® NetVista A40 for small business (6831) - withdrawn
TM
Name Type-model Color
A40 6831-EAU Black
A40 6831-GAU Black
A40 6831-GBU Black
A40 6831-TAU Black
A40 6831-VAU Black
A40 6831-VBU Black
Intel
Processor
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA) in PGA370 socket
256KB std and max / ECC / full speed
L2 cache
128MB or 256MB std / 512MB max
Memory - std/max Two 168-pin gold plated DIMM sockets / one socket used
Memory - sockets SDRAM / non-parity only / industry std / unbuffered / 133MHz SDRAM
Memory - type
SVGA / Direct AGP / in 815E Graphics Memory Controller Hub (GMCH) /
Graphics - some 0MB std and max / (DVMT) uses main memory with no display cache /
models 15-pin analog D-sub connector
NVIDIA TNT2 M64 16MB AGP 4X adapter / 15-pin analog D-sub connector
Graphics - some
models
ATA-100, Value (30 and 40GB is 7200 rpm), SMART
Disk Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
3.5: 1.44MB diskette drive
Disk controller
Diskette drive
Accelerated Hub Architecture / 266MB/sec I/O channel
Intel 815E / 82815 Graphics Memory Controller Hub (GMCH) /
Architecture
Chip set 82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE, ethernet
MAC, USB, Low Pin Count Interface / 82802 Firmware Hub
8X/4X/32X
11 Four USB ports (Vers 1.1), two in back, two in front / two serial / one parallel
CD-RW
USB/serial/parallel Integrated digital audio / software-based audio (done
Audio by processor and ICH2) / AC '97 interface / ADI1885 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Line and headphone out / line in / microphone jack (all in back)
Audio connectors One internal speaker / requires externally powered speakers
Speaker
Some models: 10/100 ethernet / controller in ICH2 and adapter in PCI/CNR slot
(Intel PRO/100 VE Desktop Connection adapter 19K5710) / no Alert on LAN
Ethernet controller
Some models: 56K V.90 PCI modem
Does not have daughtercard that is standard in A40p
Modem
Enhanced security
104-key keyboard / IBM ScrollPoint
155 watts with variable speed fan / universal / manual switch
Keyboard / mouse
Power supply
Windows Millennium Preload
Microsoft Windows Millennium Edition
Microsoft Office 2000 Small Business
is preinstalled (Word, Excel, Outlook,
Publisher, Small Business Tools)
- Lotus ® SmartSuite ®
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Windows 2000 Preload
® ®
Microsoft Windows 2000 Professional
Microsoft Office 2000 Small Business
is preinstalled
- Lotus ® SmartSuite ®
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (Windows 2000;
no option to convert to NT 4.0)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 12, 2000 and June 5, 2001
US models withdrawn from marketing effective May 2001 and November 2001
Slotxbay Processor Speed
®
4x4 Pentium III 866/133
4x4 Pentium III 933/133
4x4 Pentium III 933/133
4x4 Pentium III 1GHz/133 128MB 20GB CD-RW AGP 2X GMCH
4x4 Pentium III 1GHz/133 128MB 40GB CD-RW AGP 2X GMCH
4x4 Pentium III 1GHz/133 256MB 40GB CD-RW AGP 2X GMCH
® Pentium III 866MHz 1 , 933MHz, or 1GHz
4 CD-RW
5
license 6
6
5
license 6
Options
6
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access Keyboard II (black)
10.1GB IDE Hard Drive (Value)
15GB IDE Hard Drive (Value)
15GB IDE Hard Drive (7200 rpm)
20GB IDE Hard Drive (7200 rpm)
30GB IDE Hard Drive (7200 rpm)
Zip 250MB Internal Drive (white/blk) 00N8078
8X/4X/32X
48X-20X
IBM EtherJet 10/100 PCI Adapter
IBM EtherJet 10/100 PCI Adapter
Intel PRO/100 VE Desktop
Memory Disk CD-RW
2 4
128MB 20GB CD-RW AGP 2X GMCH
128MB 30GB CD-RW 4X NVIDIA 16MB 10/100
128MB 30GB CD-RW 4X NVIDIA 16MB 10/100
1 with 133MHz Front Side Bus
3
III, SMART Reaction II
®
II mouse
Micro Tower
CD-RW
diskette
disk
(vertical)
TM
Keyboard II (p wht) 33L3154
4 CD-RW Internal (black)
4
IDE CD-ROM (black)
with Wake on LAN
with Alert on LAN 2
Connection Ethernet Adapter
Modem or
Graphics ethernet Chip
Modem 815E
815E
815E
10/100 815E
10/100 815E
10/100 815E
SYSTEMS MANAGEMENT
Universal Manageability Services (UM)
Desktop Extensions enabled
SMART Reaction II
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Wake on LAN
U-Bolt anchoring feature
Power-on password
Administator password
Boot sequence control
Diskette boot inhibit
Diskette write protect
Boot w/o keyboard or mouse
Diskette, hardfile, serial, and
parallel I/O control
6831 dimensions (4 slot x 4 bay)
- 7.6"W X 15.0"D X 15.0"H
- 194mmW X 381mmD X 381mmH
- 22.5 lb (maximum configuration)
Slot 1: fullsize, 32-bit AGP 4X (universal) - used in some
Slot 2: three-quarter size, 32-bit PCI 2.2 (5v) with
longer slot* - ethernet in some
Slot 3: three-quarter size, 32-bit PCI 2.2 (5v)
Slot 4: three-quarter size, 32-bit PCI 2.2 (5v) - modem in
some
* Longer connector has LAN Connect Interface (LCI)
Swinging door on Bay 1 to 2 (does not cover Bay 1)
Handle on top
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
LIMITED WARRANTY*
33L3071
3 year parts / 1 year labor warranty
33L3073
International Warranty Service
33L3075
1st year: on site, 8 am - 5 pm,
Mon - Fri coverage,
33L3174
00N8202 2nd business day response time
19K4463
2nd/3rd year: parts exchange only,
19K4460
call 1-800-772-2227
19K4461
3 year on site warranty service
00N8203
upgrade options:
33L5020 • Next day response, Mon-Fri 8-5
10K3782
• 4 hour response, 7 day x 24 hr
Post warranty maintenance services
34L1201
available
24 hour x 7 day telephone, electronic,
34L1101
and Internet support
19K5710
No warranties are expressed or implied in this summary
(6831)
Preload Available
Win Millennium Sep 2000
Win Millennium Sep 2000
Windows 2000 Sep 2000
Win Millennium Jun 2001
Win Millennium Jun 2001
Windows 2000 Jun 2001
SECURITY
CD-RW
open
std diskette
,9
9
7
7
