NetVista™ A30p (8311) - August 2002 - withdrawn
Slot x
Name Type-model bay Processor
A30p 8311-61U 4x5 Pentium
A30p 8311-62U 4x5 Pentium 4 1.8
A30p 8311-2EU 4x5 Pentium 4 2.0
A30p 8311-4DU 4x5 Pentium 4 2.4
A30p 8311-83U 4x5 Pentium 4 2.53 512KB 533 128MB 80GB 7200 CD-RW MX 420 64MB out
A30p 8311-85U 4x5 Pentium 4 2.53 512KB 533 128MB 40GB 7200 CD-ROM Extreme GMCH
A30p 8311-92U 4x5 Pentium 4 2.66 512KB 533 128MB 80GB 7200 CD-RW MX 420 64MB out
A30p 8311-D1U 4x5 Pentium 4 2.8
A30p 8311-A1U 4x5 Pentium 4 3.06 512KB 533 256MB 80GB 7200 Combo
Great technology and affordable prices
Positioning
®
Intel
Processor
400 or 533MHz frontside bus (FSB) / no Hyper-Threading support
512KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
128 or 256MB std / 2GB max
Memory - std/max 8
Memory - sockets Two 184-pin gold plated DIMM sockets / one socket used
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
(one of following)
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
NVIDIA GeForce4 MX 420 / AGP 4X adapter / GeForce4 MX GPU /
64MB std and max 333MHz DDR-SDRAM / 350MHz RAMDAC /
two connectors: analog DB-15, S-Video out for TV-out
ATI Radeon 7000 / AGP 4X adapter /
Radeon GPU / 64MB std and max 332MHz DDR-SDRAM /
300MHz RAMDAC / one analog DB-15 connector
40 or 80GB, ATA-100, 7200 rpm, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 40X/12X/40X Max
CD-RW
A1U: 32X/10X/40X/16X Max
Combo
Cables Two EIDE 80-conductor cables (one 2-drop cable to optical, one 1-drop to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
All: two USB (Version 2.0)
Front ports
61U/83U/85U/D1U: microphone in (mono), headphone out (stereo)
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Speakers
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY (physical
layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 / PXE / Wake on LAN
10
56K
Modem
PCI adapter
Some: 104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Keyboard / mouse
Some: IBM Rapid Access IIIe Keyboard [RAK3] (USB / no USB hub or ports) /
Three variable speed fans (power supply, fansink, rear fan)
Cooling fans
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Software Delivery Assistant
Veritas RecordNOW and DLA (Combo and
CD-RW models)
Downloadable (all)
IBM Rapid Restore PC
Remote Deployment Manager
IBM Director Agent (not XP Home)
Software Migration Assistant
15
Update Connector
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced on August 27, 2002 or November 19, 2002
US models withdrawn effective May or August 2003
L2 FSB
GHz cache MHz Memory
® 4 1.8 512KB 400 128MB 40GB
512KB 400 128MB 80GB 7200 CD-RW Extreme GMCH
512KB 400 128MB 80GB 7200 CD-RW Extreme GMCH
512KB 533 128MB 80GB 7200 CD-RW MX 420 64MB out
512KB 533 256MB 80GB 7200 CD-RW Radeon 7000 64MB Modem RAK3
Pentium 4 at 1.8, 2.0, 2.4, 2.53, 2.66, 2.8, or 3.06GHz with
4
CD-ROM
4 CD-RW; 2EU: 48X/24X/48X Max
11 CD-RW/DVD-ROM Combo
®
V.90 data/fax soft modem / Conexant
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
IBM ScrollPoint III mouse (USB)
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8
and rpm Optical
2 7200 CD-ROM Extreme GMCH
MX 420 64MB out
4 CD-RW
3.0 with SPX / software-based audio
®
chipset / soft HSFi modem /
4 DVD-ROM Drive (black)
4
CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
PCI
Graphics Modem Keyboard
Modem
Modem
Modem
Modem RAK3
Modem RAK3
Modem
Modem RAK3
Modem RAK3
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - some
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - modem
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
33L3302
1 year parts and labor
33L3304
International Warranty Service
33L3306
On site, 8 am - 5 pm, Mon - Fri,
33L3308
2nd business day response time
09N4248
On site service upgrade options (in
22P6950
eligible locations):
22P6997
• 1 year IOR 9x5, 4 hour response
(ServicePac part number 54P1858)
22P6973
• 2 year IOR 9x5, Next Business Day
22P6959
(ServicePac part number 54P1859)
09N4211
• 2 year IOR 9x5, 4 hour response
22P8998
(ServicePac part number 54P1860)
• 3 year IOR 9x5, Next Business Day
9512AB1
(ServicePac part number 54P1861)
6656HG2
• 3 year IOR 9x5, 4 hour response
(ServicePac part number 54P1862)
33L3478
24x7 14 toll-free support for warranty
issues during the warranty period
06P3839
(8311A)
Created by IBM PC Institute
Available
Preload date
XP Home 5 Sep 02
XP Home Sep 02
XP Home Dec 02
XP Home Sep 02
XP Home Sep 02
XP Home Sep 02
XP Home Sep 02
XP Home Sep 02
XP Home Dec 02
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
1
9
7
1
