IBM NetVista A20 Reference Manual page 56

IBM
® NetVista M41 (6792) - withdrawn
TM
Slot x
Name Type-model Color
M41 6792-11U Black 4x4 Pentium
M41 6792-15U Black 4x4 Pentium 4 1.6GHz 256KB 128MB 40GB CD-ROM
M41 6792-21U Black 4x4 Pentium 4 1.8GHz 256KB 128MB 40GB CD-ROM
M41 6792-22U Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM
M41 6792-23U Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB DVD-ROM NVIDIA 32MB
M41 6792-24U Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM
M41 6792-25U Black 4x4 Pentium 4 1.8GHz 256KB 128MB 40GB CD-ROM
M41 6792-31U Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM
M41 6792-32U Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB DVD-ROM NVIDIA 32MB
M41 6792-33U Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM
M41 6792-3DU Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM
M41 6792-2DU Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM
M41 6792-2EU Black 4x4 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM
M41 6792-3GU Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM
M41 6792-39U Black 4x4 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM
Maximum performance and stability with enhanced security models
Positioning
Processor Intel
L2 cache 256KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 128MB or 256MB std / 1.5GB max
Memory - sockets Three 168-pin gold plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2) / supports optional ECC
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
(one of following) TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
Disk ATA-100, 7200 rpm, SMART
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM Some models: 48X-20X
DVD-ROM Some models: 16X/48X Max
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD or DVD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers One internal speaker for business audio
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Some models: IBM Embedded Security Subsystem
Security chip
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite ® license
®
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Home
Microsoft Windows XP Home Edition
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Professional
Microsoft Windows XP Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
See footnotes for important warranty information
US models announced on September 18 or November 27, 2001
US models withdrawn effective March, July, or October 2002
L2
bay Processor GHz cache
®
4 1.6GHz 256KB 128MB 40GB
®
Pentium 4 at 1.6, 1.8, 2.0GHz with 400MHz frontside bus
3 III
4 CD-ROM / bootable
4
DVD (ATAPI), bootable
ethernet,monitor
to motherboard which enables 256-bit encryption,
Asset EEPROM, RFID antenna
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
128MB SDRAM 133MHz CL2 NP DIMM
6
6 256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
2-Piece Speakers (black)
3-Piece Speakers (black)
5 40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
6
12X/8X/32X Max
6
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
5
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
6
IBM T560 15" Flat Panel Monitor (black)
6
IBM E74M 17" (15.9" view) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 33L3250
Mem Disk CD or DVD
2
CD-ROM
Desktop
Bay
Bay
Bay
Bay
Slot 1:
Slot 2: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: full-length, full-height, 32-bit PCI 2.2 (5v)
® 3.0 with SPX / software-based audio
18
/ daughtercard attached
13
, and C2 tamper switch
4
DVD-ROM Drive (black)
4 CD-RW internal (black) 10K3785
11
CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Graphics Security Preload
NVIDIA 16MB Windows
NVIDIA 16MB Windows XP Home Oct 2001
NVIDIA 16MB Windows 2000
NVIDIA 16MB Windows 2000
Windows 2000
NVIDIA 16MB Chip Windows 2000
NVIDIA 16MB Windows XP Home Oct 2001
NVIDIA 16MB Windows 2000
Windows 2000
NVIDIA 16MB Chip Windows 2000
NVIDIA 16MB Windows XP Pro
NVIDIA 16MB Windows XP Pro
NVIDIA 16MB Chip Windows XP Pro
NVIDIA 16MB Chip Windows XP Pro
NVIDIA 32MB Windows XP Pro
diskette
5.25", HH 1.6", access,
5.25", HH 1.6" access,
3.5", SL 1", access,
3.5", SL 1", no access, std disk
full-length, full-height, 32-bit AGP 4X (1.5v) - used
16.7" W X 16.7"D X 5.5"H
425mm W X 425mm D X 140mm H
24 to 26.5 lb (10.9 to 12.0 kg)
Stealth black color
Bay 1 and 2 in cage flips up (latched and pivoting)
Bay 3 and 4 in cage flips up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Some models: Security chip providing
encryption, Asset ID (RFID)
C2 tamper switch
10K0055
10K0057
LIMITED WARRANTY
10K0059
3 year parts and labor
10K0061
International Warranty Service
33L3440
33L3441 On site, 8 am - 5 pm, Mon - Fri
22P7156
coverage excluding holidays,
09N4207
next business day response time
22P6950
3 year on site warranty service
upgrade options
10K3790
• 4 hour response, Mon-Fri 8-5
22P6959
(ServicePac part number 41L2734)
00N8078
• 4 hour response, 7 day x 24 hr
(ServicePac part number 41L2740)
9511AG4
Post warranty maintenance
6656HG2
651767N services available
22P5170
24x7 14 toll-free support for warranty
33L3478
issues during the warranty period
(6792)
Available
date
® 5
2000 Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Nov 2001
Nov 2001
Nov 2001
Nov 2001
Optical
disk
std CD or DVD
open
std diskette
13
, and
1
9
7 :
1
