® NetVista™ A30p (8310)
Slot x
Name Type-model bay
A30p 8310-14U 4x5 Pentium
A30p 8310-1AU 4x5 Pentium 4 1.8
A30p 8310-26U 4x5 Pentium 4 2.0
A30p 8310-27U 4x5 Pentium 4 2.0
A30p 8310-36U 4x5 Pentium 4 2.26 512KB 533 128MB 80GB 7200 CD-RW
A30p 8310-38U 4x5 Pentium 4 2.26 512KB 533 256MB 80GB 7200 Combo
A30p 8310-47U 4x5 Pentium 4 2.4
A30p 8310-29U 4x5 Pentium 4 2.0
A30p 8310-3AU 4x5 Pentium 4 2.26 512KB 533 128MB 40GB Value CD-ROM
Great technology and affordable prices
Positioning
Processor Intel
256 or 512KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
Memory - std/max 8 128MB or 256MB std / 1GB max
Two 184-pin gold plated DIMM sockets / one socket used
Memory - sockets
Memory - type PC2100 266MHz DDR-SDRAM / non-parity / industry std /
unbuffered / CAS Latency 2.5 (CL2.5)
Integrated Intel Extreme Graphics / Direct AGP / in 845G
Graphics controller
GMCH / uses main memory (up to 32MB with 128MB main memory;
(one of following)
up to 64MB with 256MB+) / DVMT / 15-pin analog D-sub connector
ATI Radeon 7000 / AGP 4X adapter /
Radeon GPU / 64MB std and max 332MHz DDR-SDRAM /
300MHz RAMDAC / one analog DB-15 connector
NVIDIA
GeForce4 Ti GPU / 128MB std and max 444MHz DDR-SDRAM /
350MHz RAMDAC / three connectors: analog DB-15, digital DVI-D,
S-Video out for TV-out (but single head [not dual head])
40, 80, or 120GB, ATA-100, rubber vibration dampening mounts
Disk
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH4)
Disk controller
3.5" 1.44MB diskette drive
Diskette drive
One of following: 48X-20X
Optical
8X/4X/32X/8X Max
Cables Two EIDE 80-conductor cables (one 2-drop cable to optical,
one 1-drop cable to disk)
Intel 845G chipset / 82845G Graphics Memory Controller Hub (GMCH) /
Chipset
82801DB I/O Controller Hub (ICH4) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / Firmware Hub / LM86 temp
sensor / LPC47M133 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 2.0)
Ports
Back: four USB (Version 2.0), two 9-pin serial, parallel (25-pin), keyboard
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH4) / AC '97 interface / ADI1981A codec
Back: microphone-in (mono), line-in (stereo), line-out (stereo) [all 3.5mm]
Audio connectors
One internal beeper
Beeper
10/100 ethernet on planar / ICH4 (MAC layer) with Intel 82562EX PHY
Ethernet
(physical layer) / Intel Pro/100VE Network Connection / 32-bit PCI 2.2 /
supports PXE and Wake on LAN
Some: IBM Embedded Security Subsystem 2.0
Security chip
104-key IBM Preferred Pro Full-size keyboard / IBM Std 2-Button PS/2 Mouse
Keyboard / mouse
Three variable speed fans (power supply, fansink, rear fan)
Cooling fans
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
- Disk-to-Disk Recovery (in Service Partition)
Preload with Windows XP Professional
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service Partition)
Preloaded (all)
Access IBM
Access Support Connected Client
Norton AntiVirus (OEM Version)
InterVideo WinDVD (DVD models)
Veritas RecordNOW and DLA (CD-RW)
Downloadable (all)
IBM Rapid Restore PC
IBM Data Transfer
IBM Director Agent
IBM Client Security Sft (security chip models)
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand-alone Client
See footnotes for important warranty information
US models announced June 4, 2002
US models withdrawn effective October 2002, December 2002, or August 2003
L2 FSB
Processor GHz cache MHz
® 4 1.8 256KB 400 128MB 40GB Value CD-ROM
256KB 400 128MB 40GB Value CD-ROM
512KB 400 128MB 40GB Value CD-ROM
512KB 400 128MB 40GB Value CD-ROM
512KB 533 256MB 120GB 7200 Combo
512KB 400 128MB 40GB 7200 CD-ROM
®
Pentium 4 at 1.8, 2.0, 2.26, 2.4GHz with 400 or 533MHz FSB
® GeForce4 Ti 4200 / AGP 4X adapter /
4 CD-ROM, 40X/12X/40X Max
11 CD-RW/DVD-ROM Combo
(PS/2), mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
multi-factor authentication / local file encryption /
enhances VPN security 16
Options
5
128MB PC2100 CL2.5 NP DDR UDIMM
256MB PC2100 CL2.5 NP DDR UDIMM
512MB PC2100 CL2.5 NP DDR UDIMM
5
80GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
48X/24X/48X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM Portable USB 2.0 20GB Hard Disk
IBM 128MB USB 2.0 Memory Key
IBM G78 17" (16.0" viewable) Monitor (blk)66274AN
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM P97 17" (18.0" viewable) Monitor (blk) 6651U3N
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM High Rate Wireless LAN PCI Adapter 22P6901
Kensington MicroSaver Desktop Lock
Other options at ibm.com/pc/us/accessories
EIDE disk
8 2
Memory GB rpm Optical
4 CD-RW,
® 3.0 with SPX / software-based audio
18 / hardware key storage /
/ TCPA-compliant
4
DVD-ROM Drive (black)
4 CD-RW internal (blk)
11
CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Security
Graphics chip Ethernet
Extreme GMCH 10/100
Extreme GMCH 10/100
Extreme GMCH 10/100
Extreme GMCH 10/100
Radeon 7000 64MB 10/100
Radeon 7000 64MB 10/100
Ti 4200 128MB out 10/100
Extreme GMCH Chip 10/100
Extreme GMCH Chip 10/100
Tower
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Stealth black color
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v) some
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Security chip models: Asset ID
(system-specific info in chip)
SECURITY
U bolt anchoring feature (U-bolt is
optional; supports optional padlock)
Security slot (for attachment of optional
cable lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
Security chip models: security chip
providing C2 tamper switch, Asset ID
keylock on chassis, and other features
LIMITED WARRANTY
33L3302
3 year parts / 1 year labor
33L3304
International Warranty Service
33L3306
1st year: on site, 8 am - 5 pm,
09N4248
22P6950 Mon - Fri coverage,
22P6997
2nd business day response time
2nd/3rd year: parts exchange only,
10K3790
call 1-800-772-2227
22P6959
3 year on site warranty service
09N4211
22P8998 upgrade options:
• Next day response, Mon-Fri 8-5
9512AB1
(ServicePac
6656HG2
• 4 hour response, Mon-Fri 8-5
(ServicePac part number 41L2732)
22P5170
33L3478 • 4 hour response, 7 day x 24 hr
(ServicePac part number 31L2724)
31P6763
24x7 14 toll-free support for warranty
issues during the warranty period
(8310)
Created by IBM PC Institute
Available
Preload date
XP Pro 5 Jun 02
2000 Jun 02
XP Pro Jun 02
2000 Jun 02
XP Pro Jun 02
XP Pro Jun 02
XP Pro Jun 02
XP Pro Jun 02
XP Pro Jun 02
Optical
diskette
disk
(vertical)
std optical
open
open
std diskette
in
,19
19 ,
1
9
7
® part number 30L9199)
1
IBM Corp. August 2003
