® NetVista™ A30p (8310) - Home (March 2003) - withdrawn
Slot x
Name Type-model bay
A30p 8310-95U 4x5 Pentium
A30p 8310-D4U 4x5 Pentium 4 2.8
A30p 8310-A2U 4x5 Pentium 4 3.06 512KB 533 256MB 120GB 7200 Combo
Positioning Great technology and affordable prices
Processor
Intel
frontside bus (FSB) / no Hyper-Threading technology support
L2 cache 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 256MB std / 2GB max
Memory - sockets
Two 184-pin gold plated DIMM sockets / one socket used
Memory - type PC2100 266MHz DDR-SDRAM / non-parity / industry std /
unbuffered / CAS Latency 2.5 (CL2.5)
Graphics controller NVIDIA
GeForce4 Ti GPU / 128MB std and max 444MHz DDR-SDRAM /
350MHz RAMDAC / three connectors: analog DB-15, digital DVI-D,
S-Video out for TV-out (but single head [not dual head])
Disk 80 or 120GB, ATA-100, 7200 rpm, rubber vibration dampening mounts
Disk controller
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Diskette drive 3.5" 1.44MB diskette drive
Optical
32X/10X/40X/16X Max
Cables Two EIDE 80-conductor cables (one 2-drop cable to optical,
one 1-drop to disk)
Chipset Intel 845G chipset / 82845G Graphics Memory Controller Hub
(GMCH) / 82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus,
ATA-100 EIDE, ethernet MAC, USB, Low Pin Count Interface / Firmware Hub /
LM86 temp sensor /
LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front ports
Two USB (Version 2.0),
microphone in (mono), headphone out (stereo),
IEEE 1394 (4-pin), Sony/Philips Digital Interface (S/PDIF) (optical),
two Type I or two Type II PCMCIA slots (lower left)
Rear ports
Four USB (Version 2.0), two 9-pin serial, parallel (25-pin),
keyboard (PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15),
two IEEE 1394 (6-pin)
Audio Integrated digital audio / SoundMAX
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Audio connectors
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Speakers
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
(physical layer) / Intel Pro/100 Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Modem 56K
IEEE 1394
Combination FireWire/PCMCIA PCI adapter / FireWire: 1394A, 400Mbps,
(FireWire) dual 6-pin ports on rear, 4-pin port on front of system, no cables included /
and PCMCIA two PCMCIA Type I or two Type II slots in front lower left of system
Keyboard IBM Rapid Access IIIe Keyboard [RAK3] (USB / no USB hub or ports)
Mouse
IBM ScrollPoint III mouse (USB)
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support
IBM Rapid Restore PC
Update Connector
Norton AntiVirus (OEM Version)
PC-Doctor
Veritas RecordNOW and DLA
Intervideo WinDVD player
Downloadable (all)
Software Migration Assistant
Remote Deployment Manager
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced March 4, 2003
US models withdrawn effective August 2003
L2 FSB
Processor GHz cache MHz
® 4 2.66 512KB 533 256MB 80GB
512KB 533 256MB 120GB 7200 Combo
®
Pentium 4 at 2.66, 2.8, 3.06GHz with 533MHz
® GeForce4 Ti 4200 / AGP 4X adapter /
11
CD-RW/DVD-ROM Combo
10
V.90 data/fax soft modem / Conexant
5
Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
15
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
Iomega Zip 750MB USB 2.0 Drive
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
Memory 8 and rpm Optical
2 7200 Combo
® 3.0 with SPX / software-based audio
®
chipset / PCI adapter
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
FireWire
Graphics Modem
Ti 4200 128MB out Modem 1394 Two XP Home
Ti 4200 128MB out Modem 1394 Two XP Home Mar 03
Ti 4200 128MB out Modem 1394 Two XP Home Mar 03
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - modem
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - used
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
3 year parts / 1 year labor
International Warranty Service
33L3302
1st year: on site, 8 am - 5 pm,
33L3304
Mon - Fri coverage,
33L3306
2nd business day response time
33L3308
2nd/3rd year: parts exchange only,
09N4248
call 1-800-772-2227
22P6950
On site service upgrade options (in
22P6997
eligible locations):
• 3 year IOR 9x5, Next Business Day
22P6973
(ServicePac
22P6959
• 3 year IOR 9x5, 4 hour response
22P6970
(ServicePac part number 41L2732)
09N4211
• 3 year IOR 24x7, 4 hour response
22P7099
(ServicePac part number 31L2724)
22P8998
• 4 year IOR 9x5, Next Business Day
(ServicePac
9512AB1
• 4 year IOR 9x5, 4 hour response
6656HG2
(ServicePac part number 69P9159)
• 4 year IOR 24x7, 4 hour response
(ServicePac part number 69P9160)
33L3478
24x7 14 toll-free support for warranty
issues during the warranty period
06P3839
(8310HM)
