IBM NetVista A20 Reference Manual page 33

IBM
® NetVista™ A30p (8311) - withdrawn
Slot x
Name Type-model bay Processor
A30p 8311-13U 4x5 Pentium
A30p 8311-15U 4x5 Pentium 4 1.8
A30p 8311-29U 4x5 Pentium 4 2.0
A30p 8311-2CU 4x5 Pentium 4 2.0
A30p 8311-3DU 4x5 Pentium 4 2.26 512KB 533 128MB 80GB 7200 CD-RW MX 420 64MB out
A30p 8311-3GU 4x5 Pentium 4 2.26 512KB 533 128MB 40GB Value CD-ROM Extreme GMCH
A30p 8311-47U 4x5 Pentium 4 2.4
Great technology and affordable prices
Positioning
Intel
Processor
256 or 512KB std and max / ECC / full speed
L2 cache
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 8 128MB std / 1GB max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Graphics controller Integrated Intel Extreme Graphics / Direct AGP / in 845G
GMCH / uses main memory (up to 32MB with 128MB main memory;
(one of following)
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
NVIDIA GeForce4 MX 420 / AGP 4X adapter /
GeForce4 MX GPU / 64MB std and max 333MHz DDR-SDRAM /
350MHz RAMDAC / two connectors: analog DB-15,
S-Video out for TV-out
40 or 80GB, ATA-100, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
CD-ROM
Some: 40X/12X/40X Max
CD-RW
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
All:
Front ports
13U/15U: IEEE 1394 (4-pin)
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard (PS/2),
Rear ports
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Speakers
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
56K
Modem
PCI adapter
Some: FireWire PCI adapter / 1394A / 400Mbps / dual 6-pin ports on rear /
IEEE 1394 (FireWire)
Some: IBM Rapid Access IIIe Keyboard [RAK3] (USB / no USB hub or ports)
Keyboard
Some: 104-key IBM Preferred Pro Full-size keyboard
IBM ScrollPoint
Mouse
Three variable speed fans (power supply, fansink, rear fan)
Cooling fans
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Software Delivery Assistant
Veritas RecordNOW and DLA (CD-RW)
Downloadable (all)
IBM Rapid Restore PC
IBM Data Transfer
IBM Director Agent
Software Migration Assistant
Update Connector 15
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
Works Suite 2002 (Models 13U and 15U)
- Microsoft Works Suite 2002 (Word 2002,
Works 6.0, Encarta Encyclopedia Standard
2002, Money 2002 Standard, Picture It!
Photo 2002, Streets & Trips 2002
See footnotes for important warranty information
US models announced June 4, 2002
US models withdrawn effective October 2002, December 2002, May 2003, or August 2003
L2 FSB
GHz cache MHz Memory
® 4 1.8 256KB 400 128MB 80GB
256KB 400 128MB 40GB Value CD-ROM Extreme GMCH 1394
512KB 400 128MB 40GB Value CD-ROM Extreme GMCH
512KB 400 128MB 80GB 7200 CD-RW MX 420 64MB out
512KB 533 128MB 40GB Value CD-ROM Extreme GMCH
® Pentium 4 at 1.8, 2.0, 2.26, 2.4GHz with 400 or 533MHz FSB
4
CD-ROM / bootable
4 CD-RW /bootable
two USB (Vers 2.0), microphone in (mono), headphone out (stereo)
10 V.90 data/fax soft modem / Conexant
includes 4-pin port on front of system / no cables included
® III mouse (USB)
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)66274AN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8
GB rpm Optical
2 7200 CD-RW MX 420 64MB out 1394 RAK3 XP Home
® 3.0 with SPX / software-based audio
® chipset / soft HSFi modem /
4
DVD-ROM Drive (black)
4
CD-RW internal (blk)
11 CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
FireWire
Graphics Keyboard Preload
XP Home Works Jun 02
XP Home
RAK3 XP Home
RAK3 XP Home
XP Home
XP Home
Tower
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Stealth black color
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - some
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - modem
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - some
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3302
33L3304
LIMITED WARRANTY
33L3306
1 year parts and labor
09N4248
International Warranty Service
22P6950
22P6997
On site, 8 am - 5 pm, Mon - Fri,
2nd business day response time
10K3790
On site service upgrade options (in
22P6959
eligible locations)
09N4211
• 1 year 9x5 4 hour response
22P8998
(ServicePac part number 54P1858)
9512AB1
• 2 year 9x5 Next Business Day
6656HG2
(ServicePac part number 54P1859)
• 2 year 9x5 4 hour response
22P5170
(ServicePac part number 54P1860)
33L3478
• 3 year 9x5 Next Business Day
06P3839
(ServicePac part number 54P1861)
• 3 year 9x5 4 hour response
(ServicePac part number 54P1862)
24x7 14 toll-free support for warranty
issues during the warranty period
(8311)
Works Available
Suite date
5 Works Jun 02
Jun 02
Jun 02
Jun 02
Jun 02
Jun 02
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
1
9
7 :
1
IBM Corp. August 2003
