IBM NetVista A20 Reference Manual page 6

IBM
® NetVista A20 (6269) - Spring 2001 - withdrawn
TM
Name Type-model Color
A20 6269-AFU White 3x4
A20 6269-AGU White 3x4
A20 6269-V4U White 3x4
Processor Intel
Intel Pentium
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array(FC-PGA)
in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 64MB or 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller
AGP 2X-class graphics / Direct AGP / in 82810 Graphics
Memory Controller Hub (GMCH) /
0MB std and max display cache / Dynamic Video Memory
Technology (DVMT) uses main memory /
2D and 3D hardware acceleration / VESA DPMS, DDC1/DDC2B /
15-pin D-shell analog connector on back
Disk ATA-66, SMART
Disk controller Enhanced IDE/ ATA-66 / integrated into I/O Controller Hub (ICH)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM 48X-20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set
Intel 810E
82801 I/O Controller Hub (ICH) for PCI 2.2 bus at 32-bit 33MHz,
ATA-66 EIDE, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627HF Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Back: Two serial, one parallel, two USB (Version 1.1), keyboard, mouse
Audio Integrated digital audio / software-based audio (done by processor and
810E) / AC '97 interface / ADI 1881 codec (analog mixing, Analog-to-Digital
and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out, MIDI/game port
Speakers None / requires powered speakers
Modem None standard
Ethernet controller 10/100 ethernet / Accton 32-bit PCI adapter / full duplex /
part number 19K4310
Systems mgmt cntrl None / no support for monitoring of voltages or temperatures
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows 98SE
Microsoft Windows 98 Second Edition
- Lotus SmartSuite license
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
Microsoft ® Windows ® 2000 Professional
® ®
- Lotus SmartSuite
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (Windows NT 4.0 or
Windows 2000)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced May 8, 2001
US models withdrawn effective November 2001
Slotxbay Processor MHz 1
Celeron 800/100
Celeron 800/100
Pentium III 1GHz/133
® Celeron TM 800MHz with 100MHz Front Side Bus or
®
III 1.0GHz with 133MHz Front Side Bus
128KB std and max / ECC / full speed
3 III
4
CD-ROM / bootable
8
chip set / 82810 Graphics Memory Controller Hub (GMCH) /
5
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6 256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access
10.1GB IDE Disk ATA-66(Value)
5
15GB IDE Disk ATA-100 (Value)
Zip Drive 250MB
6
license 8X/4X/32X
6
48X-20X
8X/32X max DVD-ROM (pearl white) 33L5015
DVD MPEG-2 Decoder Card
10/100 Accton
TR5 IDE Tape Drive
TR5 SCSI Tape Drive
USB External Zip
56K Data/Fax PCI modem
ADSL / V.90 Combo PCI low profile
V.90 Modem PCI low profile
Memory Disk CD Graphics
128MB 20GB CD-ROM GMCH 10/100 Accton
64MB 10GB CD-ROM GMCH 10/100 Accton
64MB 10GB CD-ROM GMCH 10/100 Accton
Desktop 6269
Slot 1: 8 inch
Slot 2: 8 inch max, 32-bit PCI 2.2 (5v)
Slot 3: 8 inch max, 32-bit PCI 2.2 (5v)
Bay
Bay
Bay
Bay
33L3071
33L3073
33L3075
TM Keyboard II (p wht) 33L3154
TM Keyboard II (black) 33L3174
00N8202
19K4463
00N8078
4 CD-RW (pearl white) 33L5019
4 IDE CD-ROM (pearl white) 33L5001
33L5009
®
ethernet PCI adaptr 19K4310
20L0549
01K1319
00N9911
33L4618
19K4160
19K4162
Ethernet Chip Preload
810E Windows 2000 May 2001
810E Windows 98SE May 2001
810E Windows 98SE May 2001
max, 32-bit PCI 2.2 (5v) - ethernet adapter
5.25", HH 1.6", access, standard CD-ROM
5.25", HH 1.6" access, open
3.5", SL 1", access, std diskette
3.5", SL 1", no access, std disk
diskette
CD-ROM
disk
Dimensions
- 16.7"W X 16.7"D X 5.5"H
- 425mmW X 425mmD X 140mmH
- 23 lb
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
SECURITY
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800
U-bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY*
3 year parts / 1 year labor warranty
International Warranty Service
1st year: on site, 8 am - 5 pm,
Mon - Fri coverage,
2nd business day response time
2nd/3rd year: parts exchange only,
call 1-800-772-2227
3 year on site warranty service
upgrade options:
• Next day response, Mon-Fri 8-5
• 4 hour response, 7 day x 24 hr
Post warranty maintenance services
available
24 hour x 7 day telephone, electronic,
and Internet support
No warranties are expressed or implied in this summary
(6269S) IBM Corp. October 2001
Available
Pearl white color
Bay 1 and 2 in
cage flips up
Bay 3 and 4 in
cage flips up
