CH18 Hand Control Instructions
1. Product Overview
Product Name： Hand Control
Product Model No.： CH18
FCC ID: 2AEQWCH18HHC003
2. Environment requirement
Operation temperature: +10℃~ +40℃.
Storage temperature: －10℃~65℃.
Operating Humidity：10%~80%RH，non‐condensing.
Storage Humidity：10%~ 85%RH，non‐condensing.
3. Directions for Operation
In order to operate, place three 1.5V AAA batteries in the remote control and use in conjunction
with the CB18 control box. In addition, the PSK2920A power supply switch must be connected as
the power supply for the control box. Detailed operation directions below:
Match Code：
Press and hold the button, approx. 15 seconds, until the remote's front indicator lights
up. Then, connect it to the control box Power plug. After the beep sound, the pairing is complete
and remote can operate.
Indicator
light
1/4
Advertisement
Table of Contents
Related Manuals for HHC CH18
Summary of Contents for HHC CH18
- Page 1 CH18 Hand Control Instructions 1. Product Overview Product Name： Hand Control Product Model No.： CH18 FCC ID: 2AEQWCH18HHC003 2. Environment requirement Operation temperature: +10℃~ +40℃. Storage temperature: －10℃~65℃. Operating Humidity：10%~80%RH，non‐condensing. Storage Humidity：10%~ 85%RH，non‐condensing. 3. Directions for Operation ...
- Page 2 4. The port is introduced All motorized functions of the bed are controlled by the remote control. 4.1.BackrestLift. Press this button to lift up the backrest. Keep the button pressed and release when the desired tilt is achieved. Press this button to lower the backrest. Keep the button pressed and release when the desired tilt is achieved. 4.2.FootrestLift. Press this button to lift up the footrest. Keep the button pressed and release when the desired tilt is achieved. ...
- Page 3 Press this button to reduce the intensity of the back massage. Press this button to stop the back massage. Press this button to increase the intensity of the foot massage. Press this button to reduce the intensity of the foot massage. Press this button to stop the foot massage. 4.5.Backlit illumination of remote control To illuminate the buttons for better night view when press this button . The light will turn off automatically after approximately 10 seconds. Note: The light also turns on when pressing any of the other buttons. 5. Matters needing attention： 5.1 Do not mix old and new batteries or different types of batteries in remote. 5.2 When the battery power is weak, electrolyte leakage may occur, and will damage the remote. Once the power is low, replace the battery as soon as possible. ...
- Page 4 conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 6.3 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain compliance with FCC RF exposure compliance requirements, please using a minimum separation distance of 5 mm from the device. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. 6.4 For Intentional and unintentional radiators the manual shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment ...
