IBM
® NetVista™ A30 (8315) - withdrawn
Slot x
Name Type-model bay
A30 8315-11U 3x5 Pentium
A30 8315-12U 3x5 Pentium 4
A30 8315-23U 3x5 Pentium 4
A30 8315-37U 3x5 Pentium 4
A30 8315-42U 3x5 Pentium 4
Great technology and affordable prices
Positioning
Intel
Processor
256 or 512KB std and max / ECC / full speed
L2 cache
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
128MB std / 1GB max
Memory - std/max 8
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845GL
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
40 or 80GB, ATA-100, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
48X/20X
CD-ROM
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845GL chipset / 82845G Graphics Memory Controller
Chipset
Hub (GMCH) / 82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface /
Firmware Hub / LM86 temp sensor / LPC47M133 Super I/O for
diskette, parallel, serial, keyboard, mouse
All:
Front ports
12U: microphone in (mono), headphone out (stereo) [all 3.5mm]
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal beeper
Beeper
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
Mouse IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional Edition
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Software Delivery Assistant
Downloadable (all)
IBM Rapid Restore PC
IBM Data Transfer
IBM Director Agent
Software Migration Assistant
Update Connector
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced June 4, 2002
US models withdrawn effective October 2002, December 2002, or August 2003
L2 FSB
Processor GHz cache MHz
® 4 1.8 256KB 400 128MB 40GB
1.8 256KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH
2.0 512KB 400 128MB 40GB Value CD-ROM Extreme GMCH
2.2 512KB 400 128MB 40GB Value CD-ROM Extreme GMCH
2.4 512KB 400 128MB 40GB Value CD-ROM Extreme GMCH
®
Pentium 4 at 1.8, 2.0, 2.2, 2.4GHz with 400MHz FSB
4 CD-ROM / bootable
two USB (Vers 2.0),
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)66274AN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
15
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
Memory 8 GB rpm Optical
2 Value CD-ROM Extreme GMCH
® 3.0 with SPX / software-based audio
4 DVD-ROM Drive (black)
4
CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Audio
Graphics front panel
Windows
Yes Windows XP Home Jun 2002
Windows XP Pro
Windows XP Pro
Windows XP Pro
Tower
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Stealth black color
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
33L3302
1 year parts and labor
33L3304
International Warranty Service
33L3306
On site, 8 am - 5 pm, Mon - Fri,
09N4248
22P6950 2nd business day response time
22P6997
On site service upgrade options
eligible locations)
10K3790
• 1 year 9x5 4 hour response
22P6959
(ServicePac part number 54P1858)
09N4211
22P8998 • 2 year 9x5 Next Business Day
(ServicePac part number 54P1859)
9512AB1
• 2 year 9x5 4 hour response
6656HG2
(ServicePac part number 54P1860)
• 3 year 9x5 Next Business Day
22P5170
33L3478 (ServicePac part number 54P1861)
• 3 year 9x5 4 hour response
06P3839
(ServicePac part number 54P1862)
24x7 14 toll-free support for warranty
issues during the warranty period
(8315)
Created by IBM PC Institute
Available
Preload date
® XP Pro 5 Jun 2002
Jun 2002
Jun 2002
Jun 2002
Optical
diskette
disk
(vertical)
std CD-ROM
open
open
std diskette
1
9
(in
7 :
1
IBM Corp. August 2003
