NetVista™ M42 (8305) - March 2003 - withdrawn
Slot x
Name Type-model bay Processor
8305-A3U 3x4 Celeron
M42
8305-A4U 3x4 Celeron
M42
8305-A5U 3x4 Celeron
M42
8305-4BU 4x4 Pentium
M42
8305-4GU 4x4 Pentium 4 2.4
M42
8305-8BU 4x4 Pentium 4 2.66 512KB 533 256MB 40GB 7200 Combo
M42
8305-E4U 4x4 Pentium 4 3.06 512KB 533 256MB 40GB 7200 CD-ROM
M42
Positioning Stability and manageability for the enterprise
Processor
®
Intel
or Intel Pentium 4 at 2.4B, 2.66, or 3.06GHz with 533MHz FSB /
no Hyper-Threading technology support
L2 cache Celeron:
Pentium 4: 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 256MB std / 2GB max
8
Memory - sockets Two 184-pin gold plated DIMM sockets / one socket used
Memory - type PC2100 266MHz DDR-SDRAM / non-parity / industry std /
unbuffered / CAS Latency 2.5 (CL2.5)
Graphics controller Integrated Intel Extreme Graphics / Direct AGP / in 845GL/G
(one of following) GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
ATI Radeon 7000 / AGP 4X adapter /
Radeon GPU / 64MB std and max 332MHz DDR-SDRAM /
300MHz RAMDAC / one analog DB-15 connector
40GB, ATA-100, 7200 rpm,
Disk
rubber vibration dampening mounts
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Diskette drive 3.5" 1.44MB diskette drive
Optical One of following: 48X-20X
Cables Two EIDE 80-conductor cables (one 2-drop cable to optical, one 1-drop to disk)
Chipset Celeron:
Pentium 4: Intel 845G chipset / 82845G Graphics Memory Controller Hub
All:
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 2.0)
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
Audio Integrated digital audio / SoundMAX
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Audio connectors Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Speaker One internal speaker for business audio
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
(physical layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Some: IBM Embedded Security Subsystem 2.0
Security chip
Keyboard / mouse 104-key IBM Preferred Pro Full-size keyboard / IBM Std 2-Button PS/2 Mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows 2000
Microsoft Windows 2000 Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector
15
Norton AntiVirus (OEM Version)
InterVideo WinDVD (Combo models)
Veritas RecordNOW and DLA (Combo and
CD-RW models)
Downloadable (all)
Software Delivery Assistant
Software Migration Assistant
IBM Director Agent
IBM Client Security Sft (security chip models)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced March 4, 2003
US models withdrawn effective June 2003 or October 2003
L2 FSB
GHz cache MHz Memory
1.8 128KB 400 256MB 40GB
®
2.0 128KB 400 256MB 40GB 7200 CD-ROM
2.1 128KB 400 256MB 40GB 7200 CD-ROM
4 2.4 512KB 533 256MB 40GB 7200 CD-ROM
®
512KB 533 256MB 40GB 7200 CD-RW
Celeron 1.8, 2.0, or 2.1GHz with 400MHz frontside bus (FSB)
128KB std and max / ECC / full speed
CD-ROM,
4
48X/24X/48X Max CD-RW, or
4
32X/10X/40X/16X Max
Intel 845GL chipset / 82845GL Graphics Memory Controller Hub
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
®
multi-factor authentication / local file encryption / enhances VPN security
TCPA-compliant
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
1GB PC2100 NP CL2.5 DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
120GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541H 15" Flat Panel Monitor (black) 9512HB0
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8
and rpm Optical
7200 CD-ROM Extreme GMCH
2
Extreme GMCH
Extreme GMCH
Extreme GMCH
Extreme GMCH
Radeon 7000 64MB
Extreme GMCH
CD-RW/DVD-ROM Combo
11
3.0 with SPX / software-based audio
18 / hardware key storage /
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11 CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Security
Graphics chip Ethernet
10/100 XP Pro
10/100 XP Pro No Mar 2003
10/100 XP Pro No Mar 2003
10/100 2000
10/100 XP Pro No Mar 2003
10/100 XP Pro No Mar 2003
Chip 10/100 XP Pro No Mar 2003
Desktop
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1:* full-length, full-height, 32-bit AGP 4X (1.5v)* - used
Slot 2: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: full-length, full-height, 32-bit PCI 2.2 (5v)
* Slot not available on Celeron-based models
Stealth black color
16.7" W X 16.3"D X 5.5"H
425mm W X 414mm D X 140mm H
22 to 25 lb (10.0 to 11.4 kg)
Bay 1 and 2 in cage flips up (latched and pivoting)
Bay 3 and 4 in cage flips up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal; toolless AGP and PCI slots
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
Security chip models: Asset ID
(system-specific info in chip)
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
/
16
Diskette and disk I/O control
Serial/parallel I/O control
Security chip models: security chip
providing C2 tamper switch, Asset ID
keylock on chassis, and other features
33L3302
33L3304
33L3306
LIMITED WARRANTY
33L3308
3 year parts and labor
09N4248
International Warranty Service
09N4249
On site, 8 am - 5 pm, Mon - Fri
22P6950
coverage excluding holidays,
22P6997
next business day response time
On site service upgrade options (in
22P6973
eligible locations):
22P6959
• 3 year IOR 9x5, 4 hour response
22P6970
(ServicePac part number 41L2734)
09N4211
• 3 year IOR 24x7, 4 hour response
22P7099
(ServicePac part number 41L2740)
22P8998
• 4 year IOR 9x5, Next Business Day
(ServicePac part number 69P9161)
• 4 year IOR 9x5, 4 hour response
6656HG2
(ServicePac part number 69P9162)
• 4 year IOR 24x7, 4 hour response
(ServicePac part number 69P9163)
33L3478
14
24x7 toll-free support for warranty
issues during the warranty period
06P3839
(8305M)
Created by IBM PC Institute
Workhorse Avail
Preload or Global date
No Mar 2003
5
No Mar 2003
diskette
Optical
disk
std optical
open
std diskette
in
some
,19
19 ,
1
9
7
1
