NetVista™ M42 (8303) - November 2002 - withdrawn
Slot x
Name Type-model bay Processor
8303-D1U 4x3 Pentium
M42
8303-D2U 4x3 Pentium 4 2.8
M42
8303-E1U 4x3 Pentium 4 3.06 512KB 533 256MB 40GB CD-ROM
M42
8303-E2U 4x3 Pentium 4 3.06 512KB 533 256MB 40GB DVD-ROM Extreme GMCH
M42
8303-D3U 4x3 Pentium 4 2.8
M42
8303-46U 4x3 Pentium 4 2.4
M42
Stability and manageability for the enterprise
Positioning
Processor ® Pentium 4 at 2.4, 2.8 or 3.06GHz with 533MHz frontside
Intel
bus (FSB) / no Hyper-Threading technology support
512KB std and max / ECC / full speed
L2 cache
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 256MB std / 2GB max
8
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
40GB, ATA-100, 7200 rpm, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 16X-48X Max
DVD-ROM
Two EIDE 80-conductor cables (one 1-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
Integrated digital audio / SoundMAX
Audio
by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal speaker for business audio
Speaker
Some: 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
Some: 10/100/1000 gigabit ethernet on planar / Intel 82540EM PHY (physical
Some: IBM Embedded Security Subsystem 2.0
Security chip
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Mouse
Two or three variable speed fans (power supply, fansink, some have third fan)
Cooling fans
160 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows 2000
Microsoft Windows 2000 Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector
15
Norton AntiVirus (OEM Version)
InterVideo WinDVD (DVD models)
Downloadable (all)
Software Delivery Assistant
Software Migration Assistant
Remote Deployment Manager
IBM Director Agent
IBM Client Security Sft (security chip models)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced November 19, 2002 or March 4, 2003
US models withdrawn effective October 2003 or March 2004
L2 FSB
cache MHz Memory
GHz
4 2.8 512KB 533 256MB 40GB
®
512KB 533 256MB 40GB DVD-ROM Extreme GMCH
512KB 533 256MB 40GB CD-ROM
512KB 533 256MB 40GB CD-ROM
CD-ROM / bootable
4
4 DVD-ROM / bootable
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
3.0 with SPX / software-based audio (done
®
(physical layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
layer) and MAC / Intel Pro/1000MT Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
multi-factor authentication / local file encryption /
enhances VPN security / TCPA-compliant
16
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
1GB PC2100 NP CL2.5 DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/32X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner Plus internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541H 15" Flat Panel Monitor (black) 9512HB0
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE
8
disk Optical Graphics
CD-ROM Extreme GMCH
2
Extreme GMCH
Extreme GMCH
Extreme GMCH
Small Desktop
Bay
Bay
Bay
Slot 1:
Slot 2: Low Profile, 32-bit PCI 2.2 (5v)
Slot 3: Low Profile, 32-bit PCI 2.2 (5v)
Slot 4: Low Profile, 32-bit PCI 2.2 (5v)
Stealth black color
14.2" W X 16.2"D X 4.1"H
360mm W X 412mm D X 104mm H
18.0 to 20.0 lb (8.1 to 9.1 kg)
Bays 1 and 2/3 flip up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Support for 100 lb monitor on top
System stand for vertical orientation
/ hardware key storage /
18
33L3302
33L3304
33L3306
33L3308
09N4248
4 DVD-ROM Drive (black) 22P6950
CD-RW internal (blk) 22P7042
4
11 CD-RW/DVD-ROM
22P6973
22P6959
22P7036
09N4211
22P7099
22P8998
6656HG2
33L3478
06P3839
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Security Workhorse
chip Ethernet Preload or Global
10/100 XP Pro
5
Gigabit XP Pro
10/100 XP Pro
Gigabit XP Pro
Chip 10/100 XP Pro
10/100 2000
diskette
Optical
3.5", SL 1", access, std diskette
5.25", HH 1.6", access, std optical
3.5", SL 1", no access, std disk
Low Profile, 32-bit AGP 4X (1.5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
Security chip models: Asset ID
(system-specific info in chip)
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Security chip models: security chip
providing C2 tamper switch, Asset ID
keylock on chassis, and other features
LIMITED WARRANTY
3 year parts and labor
International Warranty Service
On site, 8 am - 5 pm, Mon - Fri
coverage excluding holidays,
next business day response time
On site service upgrade options (in
7
eligible locations):
• 3 year IOR 9x5, 4 hour response
(ServicePac part number 41L2734)
• 3 year IOR 24x7, 4 hour response
(ServicePac part number 41L2740)
• 4 year IOR 9x5, Next Business Day
(ServicePac part number 69P9161)
• 4 year IOR 9x5, 4 hour response
(ServicePac part number 69P9162)
• 4 year IOR 24x7, 4 hour response
(ServicePac part number 69P9163)
Post warranty maintenance
services available
14
24x7 toll-free support for warranty
issues during the warranty period
(8303V) IBM Corp. March 2004
Available
date
No Dec 2002
No Dec 2002
No Dec 2002
No Dec 2002
No Dec 2002
No Mar 2003
disk
,19
19 ,
1
9
1
