IBM NetVista A20 Reference Manual page 4

IBM
® NetVista A20 (6269) - withdrawn
TM
Name Type-model Color
A20 6269-C1U White 3x4
A20 6269-C2U White 3x4
A20 6269-D1U White 3x4
A20 6269-D2U White 3x4
A20 6269-E1U White 3x4
A20 6269-E2U White 3x4
A20 6269-K1U White 3x4
A20 6269-K2U White 3x4
A20 6269-L1U White 3x4
A20 6269-L2U White 3x4
A20 6269-M1U White 3x4
A20 6269-M2U White 3x4
A20 6269-N1U White 3x4
A20 6269-N2U White 3x4
A20 6269-20U White 3x4
A20 6269-30U White 3x4
A20 6269-40U White 3x4
A20 6269-50U White 3x4
A20 6269-60U White 3x4
A20 6269-70U White 3x4
A20 6269-80U White 3x4
Processor Intel
Intel Pentium III 650 or 700MHz with 100MHz Front Side Bus or
Intel Pentium III 667 or 733MHz with 133MHz Front Side Bus
Implementation Processor and L2 cache in Flip-Chip Pin Grid Array
(FC-PGA) in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 64MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller AGP 2X-class graphics / Direct AGP / in 82810 Graphics
Memory Controller Hub (GMCH) /
0MB std and max display cache / Dynamic Video Memory
Technology (DVMT) uses main memory /
2D and 3D hardware acceleration / VESA DPMS, DDC1/DDC2B /
15-pin D-shell analog connector on back
Disk ATA-66, SMART
Disk controller Enhanced IDE/ ATA-66 / integrated into I/O Controller Hub (ICH)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM Some models: 40X-17X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E
82801 I/O Controller Hub (ICH) for PCI 2.2 bus, ATA-66 EIDE, USB, Low Pin
Count Interface / 82802 Firmware Hub /
Winbond 83627HF Super I/O for diskette, parallel, serial, keyboard, mouse
Back: One serial, one parallel, two USB (Version 1.1), keyboard, mouse
Ports
Audio Integrated digital audio / software-based audio (done by processor and
810E) / AC '97 interface / ADI 1881 codec (analog mixing, Analog-to-Digital
and Digital-to-Analog conversion)
Back: microphone jack, line-in, line-out, MIDI/game port
Audio connectors
Speakers None / requires powered speakers
Modem None standard
Ethernet controller 10/100 ethernet / Accton 32-bit PCI adapter / full duplex
Systems mgmt cntrl None / no support for monitoring of voltages or temperatures
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Windows 98 Preload
Microsoft Windows 98 Second Edition
- Lotus SmartSuite license
®
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
All trademarks are the property of their respective owners
Models announced June 22, 2000; withdrawn effective January 2001
Slot/bay Processor MHz 1
TM
Celeron 533/66
Celeron 533/66
Celeron 566/66
Celeron 566/66
Celeron 600/66
Celeron 600/66
®
Pentium III 650/100
Pentium III 650/100
Pentium III 700/100
Pentium III 700/100
Pentium III 667/133
Pentium III 667/133
Pentium III 733/133
Pentium III 733/133
Celeron 533/66
Celeron 566/66
Celeron 600/66
Pentium III 667/133
Pentium III 733/133
Pentium III 650/100
Pentium III 700/100
® TM
Celeron 533, 566, or 600MHz
128KB std and max / ECC / full speed
3
III
4 CD-ROM / bootable
8
chip set / 82810 Graphics Memory Controller Hub (GMCH) /
9
Options
64MB SDRAM 133MHz NP DIMM
6
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access
10.1GB IDE Hard Drive (Value)
15GB IDE Hard Drive (Value)
Zip Drive 250MB
8X/4X/32X CD-RW Internal Drive
48X-20X
8X DVD-ROM
10/100 Accton ethernet PCI adapter 19K4310
Memory Disk CD-ROM Graphics
2
64MB 10GB None AGP 2X GMCH None
4
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
64MB 10GB None AGP 2X GMCH None
64MB 10GB 40X-17X AGP 2X GMCH 10/100
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
0MB None None AGP 2X GMCH None
1
with 66MHz FSB or
TM Keyboard II (p wht) 33L3154
TM
Keyboard II (black)
4 IDE CD-ROM
Ethernet Chip
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
810E
Desktop 6269
Slot 1: 3/4-size (7.2"), 32-bit PCI 2.2 (5v) - ether in some
Slot 2: 3/4-size (7.2"), 32-bit PCI 2.2 (5v)
Slot 3: 3/4-size (10"), 32-bit PCI 2.2 (5v)
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
diskette
CD-ROM
disk
SECURITY
Knockout in rear for optional keylock
to lock cover to chassis
U-bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support
Dimensions
- 16.7"W X 16.7"D X 5.5"H
- 425mmW X 425mmD X 140mmH
- 23 lb
LIMITED WARRANTY
3 year parts / 1 year labor warranty
International Warranty Service
1st year: on site, 8 am - 5 pm,
33L3071
Mon - Fri coverage,
33L3073
2nd business day response time
33L3075
2nd/3rd year: parts exchange only,
33L3174
call 1-800-772-2227
00N8202
On site warranty upgrade options:
19K4463
• Next day response
00N8078
• 4 hour response
33L5019
33L5001 Post warranty: on site options above
33L5015
IBM SystemXtra
24 hour x 7 day telephone, electronic,
and Internet support
No warranties are expressed or implied in this summary
(6269)
Preload Avail
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
Windows 98 SE Jun 00
None Jun 00
None Jun 00
None Jun 00
None Jun 00
None Jun 00
None Jun 00
None Jun 00
std or opt CD-ROM
open
std diskette
Pearl white color
Bay 1 and 2 in
cage flips up
Bay 3 and 4 in
cage flips up
9
9
7
, Mon-Fri 8-5
7 , 7 day x 24 hr
,16
IBM Corp. January 2001
