® NetVista A20 for small business (6270) - withdrawn
TM
Name Type-model Color
A20 6270-S2U Black 3x4
A20 6270-SDU Black 3x4
A20 6270-S4U Black 3x4
A20 6270-SEU Black 3x4
A20 6270-S6U Black 3x4
A20 6270-T2U Black 3x4
A20 6270-T3U Black 3x4
A20 6270-TDU Black 3x4
A20 6270-T4U Black 3x4
A20 6270-T5U Black 3x4
A20 6270-TEU Black 3x4
A20 6270-T7U Black 3x4
A20 6270-T9U Black 3x4
Processor Intel
Intel Pentium III 733, 800EB, 866, or 933MHz
with 133MHz Front Side Bus
Implementation Processor and L2 cache in FC-PGA in PGA370 socket
L2 cache Celeron:
Pentium III: 256KB std and max / ECC / full speed
Memory - std/max 64MB or 128MB std / 512MB max
Memory - sockets Two 168-pin gold plated DIMM sockets / one socket used
Memory - type SDRAM / non-parity only / industry std / unbuffered /
133MHz SDRAM, but 810E interface to memory is 100MHz
Graphics - type SVGA / graphics controller and DAC integrated in the memory
controller / not a separate chip or adapter card
Graphics - controller SVGA / Direct AGP / in 810E Graphics Memory Controller Hub
(GMCH) / 0MB std and max / 15-pin analog D-sub connector /
(DVMT) uses main memory with no display cache
Disk ATA-66, SMART
Disk controller Enhanced IDE / ATA-66 / integrated into I/O Controller Hub (ICH)
Diskette drive 3.5: 1.44MB diskette drive
CD-ROM Some models: 48X-20X
CD-RW Some models: 8X-4X-32X
Architecture Accelerated Hub Architecture / 266MB/sec I/O channel
Chip set Intel 810E
82801 I/O Controller Hub (ICH) for PCI 2.2 bus at
32-bit 33MHz, ATA-66 EIDE, USB, Low Pin Count Interface /
82802 Firmware Hub / Winbond 83627HF Super I/O for
diskette, parallel, serial, keyboard, mouse
Ports Back: One or two serial (two serial on models S6U, T7U, T9U), one parallel,
two USB (Version 1.1), keyboard, mouse
Audio Integrated digital audio / software-based audio (done by processor and
810E) / AC '97 interface / ADI 1881 codec (analog mixing, Analog-to-Digital
and Digital-to-Analog conversion)
Audio connectors Back: microphone jack, line-in, line-out
Speakers None / requires powered speakers
Ethernet controller Some models: 10/100 ethernet / Accton 32-bit PCI adapter / full duplex /
part number 19K4310
Modem Some models: 56K V.90 PCI modem
Keyboard / mouse 104-key keyboard / IBM ScrollPoint
Power supply 155 watts with variable speed fan / universal / manual switch
Windows Millennium Preload
Microsoft Windows Millennium Edition
Microsoft Office 2000 Small Business
is preinstalled (Word, Excel, Outlook,
Publisher, Small Business Tools)
- Lotus ® SmartSuite ®
- Lotus Notes ® Client 5.0 license
- Disk-to-Disk Recovery (in Service Partition)
Software Selections CD-ROM
Windows 2000 Preload
Microsoft ® Windows ® 2000 Professional
Microsoft Office 2000 Small Business
is preinstalled
- Lotus SmartSuite license
- Lotus Notes Client 5.0 license
- Disk-to-Disk Recovery (Windows 2000;
no option to convert to NT 4.0)
Software Selections CD-ROM
US models announced September 12, 2000 or January 30, 2001
US models withdrawn effective March 2001 or May 2001 or September 2001
Slotxbay Processor MHz 1
TM
Celeron 566/66
Celeron 566/66
Celeron 633/66
Celeron 633/66
Celeron 700/66
®
Pentium III 733/133 128MB 20GB 48X-20X
Pentium III 733/133 128MB 10GB 48X-20X
Pentium III 733/133 128MB 20GB 48X-20X
Pentium III 800/133 128MB 20GB 48X-20X
Pentium III 800/133 128MB 10GB 48X-20X
Pentium III 800/133 128MB 20GB 48X-20X
Pentium III 933/133 128MB 30GB CD-RW
Pentium III 866/133 128MB 20GB 48X-20X
® Celeron TM 566, 633, or 700MHz
128KB std and max / ECC / full speed
3
III
4 CD-ROM / bootable
4 CD-RW / bootable
8 chip set / 82810 Graphics Memory Controller Hub (GMCH) /
5 Options
64MB SDRAM 133MHz NP DIMM
128MB SDRAM 133MHz NP DIMM
256MB SDRAM 133MHz NP DIMM
Rapid Access
Rapid Access
license 6
10.1GB IDE Disk ATA-66(Value)
6
15GB IDE Disk ATA-100 (Value)
Zip Drive 100MB (white)
Zip Drive 250MB (white/black)
5
5.25 to 3.5 DASD Bay Conversion K 70G8165
8X/4X/32X CD-RW Internal (black)
48X-20X
8X DVD-ROM Internal IDE (black)
DVD MPEG-2 Decoder Card
6
10/100 Accton
6
56K
ADSL / V.90 Combo PCI low profile
V.90 Modem PCI low profile
10/20GB TR5 IDE Tape Drive (w/blk) 20L0549
Memory Disk CD Graphics
2 4
128MB 20GB 48X-20X GMCH None
128MB 20GB 48X-20X GMCH None
128MB 20GB 48X-20X GMCH None
128MB 20GB 48X-20X GMCH None
64MB 20GB 48X-20X GMCH 10/100 Accton None
GMCH None
GMCH 10/100 Accton None
GMCH None
GMCH None
GMCH 10/100 Accton None
GMCH None
GMCH 10/100 Accton None
GMCH 10/100 Accton None
1 with 66MHz FS Bus or
TM II mouse
TM
Keyboard II (p wht) 33L3154
TM Keyboard II (black)
4
IDE CD-ROM (white)
® ethernet PCI adaptr 19K4301
10 Data/Fax PCI modem
Ethernet Modem Chip
Modem 810E 2000
Modem 810E Millennium Sep 2000
Modem 810E 2000
Modem 810E Millennium Sep 2000
810E Millennium Feb 2001
Modem 810E 2000
810E 2000
Modem 810E Millennium Sep 2000
Modem 810E 2000
810E 2000
Modem 810E Millennium Sep 2000
810E 2000
810E 2000
Micro Tower
Slot 1: 9 inch max, 32-bit PCI 2.2 (5v)*
* ethernet adapter in some
Slot 2: 9 inch max, 32-bit PCI 2.2 (5v)
CD-ROM
Slot 3: 9 inch max, 32-bit PCI 2.2 (5v)
Swinging door on Bay 1 to 2 (does
diskette
not cover Bay 1)
Handle on top
Black color with blue panel
Bay 5.25", HH 1.6", access, CD-ROM
disk
Bay 5.25", HH 1.6" access, open
(vertical)
Bay 3.5", SL 1", access, std diskette
Bay 3.5", SL 1", no access, std disk
SECURITY
Knockout in rear for optional keylock
to lock cover to chassis (lock available
from Illinois Lock at 847-537-1800)
U-bolt anchoring feature
Power-on password
Administrator password
Boot sequence control
Diskette boot inhibit
Boot without keyboard or mouse
Diskette and disk I/O control
Serial/parallel I/O control
SYSTEMS MANAGEMENT
PC 99-compliant
Advanced Power Management 1.2
Advanced Configuration and
Power Interface (ACPI) 1.0a
System Management BIOS
DMI 2.0-compliant
RPL and DHCP support via optional
ethernet adapter
6270 Dimensions
- 7.64"W X 15.0"D X 15.0"H
- 194mm W X 381mm D X 381mm H
- 18.25 to 22.5 lb (8.4 to 10.3 kg)
33L3071
LIMITED WARRANTY*
33L3073
33L3075 3 year parts / 1 year labor warranty
International Warranty Service
33L3174
1st year: on site, 8 am - 5 pm,
00N8202
Mon - Fri coverage,
19K4463
2nd business day response time
20L0544
00N8078 2nd/3rd year: parts exchange only,
call 1-800-772-2227
33L5020
On site warranty upgrade options:
33L5001
• Next day response
33L5016
• 4 hour response
33L5009
Post warranty: on site options above
33L4618
IBM SystemXtra
19K4160
24 hour x 7 day telephone, electronic,
19K4162
and Internet support
No warranties are expressed or implied in this summary
(6270SB)
Preload Available
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Sep 2000
Feb 2001
Feb 2001
,9
9
7 , Mon-Fri 8-5
7
, 7 day x 24 hr
,16
