IBM
® NetVista™ A22p (2292) - withdrawn
Slots x
Name Type-model bays
A22p 2292-13U 4x5 Pentium
A22p 2292-21U 4x5 Pentium 4 1.6GHz 128MB 40GB 7200 CD-RW
A22p 2292-33U 4x5 Pentium 4 1.8GHz 128MB 20GB 7200 CD-ROM NVIDIA 16MB
Leading edge technologies and affordable prices
Positioning
Processor Intel
256KB std and max / ECC / full speed
L2 cache
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
Memory - std/max 128MB std / 1.5GB max
Memory - sockets Three 168-pin gold-plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2)
Graphics controller
Disk ATA-100, 7200 rpm, SMART
Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Disk controller
Diskette drive 3.5" 1.44MB diskette drive
Some models: 48X-20X
CD-ROM
CD-RW Some models 16X/10X/40X Max
Optional
CD-RW/DVD combo
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1), microphone in, headphone out;
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Integrated digital audio / SoundMAX
Audio
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
External active speakers / Jazz Infinity / 2-piece / 3 watts per channel / blk color
Speakers
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Modem 56K
PCI adapter
IEEE 1394 (FireWire) Optional PCI adapter
None
Security chip
Keyboard / mouse IBM Rapid Access IIIe Keyboard (USB / no USB hub or ports) /
IBM ScrollPoint
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Home
®
Microsoft Windows XP Home Edition
® ®
Lotus SmartSuite Millennium license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
- Microsoft Works Suite 2001 (Word 2000,
Works 6.0, Encarta Encyclopedia Standard
2001, Money 2001, Picture It! Publishing
2001, Streets & Trips 2001, Outlook
Express)
See footnotes for important warranty information
US models announced September 18, 2001
US models withdrawn effective March 2002, July 2002, or August 2003
Processor GHz Mem
®
4 1.5GHz 128MB 20GB
®
Pentium 4 1.5, 1.6, 1.8GHz with 400MHz frontside bus
NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
3
III
4 CD-ROM / bootable
ethernet, monitor
10
data/fax modem / Conexant
® III mouse (USB)
5
Options
64MB SDRAM 133MHz CL2 NP DIMM
6
128MB SDRAM 133MHz CL2 NP DIMM
256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
3-Piece Speakers (black)
40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
12X/8X/32X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 31P7405
Disk RPM Optical Graphics
2
7200 CD-ROM NVIDIA 16MB 10/100
NVIDIA 32MB
4
CD-RW / ATAPI / bootable
® 3.0 with SPX / software-based audio
®
chipset / controllerless HCF modem /
4
DVD-ROM Drive (black)
4 CD-RW internal (black) 10K3785
11 CD-RW/DVD-ROM
Personal Systems Reference (PSREF)
Modem
Ethernet
Modem Windows
10/100 Modem Windows XP Home
10/100 Modem Windows XP Home
Micro Tower
Stealth black color
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)

SYSTEMS MANAGEMENT

PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
U bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control

LIMITED WARRANTY

10K0055
1 year parts and labor
10K0057
10K0059 On site, 8 am - 5 pm, Mon - Fri,
10K0061
2nd business day response time
33L3441
On site service upgrade options (in
22P7156
eligible locations)
09N4207
• 1 year 9x5 4 hour response
22P6950
(ServicePac part number 54P1858)
• 2 year 9x5 Next Business Day
10K3790
(ServicePac part number 54P1859)
22P6959
• 2 year 9x5 4 hour response
00N8078
(ServicePac part number 54P1860)
9511AG4
• 3 year 9x5 Next Business Day
6656HG2
(ServicePac part number 54P1861)
651767N
• 3 year 9x5 4 hour response
22P5170
(ServicePac part number 54P1862)
33L3478
14
24x7 toll-free support for warranty
issues during the warranty period
(2292)
Created by IBM PC Institute
Available
Preload date
® 5
XP Home Oct 2001
Oct 2001
Oct 2001
Optical
diskette
disk
(vertical)
std optical drive
open
open
std diskette
- modem
SECURITY
1
7
:
1
IBM Corp. August 2003
