NetVista A60 (6833) - withdrawn
IBM
Processor GHz
Type-model
6833-20U Pentium ® 4 1.3 128MB 20GB
6833-21U Pentium 4 1.3 256MB
6833-61U Pentium 4 1.5 256MB 60GB EIDE 7.2K
6833-23U Pentium 4 1.3 128MB
6833-25U Pentium 4 1.3 128MB
6833-45U Pentium 4 1.4 128MB
6833-46U Pentium 4 1.4 256MB
6833-71U Pentium 4 1.7 256MB
6833-72U Pentium 4 1.7 256MB 40GB EIDE 7.2K
6833-73U Pentium 4 1.7 256MB 60GB EIDE 7.2K
Processor Intel Pentium 4 1.3, 1.4, 1.5, or 1.7GHz
L2 cache 256KB std and max / at processor speed
Implementation Processor and L2 cache in Pin Grid Array (PGA) / motherboard contains one Intel PGA423 socket (with Pentium 4 and heat
sink), four RIMM sockets, three PCI slots, one AGP slot, and 850 chipset with heat sink
SMP support No SMP support
Memory - std / max 128MB or 256MB std / 1.5GB max / dual RDRAM (Rambus) channels / 32 devices max each channel
Memory - features 128MB models: Two 4D 64MB PC800 RIMMs, non-parity
256MB models: Two 8D 128MB PC800 RIMMs, non-parity
Four 184-pin gold-plated RIMM sockets (two per channel) / two RIMMs installed (one per channel) /
CRIMMs in two sockets / supports PC600 or PC800 RIMMs (not PC700) / mixing PC600 and PC800 RIMMs results in
PC600 performance / all installed RIMMs must be installed in pairs across both channels / no support for ECC function
Graphics controller
NVIDIA TNT2 M64 (2D and 3D) / AGP 4X adapter / TNT2 GPU / 16MB std and max 125MHz SDRAM /
(one of the following) max resolution of 1600x1200 with 16.7 million colors at 85Hz / one analog DB-15 connector
NVIDIA TNT2 M64 (2D and 3D) / AGP 4X adapter / TNT2 GPU / 32MB std and max 125MHz SDRAM /
max resolution of 1600x1200 with 16.7 million colors at 85Hz / one analog DB-15 connector
IDE disk controller
Enhanced IDE busmaster / ATA-100 / two connectors on planar
Cables
Two EIDE cables (one 2-drop cable to CD, one 1-drop cable to EIDE disk)
Disk - features Enhanced IDE (EIDE) / ATA-100 / S.M.A.R.T.
Chipsets
Intel 850 chip set / MCH (Memory Controller Hub) / I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE, USB,
Low Pin Count Interface / Firmware Hub / Winbond W83627F Super I/O off LPC interface
100/10Mbps ethernet
10/100 ethernet / Accton PCI adapter / 10BaseT, 100BaseTX /
full duplex / RJ-45 port / part number 19K4310
CD-ROM Some models: 48X-20X
CD-RW 11 Some models: 12X-8X-32X
DVD Some models: 16X-40X
Diskette 3.5" 1.44MB diskette drive
Audio Integrated digital audio / software-based (done by processor and ICH2) /
AC '97 interface / ADI 1881 codec / powered speakers required
External ports Four USB (two in front, two in back) [Ver 1.1] / one serial 9-pin /
parallel (EPP, ECP), IEEE 1284 / keyboard / mouse /
MIDI (joystick) port (DB-15) / audio line in / audio line out / microphone in
Systems mgmt SMART Reaction / Wake on LAN support / no Alert on LAN /
no Asset ID
Keyboard / mouse
IBM 104-key keyboard / IBM 2-button mouse
Cooling fans Three variable speed fans (power supply, rear, processor) / not redundant
Power supply
200 watts / universal / manual switch
Micro Tower
Slot 1:
Black
Slot 2: 9" max length, 32-bit PCI 2.2 (5v) - used by ethernet adapter
Slot 3: 9" max
Slot 4: 9" max length, 32-bit PCI 2.2 (5v)
Bay
diskette Bay
Bay
Bay
Handle grip on top
disk
H 15.0" x W 7.6" x D 15.0"
(vertical)
H 381mm x W 194mm x D 381mm
22.5 pounds max (10.2 kg)
Options
64MB PC800 NP RDRAM RIMM (4 Dev)
128MB PC800 NP RDRAM RIMM (8 Dev)
256MB PC800 NP RDRAM RIMM (16 Dev)
512MB PC800 ECC RDRAM RIMM (16 Dev) 33L3254
IBM 30GB ATA-100 EIDE HDD
IBM 9.4GB DVD-RAM (black)
IBM IDE 48X-20X 4 CD-ROM (black)
IBM IDE 16X Max DVD-ROM (black)*
IBM IDE 12X/8X/32X CD-RW (black)
IBM 250MB Zip Drive (black)**
IBM NetVista USB-Parallel Printer Cable
IBM P76 Color Monitor (black)
ServicePac Warranty 3yr IOR 7x24x4
* requires MPEG-2 PCI decoder 33L5009
** requires 3.5" to 5.25" Bracket Kit 70G8165
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced April 24, 2001; others announced March 6, 2001
US models withdrawn from marketing effective November 2001 or December 2001
1 Memory Disk and rpm
2 EIDE value CD-ROM
40GB EIDE 7.2K
20GB EIDE value CD-ROM
20GB EIDE value CD-ROM
20GB EIDE value CD-ROM
40GB EIDE 7.2K
60GB EIDE 7.2K
4
CD-ROM (ATAPI), bootable
4 CD-RW(ATAPI), bootable
4
DVD (ATAPI), bootable
(RFID)
9" max length, 32-bit AGP 4X (universal) - used by graphic adapter
length, 32-bit PCI 2.2 (5v)
5.25", HH 1.6", access, standard CD-ROM or CD-RW
5.25", HH 1.6" access, open or DVD
3.5", SL 1", access, standard diskette
3.5", SL 1", no access, standard disk
20L0270
20L0271
20L0273
09N9890
10K3561
10K3782
22P6950
10K3785
00N8078
19K4164
655063N
41L2740
Graphics adapter
Optical
and memory
NVIDIA TNT2 32MB 4x4 10/100
CD-RW NVIDIA TNT2 32MB
CD-RW NVIDIA TNT2 32MB
NVIDIA TNT2 16MB
NVIDIA TNT2 16MB
NVIDIA TNT2 16MB
CD-RW NVIDIA TNT2 32MB
CD-RW NVIDIA TNT2 32MB
DVD / CD-RW NVIDIA TNT2 32MB
CD-RW NVIDIA TNT2 32MB
1 with 400MHz 1 Front Side Bus
3
SECURITY
U-bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied)
Power-on password
Administrator password
Boot sequence control
Boot without keyboard or mouse
Diskette boot inhibit and
write-protect
Disable mouse
Diskette, disk, serial port,
parallel port I/O control
No system keylock or
chassis intrusion detection
Slots x
Ethernet Preload
bays
Windows ® 2000 SmB Mar 2001
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
4x4 10/100 Windows Millennium
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
4x4 10/100 Windows 2000
Preload with Windows 2000 Professional
Microsoft Windows 2000 Professional
Windows 2000 Product Recovery CD
Windows NT 4.0 (SP6) Product Recovery CD
Disk-to-Disk Recovery (Windows 2000 or
Windows NT 4.0 SP6 in hidden service
partition)
Preload with Windows Millenium
Microsoft Windows Millenium
Windows Millenium Product Recovery CD
Disk-to-Disk Recovery (in hidden service
partition)
All models include
- Lotus SmartSuite Millennium License
®
- Lotus Notes Client License
Software Selections CD
Microsoft Office Small Business models
Microsoft Office 2000 Small Business (Word,
Excel, Outlook, Publisher,
Small Business Tools)
Microsoft Office Small Business CD
BIOS Setup Utility via F1 at startup
Boot Menu via F12 at startup
Product Recovery Pgm via F11 at startup
Adv Config Power Interface (ACPI) 1.0
LANClient Control Manager enabled
DMI 2.0-compliant
LIMITED WARRANTY*
3 year parts and labor limited warranty
International Warranty Service
On site, 8 am through 5 pm,
Mon through Fri excluding holidays,
next business day response time
3 year on site warranty service option:
• 4 hour response, 7 day x 24 hr
Post warranty maintenance
services available
24 hour x 7 day telephone, electronic, and
Internet support
No warranties are expressed or implied in this summary
(6833) IBM Corp. November 2001
Office Available
2000 date
SmB Mar 2001
SmB Mar 2001
Apr 2001
Apr 2001
Apr 2001
SmB Apr 2001
SmB Apr 2001
Apr 2001
Apr 2001
5
5
,9
9
7
7
