IBM
®
NetVista™ M42 (8303) - withdrawn
Slot x
Name Type-model bay
8303-21U 4x3 Pentium
M42
8303-22U 4x3 Pentium 4
M42
8303-24U 4x3 Pentium 4
M42
8303-27U 4x3 Pentium 4
M42
8303-31U 4x3 Pentium 4
M42
8303-33U 4x3 Pentium 4
M42
8303-36U 4x3 Pentium 4
M42
8303-41U 4x3 Pentium 4
M42
8303-42U 4x3 Pentium 4
M42
8303-43U 4x3 Pentium 4
M42
8303-26U 4x3 Pentium 4
M42
8303-35U 4x3 Pentium 4
M42
8303-44U 4x3 Pentium 4
M42
Stability and manageability for the enterprise
Positioning
®
Processor
Intel
L2 cache 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
128MB or 256MB std / 1GB max
Memory - std/max 8
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
(one of following)
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
ATI Radeon 7000 / AGP 4X adapter /
Radeon GPU / 64MB std and max 332MHz DDR-SDRAM /
300MHz RAMDAC / one analog DB-15 connector
40 or 80GB, ATA-100, 7200 rpm, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 16X-48X Max
DVD-ROM
Two EIDE 80-conductor cables (one 1-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal speaker for business audio
Speaker
Some: 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
Some: 10/100/1000 gigabit ethernet on planar / Intel 82540EM PHY (physical
Some: IBM Embedded Security Subsystem 2.0
Security chip
104-key IBM Preferred Pro Full-size keyboard / IBM Std 2-Button PS/2 Mouse
Keyboard / mouse
Two or three variable speed fans (power supply, fansink, some have third fan)
Cooling fans
160 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows 2000
Microsoft Windows 2000 Professional
®
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
InterVideo WinDVD (DVD models)
Downloadable (all)
IBM Rapid Restore PC
IBM Data Transfer
IBM Director Agent
IBM Client Security Sft (security chip models)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced June 4, 2002
US models withdrawn effective May, October, or December 2003
L2 FSB
Processor GHz cache MHz
4 2.0 512KB 400 256MB 40GB
®
2.0 512KB 400 128MB 40GB CD-ROM
2.0 512KB 400 256MB 40GB CD-ROM
2.0 512KB 400 128MB 40GB CD-ROM
2.26 512KB 533 256MB 40GB CD-ROM
2.26 512KB 533 256MB 40GB CD-ROM
2.26 512KB 533 128MB 40GB CD-ROM
2.4 512KB 533 256MB 40GB DVD-ROM Extreme GMCH
2.4 512KB 533 256MB 40GB CD-ROM
2.4 512KB 533 256MB 80GB DVD-ROM Radeon 7000 64MB
2.0 512KB 400 256MB 40GB CD-ROM
2.26 512KB 533 256MB 40GB CD-ROM
2.4 512KB 533 256MB 40GB CD-ROM
Pentium 4 at 2.0, 2.26, 2.4GHz with 400 or 533MHz FSB
CD-ROM / bootable
4
DVD-ROM / bootable
4
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
®
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
layer) and MAC / Intel Pro/1000MT Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
multi-factor authentication / local file encryption /
enhances VPN security 16 / TCPA-compliant
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/32X/48X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)66274AN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE
8
Memory disk Optical
CD-ROM
2
3.0 with SPX / software-based audio
18 / hardware key storage /
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
CD-RW/DVD-ROM
11
Personal Systems Reference (PSREF)
Security
Graphics chip Ethernet
Extreme GMCH 10/100
Extreme GMCH 10/100
Radeon 7000 64MB 10/100
Extreme GMCH 10/100
Extreme GMCH 10/100
Radeon 7000 64MB 10/100
Extreme GMCH 10/100
Gigabit XP Pro Jun 2002
Extreme GMCH 10/100
Gigabit XP Pro Jun 2002
Extreme GMCH Chip 10/100
Extreme GMCH Chip 10/100
Extreme GMCH Chip 10/100
Small Desktop
diskette
Bay 3.5", SL 1", access,
Bay 5.25", HH 1.6", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: Low Profile, 32-bit AGP 4X (1.5v) - used in some
Slot 2: Low Profile, 32-bit PCI 2.2 (5v)
Slot 3: Low Profile, 32-bit PCI 2.2 (5v)
Slot 4: Low Profile, 32-bit PCI 2.2 (5v)
Stealth black color
14.2" W X 16.2"D X 4.1"H
360mm W X 412mm D X 104mm H
20.0 to 22.0 lb (9.1 to 10.0 kg)
Bays 1 and 2/3 flip up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Support for 100 lb monitor on top
System stand for vertical orientation
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Security chip models: Asset ID
(system-specific info in chip)
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Security chip models: security chip
providing C2 tamper switch, Asset ID
keylock on chassis, and other features
LIMITED WARRANTY
33L3302
33L3304
3 year parts and labor
33L3306
International Warranty Service
09N4248
On site, 8 am - 5 pm, Mon - Fri
22P6950
coverage excluding holidays,
22P7042
next business day response time
10K3790
3 year on site warranty service
22P6959
upgrade options
09N4211
• 4 hour response, Mon-Fri 8-5
22P8998
(ServicePac part number 41L2734)
• 4 hour response, 7 day x 24 hr
9512AB1
(ServicePac part number 41L2740)
6656HG2
Post warranty maintenance
22P5170
services available
33L3478
14
24x7 toll-free support for warranty
issues during the warranty period
06P3839
(8303)
Created by IBM PC Institute
Available
Preload date
XP Pro Jun 2002
5
XP Pro Jun 2002
XP Pro Jun 2002
2000 Jun 2002
XP Pro Jun 2002
XP Pro Jun 2002
2000 Jun 2002
XP Pro Jun 2002
XP Pro Jun 2002
XP Pro Jun 2002
XP Pro Jun 2002
Optical
disk
std diskette
std optical
,19
19 ,
1
9
7
:
1
IBM Corp. December 2003
