IBM NetVista A20 Reference Manual page 42

IBM
® NetVista A40 (6648, 6578) - withdrawn
TM
Name Type-model Color
A40 6648-LAU Black
A40 6648-LBU Black
A40 6648-TCU Black
A40 6578-LAU White 4x4
A40 6578-LBU White 4x4
A40 6578-LCU White 4x4
A40 6578-LDU White 4x4
A40 6578-NAU White 4x4
A40 6578-NBU White 4x4
A40 6578-NCU White 4x4
A40 6578-NDU White 4x4
A40 6578-PAU White 4x4
A40 6578-PBU White 4x4
A40 6578-RAU White 4x4
A40 6578-RBU White 4x4
A40 6578-L1U White 4x4
A40 6578-N1U White 4x4
A40 6578-P1U White 4x4
Intel
Processor
with 133MHz Front Side Bus
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array
(FC-PGA) in PGA370 socket
L2 cache 256KB std and max / ECC / full speed
64MB, 128MB or 256MB std / 512MB max
Memory - std/max
Two 168-pin gold plated DIMM sockets / one socket used
Memory - sockets
SDRAM / non-parity only / industry std / unbuffered /
Memory - type
133MHz SDRAM
Graphics controller SVGA / Direct AGP / in 815E Graphics Memory Controller
Hub (GMCH) / 0MB std and max / 15-pin analog D-sub connector /
(DVMT) uses main memory with no display cache /
Disk ATA-66 or ATA-100, Value, SMART
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM Some models: 40X-17X
MicroATX
Motherboard
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Intel 815E / 82815 Graphics Memory Controller Hub (GMCH) /
Chip set
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100
EIDE, ethernet MAC, USB, Low Pin Count Interface /
82802 Firmware Hub
USB/serial/parallel Two USB ports (Version 1.1) on back / two serial / one parallel port
Audio Integrated digital audio / software-based audio (done
by processor and ICH2) / AC '97 interface / ADI1885 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Line and headphone out / line in / microphone jack (all in back)
Audio connectors
Speaker One internal speaker / requires externally powered speakers
Ethernet controller 6648: 10/100 ethernet / controller in ICH2 and Communications and Network Riser
(CNR) / Intel PRO/100 VE Desktop Connection riser / no Alert on LAN
6578 (Some models): 10/100 ethernet / controller ICH2 and adapter in
PCI/CNR slot (Intel PRO/100 VE Desktop Connection adapter) / no Alert on LAN
Enhanced security Does not have daughtercard that is standard in A40p
Keyboard / mouse 104-key keyboard / IBM 2-button mouse
Power supply 6648: 110 watts with variable speed fan / universal / manual switch
6578: 155 watts with variable speed fan / universal / manual switch
6648 dimensions (2 slot x 3 bay)
- 13.6"W X 14.9"D X 3.4"H
- 345mmW X 371mmD X 87mmH
- 20 lb
6578 dimensions (4 slot x 4 bay)
- 16.7"W X 16.7"D X 5.5"H
- 425mmW X 425mmD X 140mmH
- 23 lb
Preload with Windows 98
Microsoft Windows 98 Second Edition
- Lotus SmartSuite license
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
® ®
Microsoft Windows 2000 Professional
- Lotus ® SmartSuite ® license
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (Windows NT 4.0 or
Windows 2000)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US model announced June 5, 2001; others June 22, 2000
US models withdrawn effective March 2001 or May 2001 or March 2002
Slotxbay Processor Speed
®
2x3 Pentium III 733/133
2x3 Pentium III 733/133
2x3 Pentium III 1GHz 1 /133 256MB 20GB 40X-17X
Pentium III 733/133
Pentium III 733/133
Pentium III 733/133
Pentium III 733/133
Pentium III 800/133
Pentium III 800/133
Pentium III 800/133
Pentium III 800/133
Pentium III 866/133
Pentium III 866/133
Pentium III 933/133
Pentium III 933/133
Pentium III 733/133
Pentium III 800/133
Pentium III 866/133
® Pentium III 733, 800EB, 866, 933MHz
4
CD-ROM / bootable
U-Bolt anchoring feature
Power-on password
Administator password
5
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6 256MB SDRAM 133MHz NP DIMM
10.1GB IDE Hard Drive (Value)
15GB IDE Hard Drive (Value)
20GB IDE Hard Drive (7200 rpm)
5
30GB IDE Hard Drive (7200 rpm)
Zip Drive 250MB
8X/4X/24X Slimline CD-RW; black***
6
8X Max Slimline DVD-ROM; black***
6
24X-10X Slimline IDE CD-ROM; black*** 10K3780
8X/4X/32X CD-RW; pearl white****
48X-20X
*** for 6648 and 6649 only
**** not supported on 6648 or 6649
Memory Disk CD-ROM
2
64MB 10GB None AGP 2X GMCH 10/100 815E Windows 98 SE Jul 2000
64MB 10GB None AGP 2X GMCH 10/100 815E Windows 2000
4 AGP 2X GMCH 10/100 815E Windows 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 98 SE Jul 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 2000
64MB 10GB None AGP 2X GMCH None
64MB 10GB None AGP 2X GMCH None
64MB 20GB None AGP 2X GMCH None
64MB 20GB None AGP 2X GMCH None
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 98 SE Jul 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 98 SE Jul 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 98 SE Aug 2000
128MB 20GB 40X-17X AGP 2X GMCH 10/100 815E Windows 2000
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
1 or 1GHz 1
3 III, SMART Reaction II
SECURITY
Boot sequence control
Diskette boot inhibit
Diskette write protect
Boot w/o keyboard or mouse
Diskette, hardfile, serial, and
parallel I/O control
4 IDE CD-ROM; pearl white****
Personal Systems Reference (PSREF)
Graphics Ethernet Chip
815E Windows 98 SE Jul 2000
815E Windows 2000
815E Windows 98 SE Jul 2000
815E Windows 2000
815E None
815E None
815E None
Desktop 6648
Bay 5.25", 5/8", access,
Bay 3.5", SL 1" access,
Bay 3.5", SL 1", no access, std disk
Slot 1: half size, 32-bit PCI 2.2 (5v)
Slot 2: half size, 32-bit PCI 2.2 (5v)
- Slots on Communications and Network Riser (CNR)
inserted in LAN Connect Interface (LCI)
CD-ROM diskette
disk
Desktop 6578
Slot 1: fullsize, 32-bit AGP 4X (universal) - used in some
Slot 2: fullsize, 32-bit PCI 2.2 (5v) with longer slot* - e**
Slot 3: fullsize, 32-bit PCI 2.2 (5v)
Slot 4: fullsize, 32-bit PCI 2.2 (5v)
* Longer connector has LAN Connect Interface (LCI)
** ethernet adapter in some models
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
diskette
CD-ROM
disk
SYSTEMS MANAGEMENT
Universal Manageability Services (UM)
Desktop Extensions enabled
SMART Reaction II
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Wake on LAN
LIMITED WARRANTY*
3 year parts and labor warranty
International Warranty Service
33L3071
On site, 8 am through 5 pm,
33L3073
33L3075
Mon through Fri excluding holidays,
00N8202
next business day response time
19K4463
3 year on site warranty service
19K4461
upgrade options:
00N8203
• 4 hour response, 7 day x 24 hr
00N8078
10K3788
Post warranty maintenance services
10K3798
available
24 hour x 7 day telephone,
33L5019
electronic, and Internet support
33L5001
No warranties are expressed or implied in this summary
(6648)
Created by IBM PC Institute
Preload Available
Jul 2000
Jun 2001
Jul 2000
Jul 2000
Jul 2000
Jul 2000
Jul 2000
Aug 2000
Jul 2000
Jul 2000
Jul 2000
std or no CD-ROM
std diskette
Stealth black color
Floor stand included
Drive cage flips up
CD-ROM
open
std diskette
Pearl white color
Bay 1 and 2 in
cage flips up
Bay 3 and 4 in
cage flips up
,9
9
7
IBM Corp. March 2002
