IBM
® NetVista A22p for small business (6825) - withdrawn
TM
Slotx
bay
Type-model Processor
6825-11U 4x5 Pentium
6825-12U 4x5 Pentium 4
6825-21U 4x5 Pentium 4
6825-22U 4x5 Pentium 4
6825-24U 4x5 Pentium 4
6825-31U 4x5 Pentium 4
6825-32U 4x5 Pentium 4
Positioning Leading edge technologies and affordable prices;
small business software models
Processor Intel
L2 cache 256KB or 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 128MB or 256MB std / 1.5GB max
Memory - sockets Three 168-pin gold plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2) / supports optional ECC
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
(one of the following) TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
Disk
ATA-100, SMART
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Disk controller
Diskette drive 3.5" 1.44MB diskette drive
Some models 16X/10X/40X Max
CD-RW
Some models: 8X/4X/32X/8X Max
CD-RW/DVD combo
Two EIDE 80-conductor cables (one 2-drop cable to CD,
Cables
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 1.1)
Ports
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Back: microphone jack, line-in, line-out
Audio connectors
One internal speaker for business audio
Speakers
10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
Ethernet
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
None
Security chip
106-key (rubber dome) keyboard / IBM 2-button mouse
Keyboard / mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Preload with Windows XP Home
Microsoft Windows XP Home Edition
Preload with Windows XP Professional
Microsoft Windows XP Professional
All models
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
- Microsoft Office XP Small Business
(Word, Excel, Outlook, Publisher, Small
Business Tools)
Office XP Small Business CD-ROM
See footnotes for important warranty information
US models announced January 22, 2002; previous models on September 18, 2001
US models withdrawn effective March, July, or August 2002
GHz L2 cache Mem
® 4 1.6GHz 256KB 128MB 40GB
1.6GHz 256KB 128MB 20GB Value CD-RW NVIDIA 16MB
1.8GHz 256KB 128MB 40GB 7200 Combo GeForce2 32MB Windows 2000
1.8GHz 256KB 128MB 40GB Value CD-RW NVIDIA 16MB
1.8GHz 256KB 256MB 40GB 7200 CD-RW GeForce2 32MB Windows XP Pro
2.0GHz 256KB 128MB 80GB 7200 Combo GeForce2 32MB Windows XP Pro
2.0GHz 512KB 128MB 80GB 7200 Combo GeForce2 32MB Windows XP Pro
® Pentium 4 at 1.6, 1.8, 2.0GHz with 400MHz frontside bus
3
III
4 CD-RW / ATAPI / bootable
11
ethernet, monitor
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
128MB SDRAM 133MHz CL2 NP DIMM
5 256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
2-Piece Speakers (black)
3-Piece Speakers (black)
5
40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
4
IBM 16X
40X/12X/40X Max
6
8X/4X/32X/8X Max
6
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
28
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 33L3250
Other options at ibm.com/pc/us/accessories
Optical
Disk RPM Graphics
2 Value CD-RW NVIDIA 16MB Windows
Micro Tower
Bay
Bay
Bay
Bay
Bay
Slot 1:
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
CD-RW/DVD-ROM Combo
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
®
3.0 with SPX / software-based audio
max DVD-ROM Drive (black)
4
CD-RW internal (blk)
11
CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Small Business
Preload
® XP Home 5 XP Office SB
Windows XP Home XP Office SB Oct 2001
XP Office SB Oct 2001
Windows XP Home XP Office SB Oct 2001
XP Office SB Feb 2002
XP Office SB Oct 2001
XP Office SB Feb 2002
Stealth black color
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
5.25", HH 1.6", access,
5.25", HH 1.6" access,
3.5", SL 1", access,
3.5", SL 1", access,
3.5", SL 1", no access, std disk
3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
10K0055
3 year parts / 1 year labor
10K0057
10K0059
International Warranty Service
10K0061
registration available
33L3440
1st year: on site, 8 am - 5 pm,
33L3441
Mon - Fri coverage,
22P7156
2nd business day response time
09N4207
22P6950
2nd/3rd year: parts exchange only,
22P6976
call 1-800-772-2227
3 year on site warranty service
10K3790
upgrade options
22P6959
• Next day response, Mon-Fri 8-5
00N8078
(ServicePac ®
9511AG4
• 4 hour response, Mon-Fri 8-5
6656HG2
(ServicePac part number 41L2732)
651767N
• 4 hour response, 7 day x 24 hr
22P5170
(ServicePac part number 31L2724)
33L3478
14
24x7 toll-free support for warranty
issues during the warranty period
(6825)
Software Available
28 Oct 2001
Optical
diskette
disk
(vertical)
std optical drive
open
open
std diskette
1
9
7 :
part number 30L9199)
1
IBM Corp. August 2002
