NetVista™ A30p (8311) - March 2003 - withdrawn
Slot x
Name Type-model bay Processor
A30p 8311-4NU 4x5 Pentium
A30p 8311-4PU 4x5 Pentium 4 2.4
A30p 8311-8DU 4x5 Pentium 4 2.53 512KB 533 128MB 80GB 7200 CD-RW Extreme
A30p 8311-96U 4x5 Pentium 4 2.66 512KB 533 128MB 40GB 7200 CD-ROM Extreme
A30p 8311-D3U 4x5 Pentium 4 2.8
Great technology and affordable prices
Positioning
®
Intel
Processor
with 533MHz frontside bus (FSB)
512KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
128MB std / 2GB max
Memory - std/max 8
Memory - sockets Two 184-pin gold plated DIMM sockets / one socket used
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
40 or 80GB, ATA-100, 5400 or 7200 rpm,
Disk
rubber vibration dampening mounts
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Diskette drive 3.5" 1.44MB diskette drive
Some: 48X-20X
CD-ROM
Some: 48X/24X/48X Max
CD-RW
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop to disk)
Chipset Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
All: two USB (Version 2.0)
Front ports
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Speakers
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY (physical
Ethernet
layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 / PXE / Wake on LAN
Some: 56K
Modem
PCI adapter
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
Mouse
Three variable speed fans (power supply, fansink, rear fan)
Cooling fans
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector 15
Norton AntiVirus (OEM Version)
PC-Doctor
Veritas RecordNOW and DLA (CD-RW
models)
Downloadable (all)
System Migration Assistant
Software Delivery Assistant
Remote Deployment Manager
IBM Director Agent (not XP Home)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced March 4,2003
US models withdrawn effective August 2003
L2 FSB
GHz cache MHz Memory
® 4 2.4 512KB 533 128MB 40GB
512KB 533 128MB 40GB 5400 CD-ROM Extreme
512KB 533 128MB 40GB 7200 CD-ROM Extreme
Pentium 4 at 2.4, 2.53, 2.66, or 2.8GHz
4
CD-ROM
4 CD-RW
®
10 V.90 data/fax soft modem / Conexant
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
120GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM T860 18.1" Flat Panel Monitor (black) 9494HB0
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8
and rpm Optical Graphics
2 7200 CD-RW Extreme
3.0 with SPX / software-based audio
® chipset / soft HSFi modem /
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
PCI External
modem Speakers Preload
Modem Speakers XP Home
XP Home
Modem Speakers XP Home
Modem Speakers XP Home
Modem Speakers XP Home
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - some
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - modem
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3302
LIMITED WARRANTY
33L3304
33L3306
1 year parts and labor
33L3308
International Warranty Service
09N4248
On site, 8 am - 5 pm, Mon - Fri,
09N4249
2nd business day response time
22P6950
On site service upgrade options (in
22P6997
eligible locations):
• 1 year IOR 9x5, 4 hour response
22P6973
(ServicePac part number 54P1858)
22P6959
• 2 year IOR 9x5, Next Business Day
09N4211
(ServicePac part number 54P1859)
22P8998
• 2 year IOR 9x5, 4 hour response
(ServicePac part number 54P1860)
9512AB1
• 3 year IOR 9x5, Next Business Day
6656HG2
(ServicePac part number 54P1861)
• 3 year IOR 9x5, 4 hour response
(ServicePac part number 54P1862)
33L3478
24x7 14 toll-free support for warranty
issues during the warranty period
06P3839
(8311M)
Created by IBM PC Institute
Workhorse Available
or Entry date
5 No Mar 03
Entry Mar 03
No Mar 03
No Mar 03
No Mar 03
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
1
9
7
1
