IBM NetVista A20 Reference Manual page 44

IBM
® NetVista A40 (6830, 6840) - withdrawn
TM
Name Type-model Color
A40 6830-CAU Black
A40 6830-CBU Black
A40 6830-EAU Black
A40 6830-EBU Black
A40 6830-GBU Black
A40 6830-TAU Black
A40 6830-TCU Black
A40 6830-VAU Black
A40 6840-CAU White 6x7 Pentium III 800/133
A40 6840-EAU White 6x7 Pentium III 866/133
A40 6840-GAU White 6x7 Pentium III 933/133
A40 6840-C1U White 6x7 Pentium III 800/133
A40 6840-E1U White 6x7 Pentium III 866/133
A40 6840-G1U White 6x7 Pentium III 933/133
A40 6840-TAU White 6x7 Pentium III 1GHz/133 128MB 30GB 48X-20X 4X NVIDIA 32MB 10/100 815E Windows 2000
A40 6840-VAU White 6x7 Pentium III 1GHz/133 256MB 30GB 48X-20X AGP 2X GMCH
A40 6840-VBU White 6x7 Pentium III 1GHz/133 128MB 30GB 48X-20X AGP 2X GMCH
Intel
Processor
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA) in PGA370 socket
L2 cache 256KB std and max / ECC / full speed
64MB,128MB or 256MB std / 512MB max
Memory - std/max
Two 168-pin gold plated DIMM sockets / one socket used
Memory - sockets
SDRAM / non-parity only / industry std / unbuffered / 133MHz SDRAM
Memory - type
Graphics - some SVGA / Direct AGP / in 815E Graphics Memory Controller Hub (GMCH) /
0MB std and max / 15-pin analog D-sub connector /
models
(DVMT) uses main memory with no display cache
NVIDIA TNT2 M64 16MB AGP 4X adapter / 15-pin analog D-sub connector
Graphics - some
NVIDIA TNT2 M64 32MB AGP 4X adapter / 15-pin analog D-sub connector
Graphics - some
Disk ATA-100, Value, (30GB is 7200rpm), SMART
Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
Disk controller
Diskette drive 3.5" 1.44MB diskette drive
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 815E / 82815 Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE, ethernet MAC,
USB, Low Pin Count Interface / 82802 Firmware Hub
Four USB ports (Vers 1.1), two in back, two in front / two serial / one parallel
USB/serial/parallel
Audio Integrated digital audio / software-based audio (done
by processor and ICH2) / AC '97 interface / ADI1885 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Line and headphone out / line in / microphone jack (all in back)
Speaker One internal speaker / requires externally powered speakers
Some models: 10/100 ethernet / controller in ICH2 and adapter in PCI/CNR slot
Ethernet controller
(Intel PRO/100 VE Desktop Connection adapter) / no Alert on LAN
Enhanced security Does not have daughtercard that is standard in A40p
104-key keyboard / IBM 2-button mouse
Keyboard / mouse
6830: 155 watts; 6840: 200 watts; All : variable speed fan / universal / manual switch
Power supply
Slot 1: fullsize,
Micro Tower
Slot 2: three-quarter size, 32-bit PCI 2.2 (5v) with
Slot 3: three-quarter
CD-ROM
Slot 4: three-quarter size, 32-bit PCI 2.2 (5v)
* Longer connector has LAN Connect Interface (LCI)
diskette
Swinging door on Bay 1 to 2 (does not cover Bay 1)
Handle on top
Bay
Bay
disk
Bay
(vertical)
Bay
Preload with Windows Millennium
Microsoft Windows Millennium
- Lotus SmartSuite license
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
Microsoft ® Windows ® 2000 Professional
® ®
- Lotus SmartSuite license
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (Windows NT
Windows 2000)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced June 5, 2001; others September 12, 2000 or December 12, 2000
US models withdrawn effective March 2001 or May 2001 or March 2002
Slotxbay Processor Speed
®
4x4 Pentium III 800/133
4x4 Pentium III 800/133
4x4 Pentium III 866/133
4x4 Pentium III 866/133
4x4 Pentium III 933/133
4x4 Pentium III 1GHz 1 /133 128MB 20GB 48X-20X 4X NVIDIA 16MB 10/100 815E Windows 2000
4x4 Pentium III 1GHz/133 128MB 20GB None
4x4 Pentium III 1GHz/133 128MB 20GB 48X-20X AGP 2X GMCH
®
Pentium III 800EB, 866, 933MHz or 1GHz with 133MHz Front Side Bus
32-bit AGP 4X (universal) - used in some
longer slot* - ethernet in some
size, 32-bit PCI 2.2 (5v)
5.25", HH 1.6", access, CD-ROM
5.25", HH 1.6" access, open
3.5", SL 1", access, std diskette
3.5", SL 1", no access, std disk
5
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6 256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access Keyboard II (black)
15GB IDE Hard Drive (Value)
5
15GB IDE Hard Drive (7200 rpm)
20GB IDE Hard Drive (7200 rpm)
30GB IDE Hard Drive (7200 rpm)
6
Zip 250MB Internal Drive
6
8X/4X/32X CD-RW Internal (white)
® 4.0 or
8X/4X/32X CD-RW Internal (black)
48X-20X
48X-20X
Memory Disk CD-ROM Graphics
2
64MB 10GB None AGP 2X GMCH
128MB 20GB None AGP 2X GMCH
128MB 20GB None AGP 2X GMCH
128MB 20GB 48X-20X 4 4X NVIDIA 16MB None
128MB 20GB 48X-20X 4X NVIDIA 16MB 10/100 815E Windows 2000
AGP 2X GMCH
128MB 20GB 48X-20X AGP 2X GMCH
128MB 20GB 48X-20X 4X NVIDIA 16MB None
128MB 30GB 48X-20X 4X NVIDIA 32MB 10/100 815E Windows 2000
0MB None None AGP 2X GMCH
0MB None None AGP 2X GMCH
0MB None None AGP 2X GMCH
3
III, SMART Reaction II
Mini Tower
CD-ROM
diskette
disk
Mini tower
TM
Keyboard II (p wht) 33L3154
4 IDE CD-ROM (white)
4 IDE CD-ROM (black)
Personal Systems Reference (PSREF)
Ethernet Chip
None 815E Win Millennium Sep 2000
None 815E Windows 2000
None 815E Win Millennium Sep 2000
815E Windows 2000
10/100 815E Win Millennium Jan 2001
10/100 815E Windows 2000
None 815E Windows 2000
815E Windows 2000
None 815E None
None 815E None
None 815E None
10/100 815E Windows 2000
10/100 815E Windows 2000
SYSTEMS MANAGEMENT
SMART Reaction II
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Wake on LAN
SECURITY
U-Bolt anchoring feature
Power-on password
Administator password
Boot sequence control
Diskette boot inhibit
Diskette write protect
Boot w/o keyboard or mouse
Diskette, hardfile, serial, and
parallel I/O control
6830 dimensions (4 slot x 4 bay)
- 7.6"W X 15.0"D X 15.0"H
- 194mmW X 381mmD X 381mmH
- 22.5 lb (maximum configuration)
6840 dimensions (6 slot x 7 bay)
- 6.5"W X 19.7"D X 16.7"H
- 165mmW X 500mmD X 424mmH
- 38.0 lb (maximum configuration)
Slot 1: fullsize, 32-bit AGP 4X (universal) - used in some
Slot 2: fullsize, 32-bit PCI 2.2 (5v) - ethernet in some*
Slot 3: fullsize, 32-bit PCI 2.2 (5v)
Slot 4: fullsize, 32-bit PCI 2.2 (5v)
Slot 5: fullsize, 32-bit PCI 2.2 (5v)
Slot 6: fullsize, 32-bit PCI 2.2 (5v)
* Longer connector has LAN Connect Interface (LCI)
Swinging door on Bay 1 to 4 (does not cover Bay 1)
Handle on top
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, open (disk only)
Bay 3.5", SL 1", no access, open (disk only)
Bay 3.5", SL 1", no access, std disk (disk only)
LIMITED WARRANTY*
3 year parts and labor warranty
33L3071
International Warranty Service
33L3073
33L3075
On site, 8 am through 5 pm,
Mon through Fri excluding holidays,
33L3174
next business day response time
19K4463
3 year on site warranty service
19K4460
19K4461 upgrade options:
00N8203
• 4 hour response, 7 day x 24 hr
00N8078
Post warranty maintenance services
33L5019
available
33L5020
24 hour x 7 day telephone,
33L5001
electronic, and Internet support
10K3782
No warranties are expressed or implied in this summary
(6830)
Created by IBM PC Institute
Preload Available
Sep 2000
Sep 2000
Sep 2000
Jan 2001
Jun 2001
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Jan 2001
Jun 2001
Jun 2001
std CD-ROM
open
open
std diskette
,9
9
7
IBM Corp. March 2002
