® NetVista A22p (6349) - withdrawn
TM
Name Type-model Color Slotxbay
A22p 6349-11U Black 4x4 Pentium
A22p 6349-17U Black 4x4 Pentium 4 1.5GHz 256KB 128MB 20GB CD-ROM NVIDIA 16MB
Positioning Leading edge technologies and affordable prices
Processor Intel
L2 cache 256KB std and max / ECC / full speed
Implementation Processor and L2 cache in FC-PGA2 in mPGA478B socket
Memory - std/max 64MB or 128MB std / 1.5GB max
Memory - sockets Three 168-pin gold plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2)
Graphics controller NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
250MHz RAMDAC / one analog DB-15 connector
Disk ATA-100, 7200 rpm, SMART
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 48X/20X
CD-RW Optional
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD or DVD,
one 1-drop cable to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 1.1)
Ports
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Back: microphone jack, line-in, line-out
Audio connectors
Speakers None / requires optional powered speakers
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical layer)
/ supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Security chip None
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Cooling fans Two or three variable speed fans (power supply, fansink, 1.6GHz and higher
have rear fan)
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
®
Microsoft Windows 2000 Professional
Lotus SmartSuite license
®
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 98SE
Microsoft Windows 98 Second Edition
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 18, 2001; withdrawn effective December 2001
Processor L2 cache
GHz 1
® 4 1.5GHz 256KB 64MB
® Pentium 4 1.5GHz with 400MHz
3
III
4 CD-ROM / bootable
ethernet,monitor
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
128MB SDRAM 133MHz CL2 NP DIMM
6
256MB SDRAM 133MHz CL2 NP DIMM
6
512MB SDRAM 133MHz CL2 NP DIMM
2-Piece Speakers (black)
3-Piece Speakers (black)
5 40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X
6
12X/8X/32X
6
8X/4X/32X/8X
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM 675 Uninterruptable Power Supply
IBM Optical 3-Button ScrollPoint Mouse 33L3250
Mem Disk CD-ROM
20GB 2 CD-ROM NVIDIA 16MB 845 10/100 Windows
1 Front Side Bus
® 3.0 with SPX / software-based audio
4 max DVD-ROM Drive (black)
4 Max CD-RW internal (black) 10K3785
4
Max CD-RW/DVD-ROM
Graphics Chipset Ethernet
845 10/100 Windows 2000
Desktop
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: full-length, full-height, 32-bit AGP 4X (1.5v) - used
Slot 2: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: full-length, full-height, 32-bit PCI 2.2 (5v)
Slot 4: full-length, full-height, 32-bit PCI 2.2 (5v)
16.7" W X 16.7"D X 5.5"H
425mm W X 425mm D X 140mm H
24 to 26.5 lb (10.9 to 12.0 kg)
Stealth black color
Bay 1 and 2 in cage flips up (latched and pivoting)
Bay 3 and 4 in cage flips up (latched and pivoting)
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY*
3 year parts / 1 year labor
10K0055
International Warranty Service
10K0057
registration available
10K0059
1st year: on site, 8 am - 5 pm,
10K0061
Mon - Fri coverage,
33L3440
2nd business day response time
33L3441
22P7156
2nd/3rd year: parts exchange only,
09N4207
call 1-800-772-2227
22P6950
3 year on site options available
• Next day response, Mon-Fri 8-5
(ServicePac
10K3790
22P6959
• 4 hour response, Mon-Fri 8-5
00N8078
(ServicePac part number 41L2732)
• 4 hour response, 7 day x 24 hr
9511AG4
(ServicePac part number 31L2724)
6656HG2
Post warranty maintenance
651767N
22P5170
services available
33L3448
24 hour x 7 day
electronic, and Internet support
No warranties are expressed or implied in this summary
(6349)
Preload Available
® 98SE 5 Oct 2001
Oct 2001
diskette
CD-ROM
disk
std CD-ROM
open
std diskette
,9
9
7 :
®
part number 30L9199)
14 telephone,
