® NetVista A40i (2251) - withdrawn
TM
Name Type-model Processor
A40i 2251-TAU Pentium
A40i 2251-TEU Pentium III 1GHz/133 128MB 30GB CD-RW None NVIDIA TNT2 M64 32MB 10/100 Modem
A40i 2251-VAU Pentium III 1GHz/133 128MB 30GB CD-RW DVD NVIDIA TNT2 M64 32MB 10/100 Modem
Processor Intel
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array (FC-PGA) in PGA370 socket
256KB std and max / ECC / full speed
L2 cache
128MB std / 512MB max
Memory - std/max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered / 133MHz SDRAM
ATI ALL-IN-WONDER
Graphics - some
32MB std and max 166MHz DDR-SGRAM / four connectors on rear of card: one DVI-I connector, one audio/video-out
models
(S-Video or composite), one CATV in (advanced TV tuner), one audio/video-in (S-Video or composite) / Dolby Digital
audio output / MPEG-2 decoder
NVIDIA
Graphics - some
models
Disk 30GB 7200 rpm, ATA-100, SMART
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
8X/4X/32X
CD-RW
DVD 12X/40X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 815E / 82815 Graphics Memory Controller Hub (GMCH) / 82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface / 82802 (or equivalent) Firmware Hub
Four USB ports (Vers 1.1), two in back, two in front / two serial / one parallel
USB/serial/parallel
Integrated digital audio / software-based audio (done by processor and ICH2) / AC '97 interface / ADI1885 codec
Audio
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Line and headphone out / line in / microphone jack (all in back)
Audio connectors
Speaker External active stereo speakers standard
10/100 ethernet / controller in ICH2 and adapter in PCI/CNR slot
Ethernet controller
(Intel PRO/100 VE Desktop adapter) / no Alert on LAN
56K V.90 PCI Adapter
Modem
Does not have daughtercard that is standard in A40p
Enhanced security
Keyboard / mouse IBM Rapid Access
155 watts with variable speed fan / universal / manual switch
Power supply
Bay
Micro Tower
Bay
2251
Bay
Bay
CD-RW
Slot 1: fullsize,
Slot 2: three-quarter size, 32-bit PCI 2.2 (5v) with longer slot* - used by ethernet adapter
Slot 3: three-quarter
diskette
Slot 4: three-quarter size, 32-bit PCI 2.2 (5v) - used by modem
* Longer connector has LAN Connect Interface (LCI)
Swinging door on Bay 1 to 2 (does not cover Bay 1)
Black color with handle on top
disk
Dimensions (4 slot x 4 bay)
(vertical)
- 7.6" W X 15.0" D X 15.0" H
- 194mm W X 381mm D X 381mm H
- 22.5 lb (maximum configuration)
OPTIONS
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
256MB SDRAM 133MHz NP DIMM
Rapid Access Keyboard II (black)
10.1GB IDE Hard Drive (Value)
15GB IDE Hard Drive (Value)
15GB IDE Hard Drive (7200 rpm)
20GB IDE Hard Drive (7200 rpm)
30GB IDE Hard Drive (7200 rpm)
Zip 250MB Internal Drive
HiFD 200MB Diskette Drive
4
8X/4X/32X CD-RW Internal (black)
4
16X max DVD-ROM Option Kit (blk) 10K3576
IBM TR5 10/20GB Int EIDE Tape
IBM EtherJet 10/100 PCI Adapter
with Wake on LAN
IBM EtherJet 10/100 PCI Adapter
with Alert on LAN 2
IBM EtherJet 10/100 PCI Secure
Mgmt Adapter
10/100 Etherlink PCI Mgmt
Adapter by 3COM
V.90 56K PCI Data/Fax Modem
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced June 5, 2000
US models withdrawn effective November 2001
Speed Memory Disk
® III 1GHz 1 /133 128MB 30GB 2
® 1
Pentium III 1GHz with 133MHz
TM RADEON (advanced 3D and multimedia) / AGP 4X adapter /
TM TNT2 M64 32MB SDRAM AGP 4X adapter / 1600x1200 at 72Hz / 15-pin analog D-sub connector
3
4 CD-RW
4
DVD-ROM
TM
II keyboard / IBM ScrollPoint
5.25", HH 1.6", access, std CD-RW
5.25", HH 1.6" access, open or std DVD
3.5", SL 1", access, std diskette
3.5", SL 1", no access, std disk
32-bit AGP 4X (universal) - used by graphics adapter
size, 32-bit PCI 2.2 (5v)
33L3071 U-Bolt anchoring feature
33L3073 Power-on password
33L3075 Administator password
33L3174 Boot sequence control
00N8202 Diskette boot inhibit
19K4463 Diskette write protect
19K4460 Boot w/o keyboard or mouse
19K4461 Diskette, hardfile, serial, and
00N8203 parallel I/O control
00N8078
20L0543
33L5020
SMART Reaction II
PC 99-compliant
20L0549
Advanced Power Management 1.2
Advanced Configuration and
34L1201
Power Interface (ACPI) 1.0a
System Management BIOS
34L1101
DMI 2.0-compliant
RPL and DHCP support
34L4401
Wake on LAN
09N3601
33L4618
CD-RW DVD Graphics
CD-RW DVD ATI RADEON 32MB
1
Front Side Bus
III, SMART Reaction II
®
II mouse
SECURITY
SYSTEMS MANAGEMENT
Ethernet Modem Slots/bays Preload
10/100 Modem 4x4 Millennium Jun 2001
4x4 Millennium Jun 2001
4x4 Millennium Jun 2001
9
PRELOAD
Microsoft Windows Millennium Edition
- Lotus SmartSuite license
®
- Lotus Notes Client 5.0 license
Recovery CD-ROM
Software Selections CD-ROM
LIMITED WARRANTY*
3 year parts / 1 year labor warranty
1st year: on site, 8 am - 5 pm,
Mon - Fri coverage,
2nd business day response time
2nd/3rd year: parts exchange only,
call 1-800-772-2227
3 year on site warranty upgrade
options available
Post warranty maintenance services
available
24 hour x 7 day telephone, electronic,
and Internet support
No warranties are expressed or implied in this summary
(2251) IBM Corp. October 2001
