® NetVista M41 (6792) - January 2002 - withdrawn
TM
Slot x
Name Type-model Color
M41 6792-42U Black 4x4 Pentium
M41 6792-43U Black 4x4 Pentium 4 2.2GHz 512KB 256MB 40GB CD-ROM
M41 6792-44U Black 4x4 Pentium 4 2.2GHz 512KB 256MB 40GB DVD-ROM Radeon 64MB
M41 6792-45U Black 4x4 Pentium 4 2.2GHz 512KB 256MB 40GB CD-ROM
M41 6792-2HU Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM
M41 6792-2JU Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB DVD-ROM Radeon 64MB
M41 6792-3JU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB DVD-ROM NVIDIA 16MB
M41 6792-3KU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB DVD-ROM Radeon 64MB
M41 6792-3MU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM
M41 6792-3NU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM
M41 6792-3SU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM
M41 6792-3VU Black 4x4 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM
Maximum performance and stability with enhanced security models
Positioning
Processor Intel
with 400MHz frontside bus
L2 cache 256KB or 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 256MB std / 1.5GB max
Memory - sockets Three 168-pin gold plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2) / supports optional ECC
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
(one of following) TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
ATI
Radeon VE (RV100) GPU / 64MB std and max 155MHz
SDRAM / 300MHz RAMDAC / one analog DB-15 connector
Disk ATA-100, SMART
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM Some models: 48X-20X
Some models: 16X/48X Max
DVD-ROM
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD or DVD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers One internal speaker for business audio
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Security chip Some models: IBM Embedded Security Subsystem
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
®
Lotus SmartSuite license
Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Professional
Microsoft Windows XP Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
W=Workhorse models
G=Global models
See footnotes for important warranty information
US models announced January 22, 2002
US models withdrawn effective October or December 2002
L2
bay Processor GHz cache
® 4 2.2GHz 512KB 256MB 40GB
® Pentium 4 at 1.8, 2.0, and 2.2GHz
® Radeon 7000 (advanced 3D) / AGP 4X adapter /
3
III; 20GB: value, 40GB: 7200 rpm
4
CD-ROM / bootable
4
DVD (ATAPI), bootable
ethernet,monitor
to motherboard which enables 256-bit encryption,
Asset EEPROM, RFID antenna
Options
5
64MB SDRAM 133MHz CL2 NP DIMM
128MB SDRAM 133MHz CL2 NP DIMM
6
256MB SDRAM 133MHz CL2 NP DIMM
6
512MB SDRAM 133MHz CL2 NP DIMM
40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
5
40X/12X/40X Max
8X/4X/32X/8X Max
6
Combo drive (black)
6
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 33L3250
Other options at ibm.com/pc/us/accessories
Mem Disk CD or DVD
2 CD-ROM NVIDIA 16MB
NVIDIA 16MB
NVIDIA 16MB
NVIDIA 16MB
NVIDIA 16MB
GeForce2 32MB
NVIDIA 16MB
NVIDIA 16MB
Desktop
Bay
Bay
Bay
Bay
Slot 1:
Slot 2: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: full-length, full-height, 32-bit PCI 2.2 (5v)
® 3.0 with SPX / software-based audio
18 / daughtercard attached
13 , and C2 tamper switch
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Graphics Security Preload
Windows ®
Windows XP Pro
Windows XP Pro
Chip Windows XP Pro
Windows XP Pro W G Feb 2002
Windows XP Pro
Windows XP Pro W G Feb 2002
Windows XP Pro
Windows XP Pro
Windows XP Pro
Chip Windows 2000
Chip Windows XP Pro
diskette
disk
5.25", HH 1.6", access,
5.25", HH 1.6" access,
3.5", SL 1", access,
3.5", SL 1", no access, std disk
full-length, full-height, 32-bit AGP 4X (1.5v) - used
16.7" W X 16.7"D X 5.5"H
425mm W X 425mm D X 140mm H
24 to 26.5 lb (10.9 to 12.0 kg)
Stealth black color
Bay 1 and 2 in cage flips up (latched and pivoting)
Bay 3 and 4 in cage flips up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Some models: Security chip providing
encryption, Asset ID (RFID)
C2 tamper switch
LIMITED WARRANTY
10K0055
10K0057 3 year parts and labor
10K0059
International Warranty Service
10K0061
On site, 8 am - 5 pm, Mon - Fri
22P7156
coverage excluding holidays,
09N4207
next business day response time
22P6950
22P6976 3 year on site warranty service
upgrade options
10K3790
• 4 hour response, Mon-Fri 8-5
22P6959
(ServicePac part number 41L2734)
00N8078
• 4 hour response, 7 day x 24 hr
(ServicePac part number 41L2740)
9511AG4
6656HG2
Post warranty maintenance
651767N
services available
33L3478
14
24x7 toll-free support for warranty
issues during the warranty period
(6792J) IBM Corp. December 2002
Available
W or G date
2000 5 Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Optical
std CD or DVD
open
std diskette
13
