IBM
® NetVista A22 (6341) - withdrawn
TM
Name Type-model Color
A22 6341-81U Black
A22 6341-83U Black
A22 6341-D1U Black
A22 6341-D3U Black
A22 6341-E1U Black
A22 6341-E3U Black
Positioning Powerful, proven technology for performance on a budget
Processor Intel
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
Display Video Memory Technology (DVMT); uses up to 11MB
main memory with no display cache
Disk 40GB, ATA-100, 5400 rpm
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller
Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 48X-20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E2 chipset /
82810E Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627F Super I/O for diskette, parallel, serial, keyboard, mouse
Front: two USB (Version 1.1)
Ports
Back: two serial, parallel, two USB (Ver 1.1), keyboard, mouse, ethernet,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires optional powered speaker(s) (not included)
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ET PHY (physical
layer) / Wake on LAN
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 185 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service
Partition)
Software Selections CD-ROM
Preload with Windows XP Professional
Microsoft Windows XP Professional
Lotus SmartSuite license
®
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service
Partition)
Software Selections CD-ROM
See footnotes for important warranty information
US models announced June 18 or August 27, 2002
US models withdrawn effective October 2002, December 2002, or February 2003
Slot x
bay Processor GHz Memory
3x4 Celeron ® 1.2GHz 128MB
3x4 Celeron 1.2GHz 128MB
3x4 Celeron 1.3GHz 128MB
3x4 Celeron 1.3GHz 128MB
3x4 Celeron 1.4GHz 128MB
3x4 Celeron 1.4GHz 128MB
® Celeron 1.2, 1.3, or 1.4GHz with 100MHz frontside bus
4 CD-ROM / bootable
monitor
5 Options
128MB SDRAM 133MHz NP DIMM
6 256MB SDRAM 133MHz NP DIMM
6
Infinity 2-Piece Active Speakers (black)
Altec Lansing 4100 5-Piece Speakers
40X/12X/40X Max
8X/4X/32X/8X Max
Combo drive (black)
5 IBM 16X Max
V.90 10 Modem PCI low profile
IBM USB 2.0 Portable CD-RW
6
IBM Portable USB 2.0 Disk Rapid Restore
6
IBM 500 Uninterruptable Pwr Sup (flat)
IBM 675 Uninterruptable Pwr Sup (tower)
IBM High Rate Wireless LAN PCI Adapter
IBM High Rate Wireless LAN Access Point 09N9906
IBM High Rate Wireless LAN Gateway
IBM E74 (16.0" viewable) Monitor (black)
IBM P77 (16.0" viewable) Monitor (black)
IBM T541 15" Flat Panel Monitor (black)
IBM T560 15" Flat Panel Monitor (black)
IBM T750 15" Flat Panel Monitor (black)
IBM Wireless keyboard and mouse (blk)
IBM Rapid Access III USB Kybd w/ hub (blk) 22P5185
IBM Optical 3-Button ScrollPoint Mouse
IBM Portable USB 2.0 20GB Hard Disk
8 Disk CD-ROM Diskette
40GB 2 48X-20X 4 Diskette GMCH
40GB 48X-20X Diskette GMCH
40GB 48X-20X Diskette GMCH
40GB 48X-20X Diskette GMCH
40GB 48X-20X Diskette GMCH
40GB 48X-20X Diskette GMCH
®
3.0 with SPX / software-based audio
4
CD-RW internal (blk)
11
CD-RW/DVD-ROM
4 DVD-ROM Drive (black)
Personal Systems Reference (PSREF)
Graphics Ethernet Chipset
10/100 810E Windows
10/100 810E Windows 2000
10/100 810E Windows XP Pro
10/100 810E Windows 2000
10/100 810E Windows XP Pro
10/100 810E Windows 2000
Desktop
Bay 5.25", HH 1.6", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 8 inch max, 32-bit PCI 2.2 (5v)
Slot 2: 8 inch max, 32-bit PCI 2.2 (5v)
Slot 3: 8 inch max, 32-bit PCI 2.2 (5v)
16.7" W X 16.7"D X 5.5"H
425mm W X 425mm D X 140mm H
21 to 25 lb (9.6 to 11.4 kg)
Stealth black color
Bay 1 and 2 in cage flips up
Bay 3 and 4 in cage flips up
Tool-less cover removal
Tool-less PCI slots
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
SECURITY
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3073
LIMITED WARRANTY
33L3075
3 year parts / 1 year labor
33L3440
International Warranty Service
22P8474
1st year: on site, 8 am - 5 pm,
22P6976
Mon - Fri coverage,
2nd business day response time
10K3790
2nd/3rd year: parts exchange only,
22P6950
call 1-800-772-2227
19K4162
On site warranty service upgrade
22P5297
options (in eligible locations):
09N4211
• 3 year IOR 9x5, NBD response
33L3477
(ServicePac part number 30L9199)
33L3478
• 3 year IOR 9x5, 4 hour response
22P6901
(ServicePac part number 41L2732)
• 3 year IOR 24x7, 4 hour response
22P6401
(ServicePac part number 31L2724)
63324HN
• 4 year IOR 9x5, NBD response
6639U3N
(ServicePac part number 69P9158)
9512AB1
• 4 year IOR 9x5, 4 hour response
6656HG2
(ServicePac part number 69P9159)
6657HG2
• 4 year IOR 24x7, 4 hour response
22P5170
(ServicePac part number 69P9160)
Post warranty maintenance
31P7405
services available
09N4211
14
24x7 toll-free support for warranty
issues during the warranty period
(6341J)
Created by IBM PC Institute
Available
Preload date
® XP Pro 5 July2002
July2002
July2002
July2002
Aug 2002
Aug 2002
diskette
CD-ROM
disk
std or opt CD-ROM
open
std diskette
1
9
7
1
IBM Corp. February 2003
