IBM NetVista A20 Reference Manual page 23

IBM
® NetVista A22p (6350) - withdrawn
TM
Name Type-model Color Slotxbay
A22p 6350-11U Black 4x5 Pentium
A22p 6350-13U Black 4x5 Pentium 4 1.5GHz 256KB 128MB 20GB 7200 CD-ROM NVIDIA 16MB
A22p 6350-15U Black 4x5 Pentium 4 1.5GHz 256KB 128MB 20GB 7200 CD-ROM NVIDIA 16MB
A22p 6350-25U Black 4x5 Pentium 4 1.6GHz 256KB 128MB 20GB 7200 CD-ROM NVIDIA 16MB
A22p 6350-26U Black 4x5 Pentium 4 1.6GHz 256KB 128MB 40GB 7200 CD-RW
A22p 6350-35U Black 4x5 Pentium 4 1.8GHz 256KB 128MB 40GB 7200 CD-RW
A22p 6350-36U Black 4x5 Pentium 4 1.8GHz 256KB 128MB 20GB 7200 CD-ROM NVIDIA 16MB
A22p 6350-37U Black 4x5 Pentium 4 1.8GHz 256KB 128MB 20GB 7200 CD-ROM NVIDIA 16MB
A22p 6350-51U Black 4x5 Pentium 4 2.0GHz 512KB 256MB 40GB 7200 CD-RW
A22p 6350-61U Black 4x5 Pentium 4 2.2GHz 512KB 256MB 80GB 7200 Combo
Positioning Leading edge technologies and affordable prices
Processor Intel
with 400MHz frontside bus
L2 cache 256KB or 512KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 64MB or 128MB or 256MB std / 1.5GB max
Memory - sockets Three 168-pin gold-plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2) / supports optional ECC
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
ATI
Radeon VE (RV100) GPU / 64MB std and max 155MHz
SDRAM / 300MHz RAMDAC / one analog DB-15 connector
Disk ATA-100, 7200 rpm, SMART
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM Some models: 48X-20X
CD-RW Some models: 16X/10X/40X Max
CD-RW/DVD combo Some models: 8X/4X/32X/8X Max
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 1.1)
Ports
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires optional powered speakers
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Security chip None
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Cooling fans Three variable speed fans (power supply, fansink, rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 98SE
Microsoft Windows 98 Second Edition
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Professional
Microsoft Windows XP Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
See footnotes for important warranty information
US models announced January 22, 2002; previous models on Sept 18 and Nov 27, 2001
US models withdrawn effective March, July, or August 2002
Processor GHz L2 cache
® 4 1.5GHz 256KB 64MB
®
Pentium 4 at 1.5, 1.6, 1.8, 2.0, or 2.2GHz
® Radeon 7000 (advanced 3D) / AGP 4X adapter /
3
III
4 CD-ROM / bootable
4 CD-RW / bootable
11
ethernet, monitor
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
6 128MB SDRAM 133MHz CL2 NP DIMM
6 256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
2-Piece Speakers (black)
3-Piece Speakers (black)
5 40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
6
40X/12X/40X Max
6
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
5
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
6
IBM E74M 17" (15.9" view) Monitor (blk)
6
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint
Other options at ibm.com/pc/us/accessories
Mem Disk RPM Optical
20GB 2 7200 CD-ROM NVIDIA 16MB 845 Windows
CD-RW/DVD-ROM Combo
® 3.0 with SPX / software-based audio
4
DVD-ROM Drive (black)
4
CD-RW internal (blk)
11
CD-RW/DVD-ROM
® Mouse 33L3250
Personal Systems Reference (PSREF)
Graphics Chipset
845 Windows 2000
845 Windows XP Pro Nov2001
845 Windows XP Pro Nov2001
NVIDIA 16MB 845 Windows XP Pro Nov2001
NVIDIA 16MB 845 Windows XP Pro Nov2001
845 Windows 2000
845 Windows XP Pro Feb 2002
Radeon 64MB 845 Windows XP Pro Feb 2002
Radeon 64MB 845 Windows XP Pro Feb 2002
Micro Tower
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Stealth black color
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
3 year parts / 1 year labor
10K0055
International Warranty Service
10K0057
1st year: on site, 8 am - 5 pm,
10K0059
Mon - Fri coverage,
10K0061
2nd business day response time
33L3440
2nd/3rd year: parts exchange only,
33L3441
22P7156
call 1-800-772-2227
09N4207
3 year on site options available
22P6950
• Next day response, Mon-Fri 8-5
22P6976
(ServicePac
10K3790 • 4 hour response, Mon-Fri 8-5
22P6959
(ServicePac part number 41L2732)
• 4 hour response, 7 day x 24 hr
9511AG4
(ServicePac part number 31L2724)
6656HG2
Post warranty maintenance
651767N
22P5170 services available
33L3478
24x7 14 toll-free support for warranty
issues during the warranty period
(6350)
Created by IBM PC Institute
Preload Available
® 98 SE 5 Oct 2001
Oct 2001
Feb 2002
CD-ROM
diskette
disk
(vertical)
std CD-ROM
open
open
std diskette
1
9
7
:
®
part number 30L9199)
1
IBM Corp. August 2002
