IBM NetVista A20 Reference Manual page 9

IBM
® NetVista A20 (6270) - Winter 2001 - withdrawn
TM
Name Type-model Color
A20 6270-HHU Black
A20 6270-HSU Black
A20 6270-PHU Black
A20 6270-Q9U Black
Processor Intel
Intel Celeron 800MHz with 100MHz Front Side Bus or
Intel Pentium III 933MHz or 1GHz with 133MHz Front Side Bus
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
DVMT; uses main memory with no display cache
Disk ATA-66, SMART
Disk controller Enhanced IDE / ATA-66 / integrated into I/O Controller Hub (ICH)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM 48X-20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E
82801 I/O Controller Hub (ICH) for PCI 2.2 bus at
32-bit 33MHz, ATA-66 EIDE, USB, Low Pin Count Interface /
82802 Firmware Hub / Winbond 83627HF Super I/O for
diskette, parallel, serial, keyboard, mouse
Ports Back: Two serial, one parallel, two USB (Version 1.1), keyboard, mouse
Audio Integrated digital audio / software-based audio (done by processor and
810E) / AC '97 interface / ADI 1881 codec (analog mixing, Analog-to-Digital
and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires powered speakers
Ethernet controller Some models: IBM 10/100 EtherJet
10BaseT and 100BaseTX / RJ45 / Wake on LAN / part number 34L1201
Some models: 10/100 ethernet / Accton 32-bit PCI adapter / full duplex /
part number 19K4310
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows Me
Microsoft Windows Millennium Edition
- Lotus SmartSuite license
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
® ®
Microsoft Windows 2000 Professional
- Lotus ® SmartSuite ®
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (Windows NT 4.0 or
Windows 2000)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 12, 2000, November 14, 2000, or May 8, 2001
US models withdrawn effective November 2001
Slotxbay Processor
MHz 1
TM
3x4 Celeron 766/66
3x4 Celeron 800/100
3x4 Pentium ® III 933/133
3x4 Pentium III 1.0GHz
® Celeron 766MHz 1 with 66MHz Front Side Bus or
128KB std and max / ECC / full speed
3
III
4 CD-ROM / bootable
8
chip set / 82810 Graphics Memory Controller Hub (GMCH) /
5
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
Rapid Access
10.1GB IDE Disk ATA-66(Value)
15GB IDE Disk ATA-100 (Value)
5
Zip Drive 100MB (white)
Zip Drive 250MB (white/black)
license 6 5.25 to 3.5 DASD Bay Conversion K 70G8165
6 8X/4X/32X CD-RW Internal (black)
48X-20X
8X DVD-ROM Internal IDE (black)
DVD MPEG-2 Decoder Card
10/100 Accton
56K Data/Fax PCI modem
ADSL / V.90 Combo PCI low profile
V.90
10/20GB TR5 IDE Tape Drive (w/blk) 20L0549
Memory Disk CD-ROM Graphics
2
128MB 20GB 48X-20X
128MB 20GB 48X-20X GMCH 10/100 Accton
128MB 20GB 48X-20X GMCH 10/100 EtherJet
1 /133 128MB 20GB 48X-20X GMCH 10/100 EtherJet
TM PCI Management Adapter / 82559 /
TM Keyboard II (black)
4
IDE CD-ROM (white)
®
ethernet PCI adaptr 19K4301
10
Modem PCI low profile
Ethernet Chip
4
GMCH 10/100 Accton 810E Windows
810E Windows 2000 May2001
TM 810E Windows 2000 Feb 2001
810E Windows 2000 Feb 2001
Micro Tower Bay 5.25", HH 1.6", access, CD-ROM
Black Bay 5.25", HH 1.6" access, open
Bay 3.5", SL 1", access, std diskette
CD-ROM Bay 3.5", SL 1", no access, std disk
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)*
* ethernet adapter
diskette
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Swinging door on Bays 1 and 2
disk Handle on top
7.64" W X 15.0" D X 15.0" H
(vertical)
194mm W X 381mm D X 381mm H
18.25 to 22.5 lb (8.4 to 10.3 kg)
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support via optional
ethernet adapter
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U-bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY*
33L3071 3 year parts / 1 year labor warranty
33L3073
International Warranty Service
33L3075
1st year: on site, 8 am - 5 pm,
33L3174
Mon - Fri coverage,
00N8202
2nd business day response time
19K4463
20L0544 2nd/3rd year: parts exchange only,
00N8078
call 1-800-772-2227
3 year on site warranty service
33L5020
upgrade options:
33L5001
• Next day response, Mon-Fri 8-5
33L5016
33L5009 • 4 hour response, 7 day x 24 hr
Post warranty maintenance services
33L4618
available
19K4160
24 hour x 7 day telephone, electronic,
19K4162
and Internet support
No warranties are expressed or implied in this summary
(6270W)
Preload Available
® 5
Me Feb 2001
SECURITY
,9
9
7
7
IBM Corp. October 2001
