 5.7 Example Images after Installation 5.7.1 12V Battery Vertical 2-Tier/ 1-Row/Non-seismic Rack (8 batteries shown) pg.8...
- Page 9 5.7.2 12V Batteries: Vertical 3-tier/ 2-row Rack (30 batteries shown) pg.9...
-
Page 10: Operation Of Battery
6 Operation of Battery 6.1 Refresh Charge During the delivery and storage, the battery will lose part of the capacity due to self discharge, so please apply a supplemental charge before use; If storage occurs before installation / connection, supplement charge regularly; Supplementary charge according table 2 below before use: Table 2 the time interval of supplementary charge and storage temperature Time interval of... - Page 11 6.4 Charge 6.4.1 Float Charge Parameters: Charge voltage: 2.23 ~2.30V/cell at 77°F (25°C) The maximum charge current: 0.30C10 Temperature compensation coefficient: -3mV/cell (taking 77°F (25°C) as base point) Total variation range of charge voltage is ±0.02V/cell Note: 1) All cell/jar voltages of a battery string have a little difference at the beginning of use, after approximately six months voltage ranges should tighten up.
-
Page 12: Battery Maintenance
6.4.4 Notes during charging 1. Charge current at the end of charge is over 0.05 C10A, which may result in permanent damage on battery appearance and battery life; pay close attention to charging voltages. 2. The used charger should have digressive automatic constant voltage device, please contact us if use other kind of charger. - Page 13 7.2.1 Monthly Inspection items: Items Contents Standards Maintenance Total float Measure output end 1. Test data complies with the 1. If data attained by testing is varies charging voltage of positive data displayed on the from the standard, the tested data voltage of and negative end of meter and meets the...
- Page 14 7.2.1 Monthly Inspection items continued : Connection Check the tightness Torque values - please Tighten the loosen bolt/screw in time refer to the table of torque Parts of terminal bolt/screw with torque spanne Check the Without appearance of corrosion Take out the connection cable and clear it connection cable or dirt in water if it is light corrosion, for serious...
- Page 15 7.2.2 Quarterly Inspection items continued: Additional to Monthly Maintenance items: Correct string 1. Equalization charge of the The difference of float Single cell should be replaced if it battery string: charge the battery at charge voltage between fails in repair with upper limit voltage for 10 hrs, 3 single cell in a string of...
- Page 16 7.2.4 Basic requirements and precautions on maintenance routines: Principle to discover areas of concern and insure the safe operation. Should be documented while testing the batteries. Preventative maintenance and performance analysis should be carried out routinely. Battery parameter and operation should be complied with the maintenance documentation and reviewed.
-
Page 17: Exchange Of Batteries
If you have any questions or concerns, please call Power Storage Solutions for assistance (888-813-5049). Taking measurements is recommended after the battery is installed, and after the battery has been in float service for 6 months (Base Line Readings for warranty records). - Page 19 Note: Baseline reading is completed after 6 months on float in operation. Keep the baseline readings for your permanant record.
- Page 22 Notes: For assistance - Power Storage Solutions 888-813-5049 or www.pwrstoragesolutions.com pg.22...
