IBM NetVista A20 Reference Manual page 16

IBM
® NetVista A21 (6342) - withdrawn
TM
Name Type-model Color
A21 6342-25U Black
A21 6342-B3U Black
A21 6342-46U Black
A21 6342-54U Black
A21 6342-62U Black
Positioning Powerful, proven technology for performance on a budget
Processor Intel
with 100MHz Front Side Bus or
Intel Pentium III 1.0GHz with 133MHz Front Side Bus
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
DVMT; uses up to 11MB main memory with no display cache
Disk ATA-100, value, SMART
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller
Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM 48X-20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E2 chipset / 82810E Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627F Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two serial, parallel, two USB (Ver 1.1), keyboard, mouse, ethernet,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires optional powered speakers
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical layer)
/ Wake on LAN
Keyboard / mouse 104 key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced August 28, 2001; previous models on July 17, 2001
US models withdrawn effective December 2001 or March 2002 or April 2002
Slotxbay Processor
MHz 1 or GHz
3x4 Celeron 850MHz 128MB 40GB
®
3x4 Pentium III 1.0GHz
3x4 Celeron 900MHz 128MB 20GB 48X-20X Diskette GMCH
3x4 Celeron 950MHz 128MB 20GB 48X-20X Diskette GMCH
3x4 Celeron 1.0GHz
® 1
Celeron 850,900, 950MHz
128KB std and max / ECC / full speed
3
III
4 CD-ROM / bootable
monitor
®
Options
5
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
6
2-Piece Speakers
3-Piece Speakers
40GB IDE Disk ATA-100 (5400 rpm)
Zip Drive 250MB (white/black)
5.25 to 3.5 DASD Bay Conversion Kit
12X/8X/32X
48X-20X
8X/4X/32X/8X
Combo Drive (black)
16MB NVIDIA Vanta LP PCI Card
56K V.90 Data/Fax PCI modem
10
V.90
IBM E94 (18.0" viewable) Monitor (blk)
IBM T540 15" Flat Panel Monitor (black)
IBM E74M (15.9" viewable) Monitor (blk) 651767N
IBM Wireless keyboard and mouse (blk)
IBM Rapid Access III Kybd USB (black) 22P5185
Memory 8 Disk CD-ROM Diskette
1
2 4
48X-20X Diskette GMCH
128MB 40GB 48X-20X Diskette GMCH
128MB 20GB 48X-20X Diskette GMCH
1
or 1GHz
®
3.0 with SPX / software-based audio
4
max CD-RW Internal (blk)
4 IDE CD-ROM (black)
4
max CD-RW/DVD-ROM
10
Modem PCI low profile
Personal Systems Reference (PSREF)
Graphics Ethernet Chipset
10/100 810E2 Windows
10/100 810E2 Windows 2000
10/100 810E2 Windows 2000
10/100 810E2 Windows 2000
10/100 810E2 Windows 2000
Micro Tower
Bay 5.25", HH 1.6", access, CD-ROM
Bay 5.25", HH 1.6" access, open
Bay 3.5", SL 1", access, std diskette
Bay 3.5", SL 1", no access, std disk
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Stealth black color
Swinging door on Bay 1, 2, and 3 (does not cover Bay 1)
Slide out disk
Handle on top
7.6" W X 15.0" D X 15.0" H
194mm W X 381mm D X 381mm H
18.3 to 22.5 lb (8.3 to 10.3 kg)
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U bolt anchoring feature
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3071 LIMITED WARRANTY*
33L3073
3 year parts / 1 year labor warranty
33L3075
International Warranty Service
33L3440
33L3441 1st year: on site, 8 am - 5 pm,
22P7156
Mon - Fri coverage,
00N8078
2nd business day response time
70G8165
2nd/3rd year: parts exchange only,
10K3785
call 1-800-772-2227
10K3782
3 year on site warranty service
10K3790
upgrade options:
33L3443
• Next day response, Mon-Fri 8-5
33L4618
• 4 hour response, Mon-Fri 8-5
19K4162
• 4 hour response, 7 day x 24 hr
633440N
Post warranty maintenance
9511AG4
services available
22P5170
24 hour x 7 day telephone,
electronic, and Internet support
No warranties are expressed or implied in this summary
Created by IBM PC Institute
Preload Available
® 5
2000 Jul 2001
Jul 2001
Aug 2001
Aug 2001
Aug 2001
CD-ROM
diskette
disk
(vertical)
SECURITY
,9
9
7
7
7
(6342) IBM Corp. April 2002
