IBM NetVista A20 Reference Manual page 55

IBM
® NetVista M41 (6790) - withdrawn
TM
Slot x
Name Type-model Color
M41 6790-11U Black 4x3 Pentium
M41 6790-13U Black 4x3 Pentium 4 1.6GHz 256KB 128MB 40GB CD-ROM NVIDIA 16MB
M41 6790-21U Black 4x3 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-22U Black 4x3 Pentium 4 1.8GHz 256KB 128MB 40GB CD-ROM NVIDIA 16MB
M41 6790-23U Black 4x3 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-31U Black 4x3 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-32U Black 4x3 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-2DU Black 4x3 Pentium 4 1.8GHz 256KB 128MB 40GB CD-ROM NVIDIA 16MB
M41 6790-25U Black 4x3 Pentium 4 1.8GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-34U Black 4x3 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-35U Black 4x3 Pentium 4 2.0GHz 256KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-42U Black 4x3 Pentium 4 2.2GHz 512KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-43U Black 4x3 Pentium 4 2.2GHz 512KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-44U Black 4x3 Pentium 4 2.2GHz 512KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-3AU Black 4x3 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM NVIDIA 16MB
M41 6790-3BU Black 4x3 Pentium 4 2.0GHz 512KB 256MB 40GB CD-ROM NVIDIA 16MB
Positioning Maximum performance and stability with enhanced security models
Processor
Intel
with 400MHz frontside bus
L2 cache 256KB or 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max
128MB or 256MB std / 1GB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2) / supports optional ECC
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
Disk ATA-100, SMART
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 48X-20X
DVD-ROM Option
Cables Two EIDE 80-conductor cables (one 1-drop cable to CD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers One internal speaker for business audio
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Security chip
Some models: IBM Embedded Security Subsystem
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Cooling fans Two or three variable speed fans (power supply, fansink, some have third fan)
Power supply 160 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Home
Microsoft Windows XP Home Edition
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Professional
Microsoft Windows XP Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
See footnotes for important warranty information
US models announced on Sept 18, 2001 or Nov 27, 2001 or January 22, 2002
US models withdrawn effective March 2002 or July 2002 or October 2002
L2
bay Processor GHz cache
® 4 1.6GHz 256KB 128MB 40GB
®
Pentium 4 at 1.6, 1.8, 2.0, or 2.2GHz
3 III; 20GB: value, 40GB: 7200 rpm
4
CD-ROM / bootable
ethernet, monitor
to motherboard which enables 256-bit encryption,
Asset EEPROM, RFID antenna
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
6
128MB SDRAM 133MHz CL2 NP DIMM
6 256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
2-Piece Speakers (black)
40GB IDE Disk ATA-100 (5400 rpm)
5
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
40X/12X/40X Max
6
8X/4X/32X/8X Max
6
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
5
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
6
IBM E74M 17" (15.9" view) Monitor (blk)
6
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 33L3250
Other options at ibm.com/pc/us/accessories
Mem Disk CD-ROM
2 CD-ROM NVIDIA 16MB
Desktop
Small Form Factor
Bay
Bay
Bay
Slot 1:
Slot 2: Low Profile, 32-bit PCI 2.2 (5v)
Slot 3: Low Profile, 32-bit PCI 2.2 (5v)
Slot 4: Low Profile, 32-bit PCI 2.2 (5v)
® 3.0 with SPX / software-based audio
18
/ daughtercard attached
13 , and C2 tamper switch
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11 CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Graphics Security Preload
Windows
Windows XP Home
Windows 2000
Windows 2000
Chip Windows 2000
Windows 2000
Chip Windows 2000
Windows XP Pro
Chip Windows XP Pro
Windows XP Pro
Chip Windows XP Pro
Windows 2000
Windows XP Pro
Chip Windows XP Pro
Windows XP Pro
Chip Windows XP Pro
diskette
3.5", SL 1", access,
5.25", HH 1.6", access,
3.5", SL 1", no access, std disk
Low Profile, 32-bit AGP 4X (1.5v) - used
14.2" W X 16.2"D X 4.1"H
360mm W X 412mm D X 104mm H
20.0 to 22.0 lb (9.1 to 10.0 kg)
Stealth black color
Bays 1 and 2/3 flip up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Support for 100 lb monitor on top
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Some models: Security chip providing
encryption, Asset ID (RFID)
C2 tamper switch
10K0055
LIMITED WARRANTY
10K0057
10K0059
3 year parts and labor
10K0061
International Warranty Service
33L3440
On site, 8 am - 5 pm, Mon - Fri
22P7156
coverage excluding holidays,
09N4207
next business day response time
22P6950
22P6976 3 year on site warranty service
upgrade options
10K3790
• 4 hour response, Mon-Fri 8-5
22P6959
(ServicePac part number 41L2734)
00N8078
• 4 hour response, 7 day x 24 hr
9511AG4 (ServicePac part number 41L2740)
6656HG2
Post warranty maintenance
651767N
services available
22P5170
14
24x7 toll-free support for warranty
33L3478
issues during the warranty period
(6790)
Available
date
® 2000 5 Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Oct 2001
Nov2001
Nov2001
Nov2001
Nov2001
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
CD-ROM
disk
std diskette
std CD-ROM
13
, and
1
9
7
:
1
IBM Corp. October 2002
