IBM NetVista A20 Reference Manual page 28

IBM
® NetVista™ A30p (8310) - August 2002 - withdrawn
Slot x
Name Type-model bay
A30p 8310-63U 4x5 Pentium
A30p 8310-3EU 4x5 Pentium 4 2.26 512KB 533 128MB 40GB 7200 CD-ROM Extreme GMCH
A30p 8310-4EU 4x5 Pentium 4 2.4
A30p 8310-81U 4x5 Pentium 4 2.53 512KB 533 256MB 120GB 7200 Combo
A30p 8310-65U 4x5 Pentium 4 1.8
Great technology and affordable prices
Positioning
Intel
Processor
with 400 or 533MHz frontside bus (FSB)
L2 cache 512KB std and max / ECC / full speed
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
8 128MB or 256MB std / 2GB max
Memory - std/max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
PC2100 266MHz DDR-SDRAM / non-parity / industry std /
Memory - type
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
(one of following)
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
ATI Radeon 7000 / AGP 4X adapter /
Radeon GPU / 64MB std and max 332MHz DDR-SDRAM /
300MHz RAMDAC / one analog DB-15 connector
40, 80, or 120GB, ATA-100, 7200 rpm,
Disk
rubber vibration dampening mounts
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
3.5" 1.44MB diskette drive
Diskette drive
Some: 48X-20X
Optical
Some: 48X/24X/48X Max
Some: 32X/10X/40X/16X Max
Two EIDE 80-conductor cables (one 2-drop cable to optical,
Cables
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin),
Audio Integrated digital audio / SoundMAX
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal beeper
Beeper
Ethernet 10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Some: IBM Embedded Security Subsystem 2.0
Security chip
Some:
Keyboard / mouse
Model 81U: IBM Rapid Access IIIe Keyboard [RAK3] (USB / no USB hub or
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
InterVideo WinDVD (Combo models)
Veritas RecordNOW and DLA (Combo and
CD-RW models)
Downloadable (all)
IBM Rapid Restore PC
Software Delivery Assistant
Software Migration Assistant
Remote Deployment Manager
IBM Director Agent
Update Connector
IBM Client Security Sft (security chip models)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced August 27, 2002 or November 19, 2002
US models withdrawn effective December 2002 or August 2003
L2 FSB
Processor GHz cache MHz Memory
® 4 1.8 512KB 400 128MB 40GB
512KB 533 128MB 80GB 7200 CD-RW
512KB 400 128MB 40GB 7200 CD-ROM Extreme GMCH Chip
®
Pentium 4 at 1.8, 2.26, 2.4, or 2.53GHz
4
CD-ROM
4 CD-RW
11
CD-RW/DVD-ROM Combo
keyboard (PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
multi-factor authentication / local file encryption /
16
enhances VPN security / TCPA-compliant
104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 conn)
IBM Std 2-Button PS/2 Mouse (6-pin PS/2 connector)
ports) / IBM ScrollPoint III mouse (USB)
5 Options
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
1GB PC2100 CL2.5 NP DDR UDIMM
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
32X/10X/40X/16X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Multi-Burner internal (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)6627KAN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
15
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (black) 22P5170
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8 and rpm Optical
2 7200 CD-ROM Extreme GMCH
®
3.0 with SPX / software-based audio
18 / hardware key storage /
4
DVD-ROM Drive (black)
4
CD-RW internal (blk)
11 CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Security
Graphics chip Keyboard
Pro
Pro
Extreme GMCH Pro
Radeon 7000 RAK3 XP Pro
Pro
Tower
Stealth black color
7.5" W X 16.0"D X 16.3"H
191mm W X 406mm D X 413mm H
20.0 to 25.0 lb (9.1 to 10.2 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v) some
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
SMBIOS 2.3.1-compliant
DMI 2.0-compliant
Security chip models: Asset ID
(system-specific info in chip)
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Security chip models: security chip
providing C2 tamper switch, Asset ID
keylock on chassis, and other features
LIMITED WARRANTY
3 year parts / 1 year labor
33L3302 International Warranty Service
33L3304
1st year: on site, 8 am - 5 pm,
33L3306
Mon - Fri coverage,
33L3308
2nd business day response time
09N4248
2nd/3rd year: parts exchange only,
22P6950
call 1-800-772-2227
22P6997 On site service upgrade options (in
eligible locations):
22P6973
• 3 year IOR 9x5, Next Business Day
22P6959
(ServicePac
22P6970
• 3 year IOR 9x5, 4 hour response
09N4211
(ServicePac part number 41L2732)
22P8998
• 3 year IOR 24x7, 4 hour response
(ServicePac part number 31L2724)
9512AB1
• 4 year IOR 9x5, Next Business Day
6656HG2 (ServicePac
• 4 year IOR 9x5, 4 hour response
(ServicePac part number 69P9159)
33L3478
• 4 year IOR 24x7, 4 hour response
(ServicePac part number 69P9160)
06P3839
14
24x7 toll-free support for warranty
issues during the warranty period
(8310A)
Created by IBM PC Institute
Workhorse Available
Preload or Global date
XP Pro 5 No Sep 02
XP Pro No Sep 02
XP Pro No Dec02
No Sep 02
XP Pro No Sep 02
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
in
,19
SECURITY
19
,
1
9
7
®
part number 30L9199)
® part number 69P9158)
1
IBM Corp. August 2003
