IBM NetVista A20 Reference Manual page 49

IBM
® NetVista A40p (6841) - withdrawn
TM
Name Type-model Color
A40p 6841-EAU White 6x7 Pentium
A40p 6841-GAU White 6x7 Pentium III 933/133
A40p 6841-E1U White 6x7 Pentium III 866/133
A40p 6841-G1U White 6x7 Pentium III 933/133
A40p 6841-TAU White 6x7 Pentium III 1GHz
A40p 6841-VAU White 6x7 Pentium III 1GHz
Processor Intel
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA) in PGA370
socket
256KB std and max / ECC / full speed
L2 cache
128MB std / 512MB max
Memory - std/max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered / 133MHz SDRAM
SVGA / Direct AGP / in 815E Graphics Memory Controller Hub (GMCH) /
Graphics - some
0MB std and max / 15-pin analog D-sub connector /
models
(DVMT) uses main memory with no display cache
Graphics - some NVIDIA
NVIDIA TNT2 M64 32MB AGP 4X adapter / 15-pin analog D-sub connector
Graphics - some
ATA-100, Value (30GB is 7200rpm), SMART
Disk
Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
Disk controller
3.5: 1.44MB diskette drive
Diskette drive
Accelerated Hub Architecture / 266MB/sec I/O channel
Architecture
Chip set Intel 815E / 82815 Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE, ethernet
MAC, USB, Low Pin Count Interface / 82802 Firmware Hub
USB/serial/parallel Four USB ports (Vers 1.1), two in back, two in front / two serial / one parallel
Audio Integrated digital audio / software-based audio (done by processor and ICH2) /
AC '97 interface / ADI1885 codec (analog mixing, Analog-to-Digital and
Digital-to-Analog conversion)
Audio connectors Line and headphone out / line in / microphone jack (all in back)
One internal speaker / requires externally powered speakers
Speaker
Ethernet controller Some models: 10/100 ethernet / controller in ICH2 and adapter in PCI/CNR slot
(Intel PRO/100 VE Desktop Connection adapter) / no Alert on LAN
Enhanced security A40p has a security chip (256-bit encryption) daughtercard attached to
motherboard which enables RFID antenna, C2 tamper switch, and
Alert on LAN 2 support with compatible adapter
104-key keyboard / IBM ScrollPoint
Keyboard / mouse
Power supply 200 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
® ®
Microsoft Windows 2000 Professional
- Lotus ® SmartSuite ® license
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (Windows NT
Windows 2000)
Software Selections CD-ROM
Options
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
256MB SDRAM 133MHz NP DIMM
Rapid Access TM Keyboard II (p wht) 33L3154
Rapid Access Keyboard II (black)
10.1GB IDE Hard Drive (Value)
15GB IDE Hard Drive (Value)
15GB IDE Hard Drive (7200 rpm)
20GB IDE Hard Drive (7200 rpm)
30GB IDE Hard Drive (7200 rpm)
Zip 100MB Internal Drive (white)
Zip 250MB Internal Drive
8/32X max DVD-ROM Internal (wht) 33L5015
8X/4X/32X CD-RW Internal (white)
8X/4X/32X CD-RW Internal (black)
48X-20X 4 IDE CD-ROM
IBM EtherJet 10/100 PCI Adapter
with Wake on LAN
IBM EtherJet 10/100 PCI Adapter
with Alert on LAN 2
Intel PRO V 100/E Ethernet Adapter 19K5710
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced June 5, 2001; others September 12, 2000 or December 12, 2000
US models withdrawn from marketing effective May 2001 or March 2002
Slotxbay Processor Speed
® III 866/133
1 /133 128MB 30GB 48X-20X 4X NVIDIA 32MB 10/100 815E Windows 2000
1
/133 256MB 30GB 48X-20X AGP 2X GMCH
® 1
Pentium III 866, 933MHz or 1GHz
TNT2 M64 16MB AGP 4X adapter / 15-pin analog D-sub connector
®
5
6
6
® 4.0 or
33L3071
33L3073
33L3075
33L3174
00N8202
19K4463
19K4460
19K4461
00N8203
20L0544
00N8078
33L5019
33L5020
33L5001
34L1201
34L1101
Memory Disk CD-ROM Graphics
128MB 20GB 2 48X-20X 4X NVIDIA 16MB 10/100 815E Windows 2000
128MB 30GB 48X-20X 4X NVIDIA 32MB 10/100 815E Windows 2000
0MB None None AGP 2X GMCH
0MB None None AGP 2X GMCH
1
with 133MHz Front Side Bus
3 III, SMART Reaction II
II mouse
Mini Tower
CD-ROM
diskette
disk
Mini tower
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Ethernet Chip Preload
None 815E None
None 815E None
10/100 815E Windows 2000
SYSTEMS MANAGEMENT
Universal Manageability Services (UM)
Desktop Extensions enabled
SMART Reaction II
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Wake on LAN
SECURITY
U-Bolt anchoring feature
Power-on password
Administator password
Boot sequence control
Diskette boot inhibit
Diskette write protect
Boot w/o keyboard or mouse
Diskette, hardfile, serial, and
parallel I/O control
Cover key lock
TM
Alert on LAN
adapter)
TM
Asset ID (RFID)
C2 tamper switch
6841 dimensions (6 slot x 7 bay)
- 6.5"W X 19.7"D X 16.7"H
- 165mmW X 500mmD X 424mmH
- 38.0 lb (maximum configuration)
Slot 1: fullsize, 32-bit AGP 4X (universal) - used in some
Slot 2: fullsize, 32-bit PCI 2.2 (5v) - ethernet in some*
Slot 3: fullsize, 32-bit PCI 2.2 (5v)
Slot 4: fullsize, 32-bit PCI 2.2 (5v)
Slot 5: fullsize, 32-bit PCI 2.2 (5v)
Slot 6: fullsize, 32-bit PCI 2.2 (5v)
* Longer connector has LAN Connect Interface (LCI)
Swinging door on Bay 1 to 4 (does not cover Bay 1)
Handle on top
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, open (disk only)
Bay 3.5", SL 1", no access, open (disk only)
Bay 3.5", SL 1", no access, std disk (disk only)
LIMITED WARRANTY*
3 year parts and labor warranty
International Warranty Service
On site, 8 am through 5 pm,
Mon through Fri excluding holidays,
next business day response time
3 year on site warranty service
upgrade options:
• 4 hour response, 7 day x 24 hr
Post warranty maintenance services
available
24 hour x 7 day telephone,
electronic, and Internet support
No warranties are expressed or implied in this summary
(6841)
Available
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Jan 2001
Jun 2001
2 (with supported
std CD-ROM
open
open
std diskette
,9
9
7
IBM Corp. March 2002
