IBM NetVista A20 Reference Manual page 8

IBM
® NetVista A20 (6270) - withdrawn
TM
Name Type-model Color
A20 6270-D2U Black
A20 6270-E2U Black
A20 6270-E3U Black
A20 6270-E4U Black
A20 6270-F2U Black
A20 6270-F5U Black
A20 6270-H2U Black
A20 6270-H7U Black
A20 6270-M2U Black
A20 6270-M4U Black
A20 6270-N2U Black
A20 6270-N3U Black
A20 6270-N4U Black
A20 6270-P2U Black
A20 6270-P7U Black
Processor Intel
Intel Pentium III 733, 800EB, or 866MHz with 133MHz FSBus
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
Celeron:
L2 cache
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 64MB or 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
DVMT; uses main memory with no display cache
Disk ATA-66, SMART
Disk controller Enhanced IDE / ATA-66 / integrated into I/O Controller Hub (ICH)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM 48X-20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E
(GMCH) / 82801 I/O Controller Hub (ICH) for PCI 2.2 bus at
32-bit 33MHz, ATA-66 EIDE, USB, Low Pin Count Interface /
82802 Firmware Hub / Winbond 83627HF Super I/O for
diskette, parallel, serial, keyboard, mouse
Back: One serial, one parallel, two USB (Version 1.1), keyboard, mouse
Ports
Audio Integrated digital audio / software-based audio (done by processor and
810E) / AC '97 interface / ADI 1881 codec (analog mixing, Analog-to-Digital
and Digital-to-Analog conversion)
Back: microphone jack, line-in, line-out
Audio connectors
Speakers None / requires powered speakers
Ethernet controller Some models: IBM 10/100 EtherJet
10BaseT and 100BaseTX / RJ45 / Wake on LAN / part number 34L1201
Some models: IBM 10/100 EtherJet
(system does not support Alert on LAN) / 82559 / RJ45 / part number 34L1101
Some models: 10/100 ethernet / Accton 32-bit PCI adapter / full duplex /
part number 19K4310
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows 98
Microsoft Windows 98 Second Edition
- Lotus SmartSuite license
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
® ®
Microsoft Windows 2000 Professional
- Lotus ® SmartSuite ®
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (Windows NT 4.0 or
Windows 2000)
Software Selections CD-ROM
All trademarks are the property of their respective owners
US models announced September 12 or November 14, 2000
Models withdrawn from marketing effective March 2001 or May 2001
Slot/bay Processor MHz 1
TM
3x4 Celeron 566/66
3x4 Celeron 633/66
3x4 Celeron 633/66
3x4 Celeron 633/66
3x4 Celeron 667/66
3x4 Celeron 667/66
3x4 Celeron 733/66
3x4 Celeron 733/66
3x4 Pentium ® III 733/133
3x4 Pentium III 733/133
3x4 Pentium III 800/133
3x4 Pentium III 800/133
3x4 Pentium III 800/133
3x4 Pentium III 866/133
3x4 Pentium III 866/133
® Celeron 566, 633, 667, or 733MHz
128KB std and max / ECC / full speed
3
III
4 CD-ROM / bootable
8
chip set / 82810 Graphics Memory Controller Hub
5
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
Rapid Access
10.1GB IDE Disk ATA-66(Value)
15GB IDE Disk ATA-100 (Value)
5
Zip Drive 100MB (white)
Zip Drive 250MB (white/black)
license 6 5.25 to 3.5 DASD Bay Conversion K 70G8165
6 8X/4X/32X CD-RW Internal (black)
48X-20X
8X DVD-ROM Internal IDE (black)
DVD MPEG-2 Decoder Card
10/100 Accton
56K Data/Fax PCI modem
ADSL / V.90 Combo PCI low profile
V.90
10/20GB TR5 IDE Tape Drive (w/blk) 20L0549
Memory Disk CD-ROM Graphics Ethernet
2
64MB 10GB None
64MB 10GB None
64MB 10GB 48X-20X 4
128MB 10GB None
64MB 10GB 2 48X-20X GMCH
128MB 10GB None
64MB 10GB 48X-20X GMCH
128MB 10GB None
64MB 10GB None
128MB 10GB None
64MB 10GB None
64MB 10GB 48X-20X GMCH
128MB 10GB None
64MB 10GB 48X-20X GMCH
128MB 10GB None
1 with 66MHz FSBus or
TM PCI Management Adapter / 82559 /
TM
PCI Adapter with Alert on LAN 2
TM Keyboard II (black)
4
IDE CD-ROM (white)
®
ethernet PCI adaptr 19K4301
10
Modem PCI low profile
Chip
GMCH None 810E
GMCH None 810E
GMCH 10/100 EtherJet TM 810E
GMCH 10/100 EtherJet 810E
10/100 Accton 810E
GMCH 10/100 EtherJet 810E
10/100 Accton 810E
GMCH 10/100 EtherJet 810E
GMCH 10/100 Accton 810E
GMCH 10/100 EtherJet 810E
GMCH 10/100 Accton 810E
10/100 EtherJet 810E
GMCH 10/100 EtherJet 810E
10/100 Accton 810E
GMCH 10/100 34L1101 810E
Micro Tower
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)*
* ethernet adapter in some
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v)
CD-ROM
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Swinging door on Bay 1 to 2 (does
diskette
not cover Bay 1)
Handle on top
Black color with blue front panel
Bay 5.25", HH 1.6", access, CD-ROM
disk
Bay 5.25", HH 1.6" access, open
(vertical)
Bay 3.5", SL 1", access, std diskette
Bay 3.5", SL 1", no access, std disk
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U-bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support via optional
ethernet adapter
6270 Dimensions
- 7.64"W X 15.0"D X 15.0"H
- 194mm W X 381mm D X 381mm H
- 18.25 to 22.5 lb (8.4 to 10.3 kg)
LIMITED WARRANTY
33L3071 3 year parts / 1 year labor warranty
33L3073
International Warranty Service
33L3075
1st year: on site, 8 am - 5 pm,
33L3174
Mon - Fri coverage,
00N8202
2nd business day response time
19K4463
20L0544 2nd/3rd year: parts exchange only,
00N8078
call 1-800-772-2227
3 year on site options available:
33L5020
• Next day response
33L5001
• 4 hour response
33L5016
33L5009 Post warranty maintenance services
available
33L4618
IBM SystemXtra
19K4160
24 hour x 7 day telephone, electronic,
19K4162
and Internet support
No warranties are expressed or implied in this summary
Preload Avail
® 5
Windows 98 SE Sep 00
Windows 98 SE Sep 00
Windows 98 SE Sep 00
Windows 2000 Sep 00
Windows 98 SE Nov00
Windows 2000 Nov00
Windows 98 SE Nov00
Windows 2000 Nov00
Windows 98 SE Sep 00
Windows 2000 Sep 00
Windows 98 SE Sep 00
Windows 98 SE Sep 00
Windows 2000 Sep 00
Windows 98 SE Nov00
Windows 2000 Nov00
SECURITY
9
9
7 , Mon-Fri 8-5
7
, 7 day x 24 hr
,16
(6270) IBM Corp. May 2001
