IBM NetVista A20 Reference Manual page 24

IBM
® NetVista A22p (6823) - withdrawn
TM
Name Type-model Slotxbay
A22p 6823-91U 4x5 Pentium
A22p 6823-11U 4x5 Pentium 4 1.6GHz 256KB 128MB 40GB Value Combo
A22p 6823-12U 4x5 Pentium 4 1.6GHz 256KB 128MB 40GB Value CD-RW NVIDIA 32MB
A22p 6823-21U 4x5 Pentium 4 1.8GHz 256KB 128MB 40GB 7200 CD-RW NVIDIA 32MB
A22p 6823-22U 4x5 Pentium 4 1.8GHz 256KB 256MB 80GB 7200 Combo
A22p 6823-31U 4x5 Pentium 4 2.0GHz 256KB 256MB 80GB 7200 Combo
A22p 6823-3CU 4x5 Pentium 4 2.0GHz 512KB 256MB 80GB 7200 Combo
Positioning Leading edge technologies and affordable prices
Processor Intel
with 400MHz frontside bus
L2 cache 256KB or 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 128MB or 256MB std / 1.5GB max
Three 168-pin gold-plated DIMM sockets / one socket used
Memory - sockets
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2)
NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
Graphics controller
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
(one of following)
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX VGA/DVI/TV / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
connectors: analog DB-15, digital DVI-D, S-video out (single head)
ATA-100, SMART
Disk
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
3.5" 1.44MB diskette drive
Diskette drive
CD-ROM Some models: 48X-20X
CD-RW Some models 16X/10X/40X Max
Some models: 8X/4X/32X/8X Max
CD-RW/DVD combo
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 1.1), microphone in, headphone out;
Ports
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Back: microphone jack, line-in, line-out
Audio connectors
Speakers External active speakers / Jazz Infinity / 2-piece / 3.5 watts / black color
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Modem 56K
PCI adapter
Some models: FireWire PCI adapter / 1394A / 400Mbps / dual 6-pin ports on
1394 FireWire
rear / includes 4-pin port on front of system / no cables included
None
Security chip
Keyboard / mouse IBM Rapid Access IIIe Keyboard (USB / no USB hub or ports) /
IBM ScrollPoint III mouse (USB)
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
185 watts with variable speed fan / universal / manual switch
Power supply
Preload with Windows XP Home
®
Microsoft Windows XP Home Edition
Lotus SmartSuite license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
- Microsoft Works Suite 2001 (Word 2000,
Works 6.0, Encarta Encyclopedia Standard
2001, Money 2001, Picture It! Publishing
2001, Streets & Trips 2001, Outlook
Express)
See footnotes for important warranty information
US model announced January 22, 2002; previous models on September 18, 2001
US models withdrawn effective March, July, or August 2002
Processor GHz L2 cache Mem
® 4 1.5GHz 256KB 128MB 20GB
®
Pentium 4 at 1.5, 1.6, 1.8, 2.0GHz
3 III
4 CD-ROM / bootable
4
CD-RW / ATAPI / bootable
11
Firewire models: IEEE 1394 front port
ethernet, monitor
10 ®
data/fax modem / Conexant
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
6
128MB SDRAM 133MHz CL2 NP DIMM
256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
3-Piece Speakers (black)
40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
12X/8X/32X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint
Other options at ibm.com/pc/us/accessories
Disk RPM Optical Graphics
2 Value CD-ROM NVIDIA 16MB
NVIDIA 32MB
NVIDIA 32MB out Mod
NVIDIA 32MB out Mod
NVIDIA 32MB out Mod
Micro Tower
Bay
Bay
Bay
Bay
Bay
Slot 1:
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - FireWire**
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
** in some models
CD-RW/DVD-ROM Combo
®
3.0 with SPX / software-based audio
chipset / controllerless HCF modem /
4 DVD-ROM Drive (black)
4 CD-RW internal (black) 10K3785
11 CD-RW/DVD-ROM
®
Mouse 33L3250
Personal Systems Reference (PSREF)
Modem FireWire Preload
Mod XP Home
Mod XP Home Works Oct 2001
Mod 1394 XP Home Works Oct 2001
Mod 1394 XP Home Works Oct 2001
1394 XP Home Works Oct 2001
1394 XP Home Works Oct 2001
1394 XP Home Works Feb 2002
Stealth black color
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
5.25", HH 1.6", access,
5.25", HH 1.6" access,
3.5", SL 1", access,
3.5", SL 1", access,
3.5", SL 1", no access, std disk
3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
3 year parts / 1 year labor
International Warranty Service
1st year: on site, 8 am - 5 pm,
10K0055
Mon - Fri coverage,
10K0057
2nd business day response time
10K0059
2nd/3rd year: parts exchange only,
10K0061
33L3441 call 1-800-772-2227
22P7156
3 year on site warranty service
09N4207
upgrade options
22P6950
• Next day response, Mon-Fri 8-5
(ServicePac part number 30L9199)
10K3790 • 4 hour response, Mon-Fri 8-5
22P6959
(ServicePac part number 41L2732)
00N8078
• 4 hour response, 7 day x 24 hr
(ServicePac part number 31L2724)
9511AG4
Post warranty maintenance
6656HG2
651767N services available
33L3478
24x7 14 toll-free support for warranty
issues during the warranty period
(6823)
Created by IBM PC Institute
Suite Available
5 Works Oct 2001
Optical
diskette
disk
(vertical)
std optical drive
open
open
std diskette
- modem
1
9
7 :
1
IBM Corp. August 2002
