NetVista A60i (6848) - withdrawn
IBM
Type-model Processor GHz
6848-30U Pentium ® 4 1.4 128MB 45GB
6848-40U Pentium 4 1.5 128MB 75GB EIDE 7.2K CD-RW, DVD-ROM ATI
Intel processor Pentium 4 at 1.4 or 1.5GHz
L2 cache
256KB std and max / at processor speed
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA2) / motherboard contains one Intel PGA423 socket (with
Pentium 4 and heat sink), four RIMM sockets, five PCI slots, one AGP slot, integrated ethernet, and 850 chip w/ heat sink
SMP support No SMP support
Memory - std / max 128MB std / 2GB max / dual RDRAM (Rambus) channels / 32 devices max each channel /
Memory - features Two 4D 64MB PC600 RIMMs / non-parity / four 184-pin gold-plated RIMM sockets (two per channel) /
two RIMMs installed (one per channel) / CRIMMs in two sockets / supports PC600 or PC800 RIMMs (not PC700) /
mixing PC600 and PC800 RIMMs results in PC600 performance / all installed RIMMs must be installed in pairs across both
channels / supports optional ECC RIMMs (mixing non-parity and ECC RIMMs results in non-parity)
Graphics controller
(one of following)
IDE disk controller
Enhanced IDE busmaster / ATA-100 / two connectors on planar
Cables Two 2-drop EIDE cables
Disk - features 45 or 75GB EIDE / ATA-100 / 7200 rpm / S.M.A.R.T.
Rack support 4U
Architecture / chipsets Intel 850 chip set / MCH (Memory Controller Hub) / I/O Controller Hub (ICH2)
for PCI 2.2 bus, ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface /
Firmware Hub / SMC LPC47M102 Super I/O off LPC interface
100/10Mbps ethernet
Intel 82562EM / on planar / 10BaseT, 100BaseTX / full duplex / RJ-45 port /
LAN Connect Interface / controller in ICH2 and 82562EM /
support for Wake on LAN , Alert on LAN , Preboot eXecution Envir (PXE)
CD-RW 8X-4X-32X
DVD-ROM Some models: 40X-18X
Diskette drive
3.5" 1.44MB diskette drive
Audio Creative Labs
Speakers Altec Lansing IBM345 3-piece Speker System / 30 watts / 30Hz-18kHz
Data/fax modem Conexant
External ports Serial: Two 9 pin; Parallel: One (EPP, ECP) / IEEE 1284; USB: Four (Ver 1.1);
keyboard, mouse, audio line in, audio line out, microphone in
Systems mgmt
Monitoring and alerting of thermal, fans, and voltage faults
Keyboard IBM Rapid Access Keyboard III (USB)
Mouse
IBM ScrollPoint II mouse (3 button and scrolling button)
Cooling fans
Three variable speed fans (power supply, rear,
processor) / not redundant or hot-swap
Power supply 340 watts / universal / auto sensing
Preload with Windows Millennium Edition
Microsoft Windows Millennium Edition
- License for Lotus SmartSuite Millennium
- License for Lotus Notes
Device Drivers and Diagnostics CD-ROM
Software Selections CD-ROM
Windows Millennium Ed Product Recovery CD
Disk-to-Disk Recovery (Millennium Edition in
hidden service partition)
Options
64MB PC800 NP RDRAM RIMM (4 Dev)
128MB PC800 NP RDRAM RIMM (8 Dev)
256MB PC800 NP RDRAM RIMM (16 Dev)
IBM 4Ux20D Tower-to-Rack Kit
IBM 15GB ATA-66 EIDE HDD
IBM 40GB ATA-100 EIDE HDD
IBM 9.4GB DVD-RAM (black)
IBM IDE 16X Max 4 DVD-ROM (black)
IBM IDE 8X/4X/32X 4 CD-Rewritable (black)
IBM 250MB Zip Drive (black)
IBM NetVista USB-Parallel Printer Cable
IBM P76 Color Monitor (black)
IBM P96 Color Monitor (black)
All trademarks are the property of their respective owners
US models announced November 21, 2000
US models withdrawn from marketting effective May 2001
1
Memory Disk and rpm CD-RW and DVD
2 EIDE 7.2K CD-RW
1 with 400MHz Front Side Bus
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter / GeForce2 GPU / 32MB std and max 166MHz SDRAM /
one analog DB-15 connector and one DVI-D connector (single head; only one connector used at once) / S-Video out
ATI ALL-IN-WONDER RADEON (advanced 3D and multimedia) / AGP 4X adapter / 32MB std and max 166MHz
DDR-SGRAM / four connectors on rear of card: one DVI-I connector, one audio/video-out (S-Video or composite),
one CATV in, one audio/video-in (S-Video or composite)
17
rack mount support via tower-to-rack kit option
4 CD-ReWritable / bootable
4 DVD-ROM
® SoundBlaster Live! / PCI adapter
® HFC 56K 10 Data/Fax modem / PCI adapter
5
Slot 1: fullsize, AGP 4X Pro50 (1.5v) - used by std AGP graphics adapter
Slot 2: fullsize, 32-bit 33MHz, PCI 2.2 (5v) - used by modem
Slot 3: fullsize, 32-bit 33MHz, PCI 2.2 (5v) - used by sound card
® Client
Slot 4: fullsize, 32-bit 33MHz, PCI 2.2 (5v)
Slot 5: fullsize, 32-bit 33MHz, PCI 2.2 (5v)
Slot 6:
20L0270
20L0271
20L0273
09N4300
19K4460
09N0964
10K3561
10K3576
33L5020
00N8078
19K4164
655063N
655163N
Graphics adapter
NVIDIA GeForce2 MX Sound
® RADEON
3
Bay
Bay
Bay
Bay
Bay
Bay
Bay
fullsize, 32-bit 33MHz, PCI 2.2 (5v)
Metal cage for disk bays 5,6,7
rotates out of chassis
Two front stabilizing feet
Handle grip on top
H 18.5" x W 6.5" x D 20.0"
H 470mm x W 165mm x D 508mm
36 to 42 pounds (16.4 to 19.1kg)
Removable left side panel
BIOS Setup Utility via F2 at startup
Product Recovery Pgm via F11 at
startup
Adv Config Power Interface (ACPI) 1.0
LANClient Control Manager enabled
DMI 2.0-compliant
Sound Slots x
Card bays ethernet
6 x 7 10/100 Windows
Sound 6 x 7 10/100 Windows Me Dec 00
SECURITY
Cover key lock
Cover tamper detect switch
Secure fixed DASD
Power-on password
Administrator password
Keyboard/mouse password
Boot sequence control
Boot without keyboard or mouse
Diskette boot inhibit and write-protect
Disable mouse
Diskette, disk, serial port, parallel port
I/O control
Secure access openings
VPD stored in EEPROM
Write protection control for EEPROM
Barcode labels on most components
IBM Security Solutions
5.25", HH1.6", access, CD-ROM
5.25", HH1.6", access, open or DVD
3.5", SL 1", access, diskette
3.5", SL 1", access, open
3.5", SL 1", access, open
3.5", SL 1", access, open
3.5", SL 1", access, disk
LIMITED WARRANTY
3 year parts and labor limited
warranty
On site, 8 am through 5 pm,
Mon through Fri excluding holidays,
second business day response time
24 hour x 7 day telephone,
electronic, and Internet support
No warranties are expressed or implied in this summary
(6848)
Available
5
Preload date
® Me Dec 00
CD-RW
open
or DVD
diskette
disk
Mini-tower
Stealth black
9
IBM Corp. April 2001
