IBM
® NetVista A21 (6339) - withdrawn
TM
Name Type-model Color
A21 6339-16U Black
A21 6339-24U Black
A21 6339-26U Black
A21 6339-B5U Black
A21 6339-B8U Black
A21 6339-41U Black
A21 6339-56U Black
A21 6339-57U Black
A21 6339-64U Black
A21 6339-81U Black
Positioning Leading-edge technologies and affordable prices
Processor Intel
with 100MHz Front Side Bus or
Intel Pentium III 1.0GHz with 133MHz Front Side Bus
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
DVMT; uses up to 11MB main memory with no display cache
Disk ATA-100, value, SMART
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller Hub (ICH2)
Diskette drive Some models: 3.5" 1.44MB diskette drive
CD-ROM Some models: 48X/20X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E2 chipset / 82810E Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627F Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two serial, parallel, two USB (Ver 1.1), keyboard, mouse, ethernet,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires optional powered speakers
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical layer)
/ Wake on LAN
Keyboard / mouse 104 or 106-key (rubber dome) keyboard / IBM 2-button mouse
Power supply 95 watts with variable speed fan / universal / manual switch
Preload with Windows 98SE
Microsoft Windows 98 Second Edition
Lotus ® SmartSuite ® license
®
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows 2000
Microsoft Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Preload with Windows XP Home
Microsoft Windows XP Home Edition
Lotus SmartSuite license
Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 18, 2001; previous models on July 17 and August 28, 2001
US models withdrawn from marketing effective November 2001 or December 2001 or March 2002 or April 2002
Slotxbay Processor
MHz 1 or GHz
3x3 Celeron 800MHz 128MB 20GB
3x3 Celeron 850MHz 128MB 20GB 48X-20X
3x3 Celeron 850MHz 128MB 20GB 48X-20X None
3x3 Pentium ® III 1.0GHz 128MB 40GB 48X-20X Diskette GMCH
3x3 Pentium III 1.0GHz 128MB 20GB 48X-20X None
3x3 Celeron 900MHz 128MB 20GB 48X-20X Diskette GMCH
3x3 Celeron 950MHz 128MB 20GB 48X-20X Diskette GMCH
3x3 Celeron 950MHz 128MB 20GB 48X-20X None
3x3 Celeron 1.0GHz 128MB 20GB 48X-20X Diskette GMCH
3x3 Celeron 1.0GHz 128MB 20GB 48X-20X Diskette GMCH
®
Celeron 800, 850, 900, 950MHz
128KB std and max / ECC / full speed
3 III
4
CD-ROM / bootable
monitor
®
5 Options
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
6
2-Piece Speakers (black)
3-Piece Speakers (black)
40GB IDE Disk ATA-100 (5400 rpm)
Zip Drive 250MB (white/black)
5
5.25 to 3.5 DASD Bay Conversion Kit
12X/8X/32X
6
48X-20X
6
8X/4X/32X/8X
Combo Drive (black)
16MB NVIDIA Vanta LP PCI Card
56K V.90 Data/Fax PCI modem
5
V.90 10
28
IBM E94 19" (18.0" v.i.s.) Monitor (blk)
6
IBM T540 15" Flat Panel Monitor (black)
6
IBM E74M 17" (15.9" v.i.s.) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM Rapid Access III Kybd USB (black) 22P5185
Mem 8 Disk CD-ROM Diskette
1
2 None Diskette GMCH
4 Diskette GMCH
1 1
or 1.0GHz
®
3.0 with SPX / software-based audio
4 max CD-RW Internal (blk)
4 IDE CD-ROM (black)
4
max CD-RW/DVD-ROM
10
Modem PCI low profile
Personal Systems Reference (PSREF)
Graphics Ethernet
10/100 Windows
10/100 Windows 2000
GMCH 10/100 Windows 2000
10/100 Windows 2000
GMCH 10/100 Windows 2000
10/100 Windows 2000
10/100 Windows 2000
GMCH 10/100 Windows 2000
10/100 Windows 2000
10/100 Windows XP Home
Desktop
Small Form Factor
Bay 3.5", SL 1", access,
Bay 5.25", HH 1.6" access,
Bay 3.5", SL 1", no access, std disk
Slot 1: 32-bit low-profile PCI 2.2 (5v)
Slot 2: 32-bit low-profile PCI 2.2 (5v)
Slot 3: 32-bit low-profile PCI 2.2 (5v)
Stealth black color
12.0" W x 15.0" D x 3.5" H
305mm W x 380mm D x 88 mm H
18 to 19 lbs (8.2 to 8.6 kg)
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
Knockout in rear for optional U-bolt
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
LIMITED WARRANTY*
3 year parts / 1 year labor
International Warranty Service
registration available
33L3071
1st year: on site, 8 am - 5 pm,
33L3073
Mon - Fri coverage,
33L3075
2nd business day response time
33L3440
2nd/3rd year: parts exchange only,
33L3441
22P7156 call 1-800-772-2227
00N8078
3 year on site warranty service
70G8165
upgrade options
10K3785
• Next day response, Mon-Fri 8-5
10K3782
(ServicePac
10K3790 • 4 hour response, Mon-Fri 8-5
33L3443
(ServicePac part number 41L2732)
33L4618
• 4 hour response, 7 day x 24 hr
19K4162
(ServicePac part number 31L2724)
633440N
Post warranty maintenance
9511AG4
651767N services available
22P5170
24 hour x 7 day
electronic, and Internet support
No warranties are expressed or implied in this summary
(6339)
Created by IBM PC Institute
Preload Available
® 98 SE 5 Jul 2001
Jul 2001
Jul 2001
Jul 2001
Jul 2001
Aug 2001
Aug 2001
Aug 2001
Aug 2001
Sep 2001
CD-ROM
diskette
disk
std or opt diskette
std or opt CD-ROM
SECURITY
,9
9
7
:
® part number 39L9199)
14
telephone,
IBM Corp. April 2002
