User's Manual
Color LCD Monitor
Important
Please read this "User's Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective usage.
• Refer to the "Setup Guide" for information on the installation /
connection of the monitor.
• For the latest product information including the "User's Manual",
refer to our web site :
http://www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo FlexScan EV3285FX-BK
Summary of Contents for Eizo FlexScan EV3285FX-BK
- Page 1 User’s Manual Color LCD Monitor Important Please read this “User’s Manual”, and “PRECAUTIONS” (separate volume) carefully to familiarize yourself with safe and effective usage. • Refer to the “Setup Guide” for information on the installation / connection of the monitor. •...
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Notice For This Monitor
When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. -
Page 4: Cleaning
Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD panel. Do not attempt to brush with tissues as this may scratch the panel. When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur on the interior and exterior surfaces of the monitor. -
Page 5: Table Of Contents
CONTENTS Notice for this monitor ......... 3 Chapter 5 Troubleshooting ......34 Cleaning ..............4 5-1. No Picture ............ 34 To use the monitor comfortably ......4 5-2. Imaging Problems ........35 CONTENTS ............. 5 5-3. Other Problems ........... 36 Chapter 6 Reference ........ -
Page 6: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features ● Support for DisplayPort over USB Type-C (DP Alt Mode) / USB Power Delivery This product is equipped with a USB Type-C (USB-C) connector compatible with DP Alt Mode and USB Power Delivery. -
Page 7: High Degree Of Flexibility For Installation
● High Degree of Flexibility for Installation • This product can be used as an external monitor of a notebook computer. • This product can be used in a multi-monitor configuration in which multiple monitors are connected to a single PC. ●... -
Page 8: Controls And Functions
1-2. Controls and Functions ● Front 1. Ambient light sensor Detects ambient brightness. If you use Auto EcoView, the screen brightness is automatically adjusted according to the ambient brightness (page 20). 2. Operation switches Displays menus. Operate the switches according to the operation guide (page 22). -
Page 9: Rear
● Rear 6. Handle This handle is used for transportation. 7. Security lock slot Complies with Kensington’s MicroSaver security system. 8. Main power switch Turns the main power on or off. : On, : Off 9. Power connector Connects the power cord. 10. -
Page 10: Supported Resolutions
1-3. Supported Resolutions The monitor supports the following resolutions. ● For DisplayPort Single screen and PinP PbyP display display Vertical scan Resolution Dual screen Quad screen frequency (Hz) Version 1.2 Version 1.1 display display 720 × 400 70.087 √ √ √... -
Page 11: For Hdmi
● For HDMI Single screen and PinP PbyP display display Vertical scan Resolution Dual screen Quad screen frequency (Hz) 4K UHD 60Hz 4K UHD 30Hz display display 720 × 400 70.087 √ √ √ √ 640 × 480 59.940 √ √... -
Page 12: For Usb-C
● For USB-C Single screen and PinP PbyP display display Vertical scan Resolution 4K UHD 60Hz 4K UHD 30Hz Dual screen Quad screen frequency (Hz) / USB2.0 / USB3.1 display display 720 × 400 70.087 √ √ √ √ 640 × 480 59.940 √... -
Page 13: Changing The Computer Display Settings
1-4. Changing the Computer Display Settings If the image is not displayed properly after connecting the monitor to a PC, follow the procedure below to change the display settings on the computer. ● Windows 10 1. Right-click the mouse anywhere on the desktop except on icons. A menu is displayed. 2. -
Page 14: Chapter 2 Basic Adjustment / Setting
Chapter 2 Basic Adjustment / Setting This product enables users to change the brightness according to personal preference or to suit the usage environment and reduce power consumption to conserve energy. This chapter describes the basic functions that can be adjusted and set using the switches on the front of the monitor. -
Page 15: Switching Input Signals
2-2. Switching Input Signals When a monitor has multiple signal inputs, the signal to display on-screen can be changed. Note • "Screen InStyle" allows you to switch input signals using the shortcut keys on the keyboard. ● PbyP display By selecting PbyP (Picture by Picture) display when a monitor has multiple input signals, windows can be displayed side-by-side (dual screen) or side-by-side and above-and-below (quad screen). - Page 16 Setting Function Description Value PbyP Input Left USB-C Select an input signal to be displayed on the left screen of Settings DisplayPort the PbyP display (dual screen). HDMI 1 HDMI 2 Right USB-C Select an input signal to be displayed on the right screen DisplayPort of the PbyP display (dual screen).
-
Page 17: Pinp Display
● PinP display By selecting PinP (Picture in Picture) display when a monitor has multiple input signals, a large window and a small window can be displayed. Because multiple windows can be displayed on a single monitor, the need for changing between signals is eliminated, which leads to increased work efficiency. -
Page 18: Switching Display Modes (Color Modes)
2-3. Switching Display Modes (Color Modes) This product is preinstalled with color modes for various display purposes. By switching the mode according to the purpose and contents of the display, you can display images in an appropriate manner. ● Display Modes Color Mode Purpose User1... -
Page 19: Conserving Energy
2-4. Conserving Energy This monitor is equipped with EcoView functions to enable users to conserve energy. You can use this function to curtail unnecessary power consumption and save on electricity expenses. Saving power also reduces carbon dioxide emissions. Note • The power saving level (Power Reduction, CO Reduction, and Eco Performance Level) can be checked on the “EcoView Settings”... - Page 20 Setting Function Description Value Auto EcoView The ambient light sensor on the front of the monitor detects the ambient brightness to automatically adjust the screen brightness to a comfortable level using Auto EcoView. The power consumption of the backlight can be curtailed by adjusting the brightness to an appropriate level.
-
Page 21: Adjusting Brightness
2-5. Adjusting Brightness The brightness of the screen can be adjusted to suit the installation environment or personal preference. The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Setting Value 0 to 100 2-6. -
Page 22: Chapter 3 Advanced Adjustment / Setting
Chapter 3 Advanced Adjustment / Setting This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see “Chapter 2 Basic Adjustment / Setting” (page 14). 3-1. Basic Operation of the Setting Menu Menu display 1. -
Page 23: Setting Menu Functions
3-2. Setting Menu Functions ● Color Adjustment The color mode setting status can be adjusted according to personal preference. Functions that can be adjusted differ depending on the color mode. √: Adjustable -: Not adjustable Color Mode Function User1 sRGB Paper Movie DICOM... - Page 24 Setting Function Description Value Color Mode User1 Select the desired mode according to the monitor application. User2 The color setting status can also be adjusted according to personal sRGB preference. Select the mode for adjustment and perform adjustment Paper using the relevant functions. Movie Note DICOM...
- Page 25 Setting Function Description Value Advanced Overdrive Enhanced This function allows you to set the overdrive intensity based on the Settings Standard use of the monitor. Image lag can be reduced by using the “Enhanced” setting when displaying moving images. -50 to 50 Adjust the hue.
-
Page 26: Signal Settings
● Signal Settings Set the details regarding input signal, such as the screen display size and color format. Function Setting Value Description Window Selection Left Select the target for the signal settings. Right When using PbyP/PinP display, select this target first. Upper Left •... - Page 27 Function Setting Value Description Picture Expansion Auto The screen size of the monitor display can be changed. Full Screen • “Auto” Aspect Ratio The monitor automatically changes the screen size Dot by Dot according to the aspect ratio and resolution information from the PC.
-
Page 28: Preference Settings
● Preference Settings The monitor’s settings can be configured to suit the usage environment or personal preference. Setting Function Description Value USB CHARGE Normal USB downstream port of the monitor supports boost charging via Port Charging Only USB 3.0. By changing this setting to “Charging Only”, the device connected to the port can be charged in a shorter period of time than that which would be required when it is set to “Normal”. -
Page 29: Language
Setting Function Description Value Sound Left Select the source of audio to output from the monitor during PbyP/PinP Selection Right display. Upper Left • “Left” Lower Left Outputs the audio source from the left screen during PbyP display (dual Upper Right screen). -
Page 30: Information
● Information Monitor information (product name, serial number, usage time, resolution, and input signal) can be checked. Example: • Single screen display • Dual PbyP/PinP display • Quad PbyP display Chapter 3 Advanced Adjustment / Setting... -
Page 31: Chapter 4 Administrator Settings
Chapter 4 Administrator Settings This chapter describes how to configure monitor operation using the “Administrator Settings” menu. This menu is for administrators. Configuration on this menu is not required for normal monitor use. 4-1. Basic Operation of the “Administrator Settings” Menu Menu display 1. -
Page 32: Functions Of The "Administrator Settings" Menu
4-2. Functions of the “Administrator Settings” Menu Function Setting Value Description Auto Input Detection On This function automatically recognizes the connector through which PC signals are input, and displays images on the screen accordingly. • “On” When the monitor is connected to multiple PCs, if a specific PC enters power saving mode or no signals are input to the monitor, the connector is automatically changed to another one to which signals are input. - Page 33 • If the HDMI signal that is being input is not displayed, change this setting. On-Screen Logo When the monitor is turned on, the EIZO logo appears on the screen. When this function is set to “Off”, the EIZO logo does not appear.
-
Page 34: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting 5-1. No Picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light up. • Turn on the main power switch on the rear side of the monitor. •... -
Page 35: Imaging Problems
23)). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) • If the screen is too bright, try changing the Auto EcoView setting to “On”. The monitor detects the ambient brightness to adjust the screen brightness automatically (see “Auto EcoView”... -
Page 36: Other Problems
• Reboot the PC. • If the peripheral devices work correctly when they are directly connected to the PC, contact your local EIZO representative. • Depending on the USB 3.1 host controller that you are using, connected USB devices may not be recognized correctly. Update to the latest USB 3.1 driver provided by each manufacturer, or connect... -
Page 37: Chapter 6 Reference
Chapter 6 Reference 6-1. Attaching the Optional Arm An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the supported optional arm (or optional stand). http://www.eizoglobal.com Attention • When attaching an arm or stand, follow the instructions of the respective User’s Manual. •... -
Page 38: Attaching The Optional Arm (Or Optional Stand)
● Attaching the optional arm (or optional stand) 1. Lay the LCD monitor on a soft cloth spread over a stable and flat surface with the panel surface facing down. 2. Remove the stand. As shown in the figure, while holding down the lock button (1), slide the stand toward the stand base until it touches the stand base (2). -
Page 39: Detaching/Attaching The Cable Holder
6-2. Detaching/Attaching the Cable Holder ● Detaching the cable holder 1. Slide the cable holder to the left, and detach it from the stand. ● Attaching the cable holder 1. Align the tabs of the cable holder with the attachment parts of the stand. 2. -
Page 40: Detaching / Attaching The Cable Cover
6-3. Detaching / Attaching the Cable Cover ● Attaching the cable cover 1. Align the tabs of (A) with the attachment parts of the stand. 2. Slide (A) downward to secure the tabs to the attachment parts of the stand. 3. -
Page 41: Detaching The Cable Cover
4. Pass the cables between (A) and (B), and align (B) with (A) to fit in. 5. Slide (B) downward and secure it to (A). ● Detaching the cable cover 1. Slide (B) upward, and detach it from (A). 2. While holding down of (A) lightly, slide (A) upward to detach it from the stand. -
Page 42: Connecting Multiple Pcs
6-4. Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. ● Connection examples HDMI HH200PR (HDMI - HDMI) HDMI (supplied) DisplayPort DisplayPort PP200 (DisplayPort - DisplayPort) (supplied) USB-C CC200SS (USB-C - USB-C) USB-C (supplied) -
Page 43: Using The Usb Hub Function
6-5. Using the USB Hub Function This monitor is equipped with a USB hub. It functions as a USB hub when connected to a USB- compatible PC, allowing the connection of peripheral USB devices. ● Connection procedure 1. Connect the USB cable between the USB-C connectors of the PC and the monitor. 2. -
Page 44: Specifications
6-6. Specifications LCD Panel Type IPS (Anti-Glare) Backlight Size 80.0 cm (31.5 inch) Resolution 3840 dots x 2160 lines Display Size (H × V) 697.3 mm × 392.2 mm Pixel Pitch 0.182 mm Display Colors 8-bit colors: 16.77 million colors Viewing Angle 178˚... -
Page 45: Accessories
Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 1.65 A - 0.75 A Maximum Power 163 W or less Consumption Power Save Mode 0.5 W or less (no USB device connected, default settings) Standby Mode 0.5 W or less (no USB device connected, default settings) Physical Dimensions 717.4 mm ×... -
Page 46: Appendix
Apple, macOS, Mac OS, OS X, Macintosh and ColorSync are registered trademarks of Apple Inc. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. -
Page 47: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... - Page 48 03V27413A1 UM-EV3285 Copyright © 2018 EIZO Corporation. All rights reserved. 1st Edition-July, 2018...
