NetVista™ M42 (8301) - withdrawn
Slot x
Name Type-model bay
8301-22U 0x2 Pentium
M42
8301-32U 0x2 Pentium 4
M42
8301-51U 0x2 Pentium 4
M42
8301-52U 0x2 Pentium 4
M42
8301-53U 0x2 Pentium 4
M42
8301-41U 0x2 Pentium 4
M42
8301-61U 0x2 Pentium 4
M42
8301-81U 0x2 Pentium 4
M42
8301-E1U 0x2 Pentium 4
M42
Stability and manageability for the enterprise
Positioning
Processor
Intel
with 400 or 533MHz frontside bus (FSB) /
no Hyper-Threading technology support
512KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
128MB or 256MB std / 2GB* max
Memory - std/max
8
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
Disk 40GB, ATA-100, 7200 rpm, rubber vibration dampening mounts
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
None
Diskette drive
48X-20X
CD-ROM
Two EIDE 80-conductor cables (one 1-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal speaker for business audio
Speaker
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
None
Security chip
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Mouse
Two variable speed fans (power supply and fansink)
Cooling fans
125 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Downloadable (all)
IBM Rapid Restore PC
Remote Deployment Manager
Software Delivery Assistant
IBM Director Agent
Software Migration Assistant
Update Connector
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced June 4, August 27, or November 19, 2002
US models withdrawn effective May 2003, October 2003, or December 2003
* Memory upgrades supported only by special bid (not customer upgradable)
L2 FSB
Processor GHz cache MHz
® 4 2.0 512KB 400 128MB 40GB
2.26 512KB 533 128MB 40GB CD-ROM Extreme GMCH
1.8 512KB 400 256MB 40GB CD-ROM Extreme GMCH
1.8 512KB 400 128MB 40GB CD-ROM Extreme GMCH
1.8 512KB 400 256MB 40GB None
2.4 512KB 533 256MB 40GB CD-ROM Extreme GMCH
2.53 512KB 533 256MB 40GB CD-ROM Extreme GMCH
2.66 512KB 533 256MB 40GB CD-ROM Extreme GMCH
3.06 512KB 533 256MB 40GB CD-ROM Extreme GMCH
®
Pentium 4 at 1.8, 2.0, 2.26, 2.4, 2.53, 2.66 or 3.06GHz
CD-ROM / bootable
4
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM* 33L3302
256MB PC2100 CL2.5 NP DDR UDIMM* 33L3304
512MB PC2100 CL2.5 NP DDR UDIMM* 33L3306
5
1GB PC2100 NP CL2.5 DDR UDIMM*
80GB IDE Disk ATA-100 (7200 rpm)
IBM 48X-20X
IBM 16X Max
48X/32X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner Plus internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
15
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE
8
Memory disk Optical
2 CD-ROM Extreme GMCH No
Extreme GMCH
® 3.0 with SPX / software-based audio
CD-ROM internal (black)
4
DVD-ROM Drive (black)
4
4 CD-RW internal (blk)
11 CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Security
Graphics chip Ethernet
10/100 XP Pro
No 10/100 XP Pro
No 10/100 XP Pro
No 10/100 XP Pro
No 10/100 2000
No 10/100 XP Pro
No 10/100 XP Pro
No 10/100 XP Pro
No 10/100 XP Pro
Mini Desktop
Optical
Bay 5.25", HH 1.6", access, std optical
Bay 3.5", SL 1", access, std disk
Slots: No usable slots
Stealth black color
12.2" W X 13.5"D X 4.3"H
310mm W X 343mm D X 110mm H
18.0 to 20.0 lb (8.1 to 9.1 kg)
Hard disk slides out from front without tools
Toolless rails for disk mounting
Support for 100 lb monitor on top
System stand for vertical orientation
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
8301: keylock (right side) locks cover and
disk (so disk can not be removed from
front)
LIMITED WARRANTY
3 year parts and labor
International Warranty Service
On site, 8 am - 5 pm, Mon - Fri
33L3308
coverage excluding holidays,
09N4248
next business day response time
10K3782
On site service upgrade options
22P6950
(in eligible locations):
22P7042
• 3 year IOR 9x5, 4 hour response
(ServicePac part number 41L2734)
22P6973
• 3 year IOR 24x7, 4 hour response
22P6959
(ServicePac part number 41L2740)
22P7036
• 4 year IOR 9x5, Next Business Day
09N4211
(ServicePac part number 69P9161)
22P7099
• 4 year IOR 9x5, 4 hour response
22P8998
(ServicePac part number 69P9162)
• 4 year IOR 24x7, 4 hour response
9512AB1
(ServicePac part number 69P9163)
6656HG2
Post warranty maintenance
services available
14
24x7 toll-free support for warranty
33L3478
issues during the warranty period
06P3839
(8301)
Created by IBM PC Institute
Workhorse Available
Preload or Global date
5 No Jun 2002
No Jun 2002
No Sep2002
No Sep2002
No Sep2002
No Sep2002
No Sep2002
No Dec2002
No Dec2002
disk
1
9
7
1
IBM Corp. March 2004
