- Page 1 Installation - Manual V - Acoustic Housing...
- Page 2 Solflex GmbH Am Feuerstein 282 2392 Wienerwald Austria T: +43223820336 E: office@solflex.eu www.solflex.eu ATU 65324348 FN 337206t Always observe all relevant standards and statutory regulations Subject to change without prior notice. All business transactions based on our Terms and Conditions, available at www.solflex.eu...
-
Page 3: Table Of Contents
Inhalt General information .............. 4 Technical data ..............4 Warranty................7 Safety ................. 7 Intended use ............... 7 Safety instructions ............... 7 4.2.1 Risks during unloading and transportation ....... 7 4.2.2 Risks of damage to property and environment ......7 Emergency procedure ............ -
Page 4: General Information
1. General information Solflex produces acoustic housing for a wide range of Heat Pump, Air Conditioning and Refrigeration systems. This manual applies to the following series: Solflex V* Serie https://solflex.eu/en/vschalldaemmgehaeuse19db 2. Technical data Stable self-supporting, insulated box housing with fully demountable structure without welding and riveting. - Page 5 Manual V Acoustic housing...
- Page 6 Manual V Acoustic housing...
-
Page 7: Warranty
Warranty 4.2.2 Risk of damage to property and the 24 months from delivery. environment Safety Bei unsachgemäßer oder nicht bestimmungsgemäßer Verwendung Serious damage to property können Gefahren für Leib und Leben des from dropping loads; Benutzers oder Dritter bzw. Please observe the instructions in Beeinträchtigungen des Gerätes und section “Delivery of product”. -
Page 8: Unloading / Transport To Location Of Installation
Unloading / transport to Unloading with a forklift or location of installation pallet truck Dieses Schalldämmgehäuse wird zerlegt It is important to ensure that the auf einer Palette geliefert. Beim Abladen products base frame rests completely on darf die Anhebe kraft nur auf einer the forks of the lifting device and the Palette erfolgen. -
Page 9: Unloading With A Crane
Unloading with a crane Only suitable and approved lifting accessories (ropes, lifting straps, …) may be used. Use spacers to protect the acoustic housing from damage. The specially provided crane lugs are to be used to transport the acoustic housing. These may not be mounted on the upper corner connections. -
Page 10: Manual Positioning
There are 3 different variations of lifting accessories: Variation 1 Crane strap on the corner bracket Variante 2: Crane strap on the base frame Variante 3: Form tube through base frame Larger acoustic housings are Never move the acoustic housing with blows from heavy equipment equipped with 8 lugs, please note (e.g. -
Page 11: Installation Of Unit
Installation of unit At the place of installation, it must be possible to provide impeccable service and maintenance and the necessary air intake of the built-in air-conditioning, refrigeration and heat pump units. When planning the installation site, the guide lines for minimum distances around the air-conditioning, refrigeration and heat pump manufacturer must be respected. -
Page 12: Foundation
Foundation The foundation must meet the relevant static and sound propagation requirements and must feature a proper drain for water. It must be level and smooth. The resonance frequency of the support structure must be distinctly different from the excitation frequency of the rotating machine components (Heat Pump, Air Conditioning and Refrigeration system). -
Page 13: Adjusting The Feet
The base frame and the crane lugs are statically designed and dimensioned so that the air conditioning, cooling and heat pump devices can be pre-assembled in the soundproof housing and lifted together with the crane. No liability will be accepted for any errors or consequences resulting from the fixing and checking of the fixing of the cross member and the pre-assembly of the air conditioning, refrigeration or heat pump units. -
Page 14: Installation Of Refrigeration, Air Conditioning And Heat Pumps
Depending on the type of the V series acoustic housing, there are 3 options for installing the refrigeration, air conditioning or heat pump device: 1.V series acoustic housing without bottom is put over the air conditioning or heat pump device as a hood using a crane. - Page 15 3. The refrigeration, air conditioning or heat pump devices are inserted into the soundproof housing. Then the refrigeration, air conditioning or heat pump device to be installed is placed on a pedestal that is the same height as the cross member (e.g. made of 2-3 wooden pallets) and pushed horizontally into the soundproof housing: Align refrigeration, air conditioning or heat pumps in the middle of the air...
- Page 16 It is important that the alignment of the refrigeration, air conditioning or heat pump device is in the middle of the air separation part. In order to facilitate the drilling of the housing bushings for pipes and electrical cables as well as the connection work on the refrigeration, air conditioning or heat pump device, we recommend dismantling the necessary lamella packs using the quick-release fasteners with the special key supplied.
- Page 17 Manual V Acoustic housing...
-
Page 18: Maintenance And Service
Maintenance and Service The surface and inside of the backdrop must not be damaged in order to prevent water from being General sucked into the foam through damage / openings on the film For maintenance and service work on surface. the refrigeration, air-conditioning or heat pump unit, the necessary panels If necessary, the silencers must be... -
Page 19: Grounding
7.12 Maintenance table for the soundproof housing Activity Maintenance Manu Component facturer Lamellas/Scenes Air seperation Drain Pan/ Solflex Condensate Housing Doors Manual V Acoustic housing... - Page 20 A-2392 Wienerwald, Austria +43 2238 203 36, office@solflex.eu V-IM-06/2021-ENG Erste Bank AG, IBAN AT702011129323600200, BIC IBAATWWXXX, UID ATU65324348, FN 337206t, Gerichtsstand Wiener Neustadt, Austria All business transactions based on our Terms and Conditions, available at www.solflex.eu. Subject to change without prior notice.
