® NetVista™ A30 (8315) - August 2002 - withdrawn
Slot x
Name Type-model bay Processor
A30 8315-52U 3x5 Celeron
A30 8315-53U 3x5 Celeron
A30 8315-54U 3x5 Celeron
A30 8315-5BU 3x5 Celeron
A30 8315-5CU 3x5 Celeron
A30 8315-5DU 3x5 Celeron
A30 8315-B1U 3x5 Celeron
A30 8315-B2U 3x5 Celeron
A30 8315-61U 3x5 Pentium
A30 8315-62U 3x5 Pentium 4 1.8
A30 8315-24U 3x5 Pentium 4 2.0
A30 8315-39U 3x5 Pentium 4 2.2
A30 8315-91U 3x5 Pentium 4 2.6
Great technology and affordable prices
Positioning
Processor Intel
or Intel Pentium 4 at 1.8, 2.0, 2.2, or 2.6GHz with 400MHz FSB
Celeron:
L2 cache
Pentium 4: 512KB std and max / ECC / full speed
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
Memory - std/max 8 128MB std / 2GB max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
Memory - type PC2100 266MHz DDR-SDRAM / non-parity / industry std /
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845GL
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
20 or 40GB, ATA-100, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 40X/12X/40X Max
CD-RW
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845GL chipset / 82845GL Graphics Memory Controller
Chipset
Hub (GMCH) / 82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface /
Firmware Hub / LM86 temp sensor / LPC47M133 Super I/O for
diskette, parallel, serial, keyboard, mouse
Two USB (Version 2.0)
Front ports
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
Some: external active speakers / Jazz Infinity / 2-piece / 6 watts / black color
Speakers
Beeper One internal beeper
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Some: 56K
Modem
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional Edition
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Software Delivery Assistant
Veritas RecordNOW and DLA (CD-RW)
Downloadable (all)
IBM Rapid Restore PC
Remote Deployment Manager
IBM Director Agent (not XP Home)
Software Migration Assistant
15
Update Connector
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced August 27, 2002 or November 19, 2002
US models withdrawn effective December 2002, February 2003, May 2003, June 2003, or August 2003
L2 FSB
GHz cache MHz Memory
® 1.7 128KB 400 128MB 20GB
1.7 128KB 400 128MB 20GB Value CD-ROM Extreme GMCH
1.7 128KB 400 128MB 40GB Value CD-ROM Extreme GMCH
1.8 128KB 400 128MB 40GB 7200 CD-RW
1.8 128KB 400 128MB 20GB Value CD-ROM Extreme GMCH
1.8 128KB 400 128MB 20GB Value CD-ROM Extreme GMCH
2.0 128KB 400 128MB 40GB Value CD-ROM Extreme GMCH
2.0 128KB 400 128MB 40GB Value CD-ROM Extreme GMCH
®
4 1.8 512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
®
Celeron 1.7, 1.8, or 2.0GHz with 400MHz frontside bus (FSB)
128KB std and max / ECC / full speed
4 CD-ROM / bootable
4
CD-RW / bootable
10
V.90 data/fax soft modem / Conexant
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8 and rpm Optical
2 Value CD-ROM Extreme GMCH Modem Speakers XP Home
Extreme GMCH
® 3.0 with SPX / software-based audio
®
chipset / PCI adapter
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11 CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
PCI External
Graphics Modem Speakers
Modem Speakers XP Home Dec 2002
Modem Speakers XP Home Sep 2002
Modem Speakers XP Home Sep 2002
Modem Speakers XP Home Dec 2002
Modem Speakers XP Home Sep 2002
Modem
Modem
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - used in
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
33L3302
33L3304
1 year parts and labor
33L3306
International Warranty Service
33L3308
On site, 8 am - 5 pm, Mon - Fri,
09N4248
2nd business day response time
22P6950
On site service upgrade options
22P6997
(in eligible locations):
• 1 year IOR 9x5, 4 hour response
22P6973
(ServicePac part number 54P1858)
22P6959
• 2 year IOR 9x5, Next Business Day
22P6970
(ServicePac part number 54P1859)
09N4211
• 2 year IOR 9x5, 4 hour response
22P7099
(ServicePac part number 54P1860)
22P8998
• 3 year IOR 9x5, Next Business Day
(ServicePac part number 54P1861)
9512AB1
• 3 year IOR 9x5, 4 hour response
6656HG2
(ServicePac part number 54P1862)
14
24x7 toll-free support for warranty
22P5170
issues during the warranty period
33L3478
06P3839
(8315A)
Available
Preload date
5 Sep 2002
XP Pro Sep 2002
XP Pro Sep 2002
XP Pro Dec 2002
XP Pro Sep 2002
XP Home Sep 2002
XP Home Sep 2002
XP Pro Sep 2002
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
some
1
9
7
