IBM NetVista A20 Reference Manual page 18

IBM
® NetVista A22 (2257) - withdrawn
TM
Name Type-model Color
A22 2257-31U Black 3x4 Celeron
A22 2257-32U Black 3x4 Celeron 1.3GHz 128MB 40GB
A22 2257-33U Black 3x4 Celeron 1.3GHz 128MB 40GB
Positioning Powerful, proven technology for performance on a budget
Processor Intel
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
Display Video Memory Technology (DVMT); uses up to 11MB
main memory with no display cache
Disk 40GB, ATA-100, 5400 rpm
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller
Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 31U/32U: 48X-20X
CD-RW 33U:
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E2 chipset /
82810E Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627F Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two serial, parallel, two USB (Ver 1.1), keyboard, mouse, ethernet,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers 31U:
32U/33U: External speakers / 2-piece / 1.5 watts per channel /
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ET PHY (physical
layer) / Wake on LAN
Modem 56K
Keyboard 104-key IBM Preferred Pro Full-size keyboard (6-pin PS/2 connector)
Mouse IBM Standard 2-Button Mouse (6-pin PS/2 connector)
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows XP Professional
® ®
Microsoft Windows XP Professional
- Disk-to-Disk Recovery (in Service
Partition)
Software Selections CD-ROM
Preload with Windows XP Home Edition
Microsoft Windows XP Home Edition
- Disk-to-Disk Recovery (in Service
Partition)
Software Selections CD-ROM
Preloaded (all)
Access IBM
Norton AntiVirus (OEM Version)
PC-Doctor
Update Connector
Veritas MyCD and DLA (CD-RW)
Downloadable (all)
IBM Rapid Restore PC
Access Support
Remote Deployment Manager
Software Delivery Assistant
IBM Director Agent
Software Migration Assistant
License - CD not included (all)
- Lotus SmartSuite Millennium and
Lotus Notes Stand Alone Client
See footnotes for important warranty information
US models announced October 8, 2002
US models withdrawn effective February 2003
Slot x
bay Processor Memory
GHz
®
1.3GHz 128MB 40GB
®
Celeron 1.3GHz with 100MHz frontside bus
4 CD-ROM / bootable
4
16X/10X/40X Max CD-RW / bootable
monitor
None / requires optional powered speaker(s) (not included)
200Hz - 17 kHz frequency response / black color with blue grill
10
V.90 data/fax modem / Conexant
5 Options
128MB SDRAM 133MHz NP DIMM
256MB SDRAM 133MHz NP DIMM
Infinity 2-Piece Active Speakers (black)
Altec Lansing 4100 5-Piece Speakers
40X/12X/40X Max
5 8X/4X/32X/8X Max
Combo drive (black)
IBM 16X Max
10
V.90 Modem PCI low profile
IBM USB 2.0 Portable CD-RW
IBM Portable USB 2.0 Disk Rapid Restore
IBM 500 Uninterruptable Pwr Sup (flat)
IBM 675 Uninterruptable Pwr Sup (tower)
IBM High Rate Wireless LAN PCI Adapter
IBM High Rate Wireless LAN Access Point 09N9906
IBM High Rate Wireless LAN Gateway
15
IBM E74 (16.0" viewable) Monitor (black)
IBM P77 (16.0" viewable) Monitor (black)
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM T750 15" Flat Panel Monitor (black)
IBM Wireless keyboard and mouse (blk)
IBM Rapid Access III USB Kybd w/ hub (blk) 22P5185
IBM Optical 3-Button ScrollPoint Mouse
IBM Portable USB 2.0 20GB Hard Disk
6
8 Disk Optical Diskette Graphics
2
CD-ROM Diskette GMCH 10/100 No
CD-ROM Diskette GMCH 10/100 Modem 810E Yes
CD-RW Diskette GMCH 10/100 Modem 810E Yes
® 3.0 with SPX / software-based audio
®
chipset / PCI adapter
4
CD-RW internal (blk)
11 CD-RW/DVD-ROM
4 DVD-ROM Drive (black)
Personal Systems Reference (PSREF)
Ethernet Chipset
Speakers
Modem
810E No
Micro Tower
Bay 5.25", HH 1.6", access, Optical
Bay 5.25", HH 1.6" access, open
Bay 3.5", SL 1", access, std diskette
Bay 3.5", SL 1", no access, std disk
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v) -
used by modem (some)
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Stealth black color
Swinging door on Bay 1, 2, and 3 (does not cover Bay 1)
Slide out disk
Handle on top
7.6" W X 15.0" D X 15.0" H
194mm W X 381mm D X 381mm H
18.3 to 22.5 lb (8.3 to 10.3 kg)
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
U bolt anchoring feature
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3073
33L3075
33L3440
22P8474
22P6976
LIMITED WARRANTY*
10K3790
22P6950
1 year parts and labor
19K4162
On site, 8 am - 5 pm, Mon - Fri,
22P5297
2nd business day response time
09N4211
On site service upgrade options
33L3477
(in eligible locations)
33L3478
22P6901
• 1 year 9x5 4 hour response
(ServicePac part number 54P1858)
22P6401
• 2 year 9x5 Next Business Day
63324HN
(ServicePac part number 54P1859)
6639U3N
• 2 year 9x5 4 hour response
9512AB1
6656HG2
(ServicePac part number 54P1860)
6657HG2
• 3 year 9x5 Next Business Day
22P5170
(ServicePac part number 54P1861)
• 3 year 9x5 4 hour response
31P7405
(ServicePac part number 54P1862)
09N4211
24 hour x 7 day
electronic, and Internet support
(2257)
Created by IBM PC Institute
Available
Preload date
5
XP Pro Oct 2002
XP Home Oct 2002
XP Home Oct 2002
Optical
diskette
disk
(vertical)
,9
7
:
14 telephone,
IBM Corp. February 2003
