IBM NetVista A20 Reference Manual page 13

IBM
® NetVista A21 (6337) - withdrawn
TM
Name Type-model Color
IBM Odyssey Direct models
A21 6337-G03 Black 3x4
A21 6337-G04 Black 3x4
A21 6337-G05 Black 3x4
Positioning Leading-edge technologies and affordable prices
Processor Intel
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache 128KB std and max / ECC / full speed
Memory - std/max 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
DVMT; uses up to 11MB main memory with no display cache
Disk ATA-100, value, SMART
Disk controller Enhanced IDE / ATA-100 / integrated into I/O Controller
Hub (ICH2)
Diskette drive 3.5" 1.44MB diskette drive
CD-ROM Some models: 48X/20X
CD-RW Some models: 16X/10X/40X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E2 chipset / 82810E Graphics Memory Controller Hub (GMCH) /
82801BA I/O Controller Hub (ICH2) for PCI 2.2 bus, ATA-100 EIDE,
ethernet MAC, USB, Low Pin Count Interface / 82802 Firmware Hub /
Winbond 83627F Super I/O for diskette, parallel, serial, keyboard, mouse
Ports Front: two USB (Version 1.1)
Back: two serial, parallel, two USB (Ver 1.1), keyboard, mouse, ethernet,
Audio Integrated digital audio / SoundMAX
(done by processor and ICH2) / AC '97 interface / ADI1887 codec
(analog mixing, Analog-to-Digital and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers Ext active speakers / 2-piece / 1.5 watts / 200Hz-17kHz freq resp / black color
Ethernet 10/100 ethernet on planar / ICH2 (MAC layer) with Intel 82562ETPHY (physical layer)
/ Wake on LAN
Keyboard / mouse 106-key (rubber dome) keyboard / IBM 2-button mouse
Power supply 155 watts with variable speed fan / universal / manual switch
Preload with Windows 2000
Microsoft ® Windows 2000 Professional
Lotus SmartSuite license
Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
- Microsoft Office XP Small Business
(Word, Excel, Outlook, Publisher, Small
Business Tools)
Office XP Small Business CD-ROM
Preload with Windows Millennium (Me)
Microsoft Windows Millennium Edition
Lotus SmartSuite license
Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
* For a copy of IBM's Statement of Limited Warranty, call 1-800-772-2227
US models announced September 18, 2001
US models withdrawn effective April 2002
Slot x
bay Processor Memory
GHz 1
Celeron 1.0GHz 128MB
Celeron 1.0GHz 128MB
Celeron 1.0GHz 128MB
® 1
Celeron 1GHz with 100MHz Front Side Bus
3
III
4
CD-ROM / bootable
4 max CD-RW / bootable
monitor
®
Options
5
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
6
256MB SDRAM 133MHz NP DIMM
6
2-Piece Speakers (black)
3-Piece Speakers (black)
40GB IDE Disk ATA-100 (5400 rpm)
28
Zip Drive 250MB (white/black)
5.25 to 3.5 DASD Bay Conversion Kit
12X/8X/32X
48X/20X
8X/4X/32X/8X
5
Combo Drive (black)
16MB NVIDIA Vanta LP PCI Card
6
56K V.90 Data/Fax PCI modem
6
10
V.90
IBM E94 19" (18.0" v.i.s.) Monitor (blk)
IBM T540 15" Flat Panel Monitor (black)
IBM E74M 17" (15.9" v.i.s.) Monitor (blk)
IBM Wireless keyboard and mouse (blk)
IBM Rapid Access III Kybd USB (black) 22P5185
8 Disk Optical Graphics Ethernet
20GB 2 CD-ROM GMCH 10/100
40GB CD-RW GMCH 10/100
20GB CD-ROM GMCH 10/100
®
3.0 with SPX / software-based audio
4
max CD-RW Internal (blk)
4 IDE CD-ROM (black)
4
max CD-RW/DVD-ROM
10
Modem PCI low profile
Personal Systems Reference (PSREF)
Preload
Windows ® 2000 5
Windows 2000
Windows Me
Micro Tower
Bay 5.25", HH 1.6", access, CD-ROM
Bay 5.25", HH 1.6" access, open
Bay 3.5", SL 1", access, std diskette
Bay 3.5", SL 1", no access, std disk
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v)
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Stealth black color
Swinging door on Bay 1, 2, and 3 (does not cover Bay 1)
Slide out disk
Handle on top
7.6" W X 15.0" D X 15.0" H
194mm W X 381mm D X 381mm H
18.3 to 22.5 lb (8.3 to 10.3 kg)
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0b
System Management BIOS
DMI 2.0-compliant
Wired for Management 2.0-compliant
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U bolt anchoring feature
Padlock support (user supplied lock)
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
33L3071
LIMITED WARRANTY*
33L3073
1 year parts and labor
33L3075
33L3440
On site, 8 am - 5 pm, Mon - Fri,
33L3441
2nd business day response time
22P7156
On site warranty service upgrade
00N8078
7
options :
70G8165
• 1 year 9x5 4 hour response
10K3785
10K3782
(ServicePac part number 54P1858)
• 2 year 9x5 Next Business Day
10K3790
(ServicePac part number 54P1859)
33L3443
• 2 year 9x5 4 hour response
33L4618
(ServicePac part number 54P1860)
19K4162
633440N
• 3 year 9x5 Next Business Day
9511AG4
(ServicePac part number 54P1861)
651767N
• 3 year 9x5 4 hour response
22P5170
(ServicePac part number 54P1862)
24 hour x 7 day
electronic, and Internet support
No warranties are expressed or implied in this summary
Created by IBM PC Institute
Small Busines Available
Software date
XP Office SB 28 Sep 2001
XP Office SB Sep 2001
Sep 2001
Optical
diskette
disk
(vertical)
SECURITY
,9
14 telephone,
(6337) IBM Corp. April 2002
