IBM NetVista A20 Reference Manual page 39

IBM
® NetVista™ A30 (8315) - March 2003 - withdrawn
Slot x
Name Type-model bay
A30 8315-B4U 3x5 Celeron
A30 8315-B9U 3x5 Celeron
A30 8315-B5U 3x5 Celeron
A30 8315-B6U 3x5 Celeron
A30 8315-B7U 3x5 Celeron
A30 8315-B8U 3x5 Celeron
Great technology and affordable prices
Positioning
Intel
Processor
128KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
8 128MB std / 2GB max
Memory - std/max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
Memory - type PC2100 266MHz DDR-SDRAM / non-parity / industry std /
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845GL
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
40 or 80GB, ATA-100, 5400 or 7200 rpm
Disk
rubber vibration dampening mounts
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 48X/24X/48X Max
CD-RW
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845GL chipset / 82845GL Graphics Memory Controller
Chipset
Hub (GMCH) / 82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface /
Firmware Hub / LM86 temp sensor / LPC47M133 Super I/O for
diskette, parallel, serial, keyboard, mouse
Front ports Two USB (Version 2.0)
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
Some: external active speakers / Jazz Infinity / 2-piece / 6 watts / black color
Speakers
One internal beeper
Beeper
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Some: 56K
Modem
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional Edition
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector
Norton AntiVirus (OEM Version)
PC-Doctor
Veritas RecordNOW and DLA (CD-RW)
Downloadable (all)
Software Delivery Assistant
Software Migration Assistant
Remote Deployment Manager
IBM Director Agent (not XP Home)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced March 4, 2003
US models withdrawn effective August 2003
L2 FSB
Processor GHz cache MHz
® 2.0 128KB 400 128MB 80GB
2.0 128KB 400 128MB 40GB 5400 CD-ROM Extreme
2.1 128KB 400 128MB 40GB 7200 CD-ROM Extreme
2.1 128KB 400 128MB 40GB 7200 CD-ROM Extreme
2.2 128KB 400 128MB 40GB 7200 CD-ROM Extreme
2.2 128KB 400 128MB 40GB 7200 CD-ROM Extreme
®
Celeron 2.0. 2.1, or 2.2GHz with 400MHz frontside bus (FSB)
4 CD-ROM / bootable
4 CD-RW / bootable
10 V.90 data/fax soft modem / Conexant
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
120GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
15 IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM T860 18.1" Flat Panel Monitor (black) 9494HB0
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
Memory 8 and rpm Optical
2 7200 CD-RW
® 3.0 with SPX / software-based audio
® chipset / PCI adapter
4
DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
PCI External
Graphics modem speakers
Extreme Modem Speakers XP Home
Modem Speakers XP Home
Modem Speakers XP Home
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - used in
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3302
33L3304
33L3306
LIMITED WARRANTY
33L3308
09N4248
1 year parts and labor
09N4249
International Warranty Service
22P6950
On site, 8 am - 5 pm, Mon - Fri,
22P6997
2nd business day response time
On site service upgrade options
22P6973
(in eligible locations):
22P6959
• 1 year IOR 9x5, 4 hour response
22P6970
(ServicePac part number 54P1858)
09N4211
• 2 year IOR 9x5, Next Business Day
22P7099
(ServicePac part number 54P1859)
22P8998
• 2 year IOR 9x5, 4 hour response
(ServicePac part number 54P1860)
9512AB1
• 3 year IOR 9x5, Next Business Day
6656HG2
(ServicePac part number 54P1861)
• 3 year IOR 9x5, 4 hour response
(ServicePac part number 54P1862)
22P5170
14
24x7 toll-free support for warranty
33L3478
issues during the warranty period
06P3839
(8315M)
Created by IBM PC Institute
Workhorse Available
Preload or Entry date
5 No Mar 2003
XP Home Entry Mar 2003
No Mar 2003
XP Pro No Mar 2003
No Mar 2003
XP Pro No Mar 2003
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
some
SECURITY
1
9
7
1
IBM Corp. August 2003
