Triton Products LocBoard LB1-B Installation & Assembly Instructions

LB1-B, T, W - (2) 24" x 24" x 9/16" LocBoard® Pegboards
Read all instructions completely before installing. Should you have any questions about your
installation, please call Customer Service at 440-248-5480
•
These rugged steel tool boards can be easily and quickly positioned to conform to your storage
requirements.
•
Boards can be positioned side by side or above one another in vertical and horizontal mounting
positions.
•
Additional boards and hooks can be added to your system as your needs continue to grow.
•
LocBoards fasten directly to concrete, solid wood and hollow wall structures without the use of
furring strips. (Mounting hardware not included.)
LocBoard™ Installation:
Hardware needed for installation: (NOTE DO NOT USE Tapered Head Screws.)
1. For hollow or concrete block wall: Quantity=12 Each #8- 2" long Phillips pan head machine screws
and #8 plastic commercial grade wall anchors. Head diameter size of screws should not exceed .35"
in order to fit through square holes in front of boards.
2. For wood stud or wood headers: Use #8-2" long wood screws with Phillips pan heads.
Level, Marker, 7/32" standard or masonry drill bit, 7/64" std bit for wood studs, #2 Phillips head
screwdriver, power drill.
1. Select wall location for your LocBoards and the desired vertical or horizontal mounting pattern
you wish to mount in. When selecting a location for mounting always make sure that mounting
locations do not fall in line with, are adjacent to, or interfere with any internal or external
electrical wiring, wall mounted or built-in electrical appliances, heaters, gas lines, ductwork or
plumbing inside of wall, or are located on the opposite side of any wall surface from where you
are mounting. If you are unsure, please consult a professional before proceeding with
installation.
2. (Using Images on Back) There are four screw holes on the back of your LocBoard that are
accessible through the square holes on the front.
3. Place 1 LocBoard flat against wall surface. While using a level to make sure your board is straight
and squared, looking through the square holes on the front of the board, mark the centers of all
6 screw holes onto your wall surface. Note: Installation for first board should be completed
before marking mounting holes for the second board.
4. Pre-drill holes for #8 wall anchors marked in Step 3 using 7/32" standard or masonry drill bit
depending on wall surface. If you hit a wood stud stop drilling and using a 7/64" drill bit create a
pilot hole for the wood screw Note: Avoid over drilling holes. (Plastic wall anchors should fit
snug.)
5. Insert plastic wall anchors in each hole drilled in Step 4 except where you drilled 7/64" pilot hole
for wood stud.
6. Align mounting holes in wall surface with screw holes in pegboard. Insert wood screws through
the front square opening and into pre-installed plastic wall anchors. Tighten all screws. The
head of each screw should not be visible.
7. Repeat Steps 2-6 for second LocBoard installation.
