IBM NetVista A20 Reference Manual page 19

IBM
® NetVista A22p (2292) - January 2002 - withdrawn
TM
Name Type-model Slotxbay
A22p 2292-22U 4x5 Pentium
A22p 2292-23U 4x5 Pentium 4 1.6GHz 256KB 128MB 20GB CD-ROM Vanta 16MB
A22p 2292-34U 4x5 Pentium 4 1.8GHz 256KB 128MB 20GB CD-ROM Vanta 16MB
A22p 2292-35U 4x5 Pentium 4 1.8GHz 256KB 128MB 40GB CD-RW
A22p 2292-36U 4x5 Pentium 4 1.8GHz 256KB 256MB 40GB CD-RW
A22p 2292-41U 4x5 Pentium 4 2.2GHz 512KB 256MB 80GB DVD, RW GeForce2 32MB out 10/100 Mod 1394 XP Home
A22p 2292-42U 4x5 Pentium 4 2.2GHz 512KB 256MB 80GB DVD, RW GTS Pro 64MB out
A22p 2292-43U 4x5 Pentium 4 2.2GHz 512KB 256MB 80GB Combo
A22p 2292-51U 4x5 Pentium 4 2.0GHz 512KB 256MB 40GB CD-RW
Leading edge technologies and affordable prices
Positioning
Intel
Processor
with 400MHz frontside bus
L2 cache 256KB or 512KB std and max / ECC / full speed
Processor and L2 cache in FC-PGA2 in mPGA478B socket
Implementation
128MB or 256MB std / 1.5GB max
Memory - std/max
Memory - sockets Three 168-pin gold-plated DIMM sockets / one socket used
Memory - type 133MHz SDRAM / non-parity / industry std / unbuffered /
PC133-compliant / CAS Latency 2 (CL2)
NVIDIA Vanta (2D and 3D) / AGP 4X adapter /
Graphics controller
TNT2 Vanta GPU / 16MB std and max 125MHz SDRAM /
(one of following)
250MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX (advanced 3D) / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / one analog DB-15 connector
NVIDIA GeForce2 MX VGA/DVI/TV / AGP 4X adapter /
GeForce2 MX GPU / 32MB std and max 166MHz SDRAM /
350MHz RAMDAC / three connectors: analog DB-15,
digital DVI-D, S-video out (but single head [not dual head])
NVIDIA GeForce2 GTS Pro (advanced 3D) / AGP 4X adapter /
GeForce2 Pro GPU / 64MB std and max 200MHz
DDR-SDRAM / 350MHz RAMDAC /
one analog DB-15 connector and S-Video out connector
ATA-100, 7200 rpm, SMART
Disk
Disk controller Enhanced IDE / ATA-100 / integrated in I/O Controller Hub (ICH2)
3.5" 1.44MB diskette drive
Diskette drive
Some models: 48X-20X
CD-ROM
CD-RW Some models 16X/10X/40X Max
Some models: 16X/48X Max
DVD-ROM
Some models: 8X/4X/32X/8X Max
CD-RW/DVD combo
Cables Two EIDE 80-conductor cables (one 2-drop cable to CD, one 1-drop cbl to disk)
Chipset Intel 845 chipset / 82845 Memory Controller Hub (MCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
National 87360 Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1), microphone in, headphone out;
Back: two 9-pin serial, parallel, two USB (Ver 1.1), keyboard, mouse,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
Back: microphone jack, line-in, line-out
Audio connectors
Speakers External active speakers / Jazz Infinity / 2-piece / 3.5 watts / black color
10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical
Ethernet
layer) / supports PXE and Wake on LAN / Intel Pro/100VE Desktop Connection
Modem 56K
Some models: FireWire PCI adapter / 1394A / 400Mbps / dual 6-pin ports on rear /
1394 FireWire
includes 4-pin port on front of system / no cables included
Security chip None
Keyboard / mouse IBM Rapid Access IIIe Keyboard (USB / no USB hub or ports) /
IBM ScrollPoint
Three variable speed fans (power supply, fansink, rear fan)
Cooling fans
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows XP Home
®
Microsoft Windows XP Home Edition
® ®
Lotus SmartSuite Millennium license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
- Models 23U and 35U only: Microsoft Works
Suite 2001 (Word 2000, Works 6.0,
Encarta Encyclopedia Standard
2001, Money 2001, Picture It! Publishing
2001, Streets & Trips 2001, Outlook
Express)
Note: Models 41U and 42U have two optical
drives (one DVD-ROM and one CD-RW)
See footnotes for important warranty information
US models announced January 22, 2002
US models withdrawn effective July 2002 or August 2002
Processor GHz L2 cache Mem
®
4 1.6GHz 256KB 128MB 20GB
® Pentium 4 at 1.6, 1.8, 2.0, or 2.2GHz
3 III
4 CD-ROM / bootable
4
CD-RW / ATAPI / bootable
4 DVD-ROM / bootable
11
ethernet, monitor
10 ®
data/fax modem / Conexant
® III mouse (USB)
5 Options
64MB SDRAM 133MHz CL2 NP DIMM
6
128MB SDRAM 133MHz CL2 NP DIMM
256MB SDRAM 133MHz CL2 NP DIMM
512MB SDRAM 133MHz CL2 NP DIMM
40GB IDE Disk ATA-100 (5400 rpm)
60GB IDE Disk ATA-100 (7200 rpm)
IBM 16X Max
40X/12X/40X Max
8X/4X/32X/8X Max
Combo drive (black)
IBM DVD-RAM/DVD-R Drive (black)
Zip Drive 250MB (white/black)
IBM E94 19" (18.0" viewable) Monitor (blk) 633440N
IBM T540 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" view) Monitor (blk)
Other options at ibm.com/pc/us/accessories
Disk Optical Graphics
2
CD-ROM Vanta 16MB
GeForce2 32MB
GeForce2 32MB out 10/100 Mod 1394 XP Home
GeForce2 32MB out 10/100 Mod 1394 XP Home
GeForce2 32MB out 10/100 Mod 1394 XP Home
Micro Tower
Stealth black color
7.5" W X 15.7"D X 16.3"H
190mm W X 399mm D X 415mm H
22.5 to 29.5 lb (10.2 to 13.4 kg)
Handle on top front
Disk bay pivots forward
Power supply latched and pivots
from left side
Toolless rails for disk mounting
Toolless cover removal
Toolless AGP and PCI slots
Bay
Bay
Bay
Bay
Bay
Slot 1:
Slot 2: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
Slot 3: 3/4-length, full-height, 32-bit PCI 2.2 (5v) - FireWire**
Slot 4: 3/4-length, full-height, 32-bit PCI 2.2 (5v)
** in some models
CD-RW/DVD-ROM Combo
®
3.0 with SPX / software-based audio
chipset / controllerless HCF modem / PCI adapter
4
DVD-ROM Drive (black)
4
CD-RW internal (blk)
11 CD-RW/DVD-ROM
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Modem FireWire Preload
Ethernet
10/100 Mod XP Home
10/100 Mod XP Home Works Feb 2002
10/100 Mod XP Home
10/100 Mod XP Home Works Feb 2002
10/100 Mod 1394 XP Home
5.25", HH 1.6", access, std optical drive
5.25", HH 1.6" access, std optical or open
3.5", SL 1", access, open
3.5", SL 1", access, std diskette
3.5", SL 1", no access, std disk
3/4-length, full-height, 32-bit AGP 4X (1.5v) - used
SYSTEMS MANAGEMENT
PC 2001-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature (U-bolt
assembly is optional)
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY
1 year parts and labor
On site, 8 am - 5 pm, Mon - Fri,
2nd business day response time
10K0055
On site warranty service upgrade
10K0057
7
options :
10K0059
• 1 year 9x5 4 hour response
10K0061
(ServicePac part number 54P1858)
22P7156
09N4207
• 2 year 9x5 Next Business Day
22P6950
(ServicePac part number 54P1859)
22P6976
• 2 year 9x5 4 hour response
(ServicePac part number 54P1860)
10K3790
• 3 year 9x5 Next Business Day
22P6959
00N8078
(ServicePac part number 54P1861)
• 3 year 9x5 4 hour response
9511AG4
(ServicePac part number 54P1862)
6656HG2
24x7 14 toll-free support for warranty
651767N
issues during the warranty period
(2292J)
Suite Available
5
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Feb 2002
Optical
diskette
disk
(vertical)
- modem
1
1
IBM Corp. August 2002
