IBM NetVista A20 Reference Manual page 47

IBM
® NetVista A40p (6579) - Fall 2000 - withdrawn
TM
Name Type-model Color
A40p 6579-RAU White 4x4
A40p 6579-RBU White 4x4
A40p 6579-R1U White 4x4
Processor Intel
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA)
in PGA370 socket
L2 cache 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM
Graphics - some SVGA / Direct AGP / in 815E Graphics Memory Controller Hub
models (GMCH) / 0MB std and max / (DVMT) uses main memory with no
display cache / 15-pin analog D-sub connector
Graphics - some nVidia TNT2 M64 32MB AGP 4X adapter / 15-pin analog D-sub
models connector
Disk ATA-66, SMART
Disk controller Enhanced IDE/ ATA-100 / integrated into I/O Controller Hub (ICH2)
Diskette drive 3.5: 1.44MB diskette drive
Some models: 48X-20X
CD-ROM
Motherboard MicroATX
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 815E
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100
EIDE, ethernet MAC, USB, Low Pin Count Interface /
82802 Firmware Hub
USB/serial/parallel Two USB ports (Version 1.1) on back / two serial / one parallel port
Audio Integrated digital audio / software-based audio (done
by processor and ICH2) / AC '97 interface / ADI1885 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Line and headphone out / line in / microphone jack (all in back / 3.5mm)
Speaker One internal speaker / requires externally powered speakers
Ethernet controller 6579 (Some models): 10/100 ethernet / controller in ICH2 and adapter in PCI/
CNR slot (Intel PRO/100 VE Desktop Connection adapter) / no Alert on LAN
Enhanced security A40p has a security chip (256-bit encryption) daughtercard attached to
motherboard which enables RFID antenna, C2 tamper switch, and
Alert on LAN 2 support with compatible adapter
Keyboard / mouse 104-key keyboard / IBM ScrollPoint
Power supply 6579: 155 watts with variable speed fan / universal / manual switch
6579 dimensions (4 slot x 4 bay)
- 16.7"W X 16.7"D X 5.5"H
- 425mmW X 425mmD X 140mmH
- 23 lb
Windows Millennium Preload
Microsoft Windows Millennium
- Lotus SmartSuite license
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Windows 2000 Preload
Microsoft ® Windows ® 2000 Professional
® ®
- Lotus SmartSuite
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (NT 4.0 or W2000)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 12, 2000; withdrawn effective September 2001
Slotxbay Processor MHz 1
Pentium ® III 933/133 128MB 30GB 48X-20X
Pentium III 933/133 128MB 30GB 48X-20X 4X nVidia 32MB 10/100 815E
Pentium III 933/133
® Pentium III 933MHz 1 with 133MHz Front Side Bus
3 III, SMART Reaction II / 30GB is 7200rpm
4
CD-ROM / bootable
8 / 82815 Graphics Memory Controller Hub (GMCH) /
Keylockable cover
RFID antenna
C2 tamper switch
U-Bolt anchoring feature
Power-on password
Administator password
9 Options
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
6
6 256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access
10.1GB IDE Hard Drive (Value)
5
15GB IDE Hard Drive (Value)
15GB IDE Hard Drive (7200 rpm)
20GB IDE Hard Drive (7200 rpm)
6
license
30GB IDE Hard Drive (7200 rpm)
6
48X-20X
Zip Drive 250MB
8X/4X/32X CD-RW Internal Drive
IBM Scrollpoint Pro Mouse (Sage)
IBM Scrollpoint Pro Mouse (Blue)
Memory Disk CD-ROM
4 4X nVidia 32MB 10/100 815E
0MB None None AGP 2X GMCH None
TM
II mouse
SECURITY
Boot sequence control
Diskette boot inhibit
Diskette write protect
Boot w/o keyboard or mouse
Diskette, hardfile, serial, and
parallel I/O control
TM Keyboard II (p wht) 33L3154
TM Keyboard II (black)
4 IDE CD-ROM
Graphics Ethernet Chip
815E
Desktop 6579
Slot 1: fullsize, 32-bit AGP 4X (universal) - used in some
Slot 2: fullsize, 32-bit PCI 2.2 (5v) with longer slot* - e**
Slot 3: fullsize, 32-bit PCI 2.2 (5v)
Slot 4: fullsize, 32-bit PCI 2.2 (5v) - ethernet
* Longer connector has LAN Connect Interface (LCI)
** ethernet adapter in some models
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
diskette
CD-ROM
disk
SYSTEMS MANAGEMENT
Universal Manageability Services (UM)
Desktop Extensions enabled
SMART Reaction II
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Wake on LAN
Alert on LAN
adapter)
Asset ID TM (RFID)
C2 tamper switch
LIMITED WARRANTY*
3 year parts and labor warranty
International Warranty Service
On site, 8 am through 5 pm,
33L3071
Mon through Fri excluding holidays,
33L3073
next business day response time
33L3075
On site warranty upgrade option:
33L3174
• 4 hour response
00N8202
Post warranty on site options:
19K4463
• Next day response
19K4460
• 4 hour response
19K4461
IBM SystemXtra
00N8203
33L5001
24 hour x 7 day telephone, electronic,
00N8078
and Internet support
33L5019
33L3246
33L3247
No warranties are expressed or implied in this summary
(6579F)
Preload Available
Win Millennium Sep 2000
Windows 2000 Sep 2000
None Sep 2000
CD-ROM
open
std diskette
Pearl white color
Bay 1 and 2 in
cage flips up
Bay 3 and 4 in
cage flips up
TM
2 (with supported
,9
9
7 , 7 day x 24 hr
7 , Mon-Fri 8-5
7
, 7 day x 24 hr
16
IBM Corp. September 2001
