IBM
® NetVista™ A30 (8313) - withdrawn
Slot x
Name Type-model bay
A30 8313-52U 3x4 Celeron
A30 8313-53U 3x4 Celeron 1.7
A30 8313-55U 3x4 Celeron 1.7
A30 8313-5BU 3x4 Celeron 1.8
A30 8313-5CU 3x4 Celeron 1.8
A30 8313-B2U 3x4 Celeron 2.0
A30 8313-B3U 3x4 Celeron 2.0
A30 8313-B4U 3x4 Celeron 2.1
A30 8313-B5U 3x4 Celeron 2.1
A30 8313-B6U 3x4 Celeron 2.2
A30 8313-B7U 3x4 Celeron 2.2
Great technology and affordable prices
Positioning
Processor Intel
with 400MHz frontside bus (FSB)
L2 cache 128KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
8
Memory - std/max 128 or 256MB std / 2GB max
Memory - sockets Two 184-pin gold plated DIMM sockets / one socket used
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Graphics controller Integrated Intel Extreme Graphics / Direct AGP / in 845GL
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
40GB, ATA-100, 5400 rpm, rubber vibration dampening mounts
Disk
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 48X-20X
Cables Two EIDE 80-conductor cables (one 2-drop cable to optical,
one 1-drop cable to disk)
Chipset Intel 845GL chipset / 82845GL Graphics Memory Controller Hub
(GMCH) / 82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface /
Firmware Hub / LM86 temp sensor /
LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin),
Audio Integrated digital audio / SoundMAX
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Audio connectors Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Some: external active speakers / Jazz Infinity
Speaker
Beeper One internal beeper
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
(physical layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Modem Some: 56K
Keyboard 104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Mouse IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional Edition
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector
Norton AntiVirus (OEM Version)
PC-Doctor
Downloadable (all)
Remote Deployment Manager
Software Delivery Assistant
Software Migration Assistant
IBM Director Agent (not XP Home)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced on August 27 or November 19, 2002, or March 4, 2003
US models withdrawn effective May, June, or August 2003
L2 FSB
Processor GHz cache MHz Memory
® 1.7 128KB 400 128MB 40GB
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 256MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
128KB 400 128MB 40GB 5400 CD-ROM Extreme GMCH
® Celeron 1.7, 1.8, 2.0, 2.1 or 2.2GHz
4 CD-ROM / bootable
keyboard (PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
10 V.90 data/fax soft modem / Conexant
PCI adapter
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
15 IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8 and rpm Optical
2 5400 CD-ROM Extreme GMCH Modem Speakers XP Home
® 3.0 with SPX / software-based audio
® / 2-piece / 6 watts / black color
® chipset / soft HSFi modem /
4 DVD-ROM Drive (black)
4
CD-RW internal (blk)
11 CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
PCI External
Graphics modem speakers
Modem Speakers XP Home Sep 2002
Modem Speakers XP Home Dec 2002
Modem Speakers XP Home Mar 2003
Modem Speakers XP Home Mar 2003
Desktop
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: full-length, full-height, 32-bit PCI 2.2 (5v) - used in
Slot 2: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: full-length, full-height, 32-bit PCI 2.2 (5v)
Stealth black color
16.7" W X 16.3"D X 5.5"H
425mm W X 414mm D X 140mm H
22 to 25 lb (10.0 to 11.4 kg)
Bay 1 and 2 in cage flips up (latched and pivoting)
Bay 3 and 4 in cage flips up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal; toolless PCI slots
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
33L3302
3 year parts / 1 year labor
33L3304
International Warranty Service
33L3306
1st year: on site, 8 am - 5 pm,
33L3308
Mon - Fri coverage,
09N4248
2nd business day response time
22P6950
2nd/3rd year: parts exchange only,
22P6997
call 1-800-772-2227
On site service upgrade options (in
22P6973
eligible locations):
22P6959
• 3 year IOR 9x5, Next Business Day
22P6970
(ServicePac
09N4211
• 3 year IOR 9x5, 4 hour response
22P7099
(ServicePac part number 41L2732)
22P8998
• 3 year IOR 24x7, 4 hour response
(ServicePac part number 31L2724)
9512AB1
• 4 year IOR 9x5, Next Business Day
6656HG2
(ServicePac part number 69P9158)
• 4 year IOR 9x5, 4 hour response
(ServicePac part number 69P9159)
33L3478
• 4 year IOR 24x7, 4 hour response
(ServicePac part number 69P9160)
06P3839
14
24x7 toll-free support for warranty
issues during the warranty period
(8313)
Created by IBM PC Institute
Available
Preload date
5 Sep 2002
XP Pro Sep 2002
XP Pro Sep 2002
XP Pro Sep 2002
XP Pro Dec 2002
XP Pro Mar 2003
XP Pro Mar 2003
diskette
Optical
disk
std CD-ROM
open
std diskette
some
1
9
7
® part number 30L9199)
1
IBM Corp. August 2003
