IBM NetVista A20 Reference Manual page 30

IBM
®
NetVista™ A30p (8310) - Home - withdrawn
Slot x
Name Type-model bay Processor
A30p 8310-1BU 4x5 Pentium
A30p 8310-28U 4x5 Pentium 4 2.0
A30p 8310-37U 4x5 Pentium 4 2.26 512KB 533 128MB 80GB 7200 CD-RW MX 420 64MB out
A30p 8310-39U 4x5 Pentium 4 2.26 512KB 533 256MB 80GB 7200 Combo
A30p 8310-48U 4x5 Pentium 4 2.4
Great technology and affordable prices
Positioning
Intel
Processor
256 or 512KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
8 128 or 256MB std / 1GB max
Memory - std/max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
(one of following) GMCH / uses main memory (up to 32MB with 128MB main memory;
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
NVIDIA GeForce4 MX 420 / AGP 4X adapter /
GeForce4 MX GPU / 64MB std and max 333MHz DDR-SDRAM /
350MHz RAMDAC / two connectors: analog DB-15,
S-Video out for TV-out
NVIDIA
GeForce4 Ti GPU / 128MB std and max 444MHz DDR-SDRAM /
350MHz RAMDAC / three connectors: analog DB-15, digital DVI-D,
S-Video out for TV-out (but single head [not dual head])
40, 80, or 120GB, ATA-100, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
One of following: 40X/12X/40X Max
Optical
Two EIDE 80-conductor cables (one 2-drop cable to optical, one 1-drop to disk)
Cables
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
All:
Front ports
39U/48U: IEEE 1394 (4-pin), Sony/Philips Digital Interface (S/PDIF) (optical),
All:
Rear ports
39U/48U: two IEEE 1394 (6-pin)
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Speakers
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
56K
Modem
PCI adapter
Some: Combination FireWire/PCMCIA PCI adapter / FireWire: 1394A, 400Mbps,
IEEE 1394
(FireWire)
and PCMCIA
IBM Rapid Access IIIe Keyboard (USB / no USB hub or ports)
Keyboard
IBM ScrollPoint
Mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows XP Home
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
PC-Doctor
Software Delivery Assistant
Veritas RecordNOW and DLA (CD-RW)
Intervideo WinDVD player (DVD models)
Downloadable (all)
IBM Rapid Restore PC
IBM Data Transfer
IBM Director Agent
Software Migration Assistant
15
Update Connector
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced June 4, 2002
US models withdrawn effective October 2002, December 2002, May 2003, or August 2003
L2 FSB
GHz cache MHz Memory
® 4 1.8 256KB 400 128MB 40GB
512KB 400 128MB 40GB Value DVD
512KB 533 256MB 120GB 7200 Combo
®
Pentium 4 at 1.8, 2.0, 2.26, 2.4GHz with 400 or 533MHz FSB
®
GeForce4 Ti 4200 / AGP 4X adapter /
8X/4X/32X/8X Max
two USB (Vers 2.0), microphone in (mono), headphone out (stereo)
two Type I or two Type II PCMCIA slots (lower left)
four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
10 V.90 data/fax soft modem / Conexant
dual 6-pin ports on rear, 4-pin port on front of system, no cables included /
two PCMCIA Type I or two Type II slots in front lower left of system
® III mouse (USB)
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)66274AN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8
GB rpm Optical
2 Value DVD Extreme GMCH
Extreme GMCH
MX 420 64MB out
Ti 4200 128MB out Modem 1394 Two XP Home Jun 02
4 CD-RW, 16X/48X Max 4 DVD-ROM,
11 CD-RW/DVD-ROM Combo
®
3.0 with SPX / software-based audio
® chipset / soft HSFi modem /
4 DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
FireWire
Graphics Modem PCMCIA
Modem
Modem
Modem
Modem 1394 Two XP Home Jun 02
Tower
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Stealth black color
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - some
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - modem
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - some
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
3 year parts / 1 year labor
33L3302
International Warranty Service
33L3304
1st year: on site, 8 am - 5 pm,
33L3306
Mon - Fri coverage,
09N4248
2nd business day response time
22P6950
2nd/3rd year: parts exchange only,
22P6997
call 1-800-772-2227
10K3790
3 year on site warranty service
22P6959
upgrade options
09N4211
• Next day response, Mon-Fri 8-5
22P8998
(ServicePac
9512AB1
• 4 hour response, Mon-Fri 8-5
6656HG2
(ServicePac part number 41L2732)
• 4 hour response, 7 day x 24 hr
22P5170
(ServicePac part number 31L2724)
33L3478
24x7 14 toll-free support for warranty
06P3839
issues during the warranty period
(8310H)
Created by IBM PC Institute
Available
Preload date
XP Home 5 Jun 02
XP Home Jun 02
XP Home Jun 02
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
1
9
7 :
®
part number 30L9199)
1
IBM Corp. August 2003
