MANUAL
ENGLISH
Infinity iB-715
V1
Ordercode: 41540
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infinity iB-715 and is the answer not in the manual?

Questions and answers

Related Manuals for Highlite International Infinity iB-715

Summary of Contents for Highlite International Infinity iB-715

  • Page 1 MANUAL ENGLISH Infinity iB-715 Ordercode: 41540 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...

  • Page 2: Table Of Contents

    Infinity iB-715 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Frontside..................................7 Backside ..................................8 Installation ...................................

  • Page 3: Warning

    Infinity iB-715 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling.
  • Page 4 Infinity iB-715 Please consider that damages caused by manual modifications to the device are not subject to warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only. IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the device.

  • Page 5: Operating Determinations

    Infinity iB-715 Operating Determinations  This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects.  The minimum distance between light output and the illuminated surface must be more than 1 meter.

  • Page 6: Connection With The Mains

    Infinity iB-715 The Infinity can be placed on a flat stage floor or mounted to any kind of truss with a mounting bracket and a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug.

  • Page 7: Return Procedure

    Infinity iB-715 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.

  • Page 8: Description Of The Device

    Infinity iB-715 Description of the device Features The Infinity iB-715 is a moving head effect with high output and great effects.  Input voltage: 100-240V, 60/50Hz  Power consumption: 165W  DMX channels: 23, 51 channels  LCD display with gravity sensor ...

  • Page 9: Backside

    07) PowerCON power connector 100-240V IN 08) Fuse F3AL/250V Installation Remove all packing materials from the Infinity iB-715. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly.

  • Page 10: Control Modes

    Infinity iB-715 Control Modes There are 3 modes: • Stand-alone • Master/Slave • DMX-512 (23CH, 51CH) One Infinity (Stand-alone) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket.

  • Page 11: Multiple Infinitys (Dmx Control)

    Infinity iB-715 Multiple Infinitys (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Infinity and other devices.

  • Page 12: Fixture Linking

    Infinity iB-715 Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.

  • Page 13: Control Panel

    Infinity iB-715 Control Panel Home button Edit Menu button Settings Mode Button Address Setting Button Infinity Logo Button Up Button Down Button OK/ENTER Left Button Right Button LCD Display Fig. 05 Control Mode The fixtures are individually addressed on a data-link and connected to the controller.

  • Page 14: Menu Overview

    Infinity iB-715 Menu Overview Ordercode: 41540...

  • Page 15: Main Menu Options

    Infinity iB-715 Main Menu Options DMX address Edit Mode Settings Menu Built-in Programs Test Mode Info Home Edit Menu Down Setting Mode Address Setting Left Infinity Logo Right 1. DMX Addressing With this menu you can set the DMX address.

  • Page 16: Edit Mode

    Infinity iB-715 2. Edit Mode With this menu you can set your desired mode. 01) Press the button or press the buttons to select 02) Press the button, to confirm. You can choose from 3 different modes. 03) Press the...

  • Page 17: Color Balance

    Infinity iB-715 05) Press the buttons to change the value from NO to YES. 06) Some of the available menus have different options to the regular, YES or NO function: Pan Angle: 540°, 360°, 180° Tilt Angle: 270°, 180°, 90°...

  • Page 18: Reset

    Infinity iB-715 3.3. Reset With this menu you can reset the device’s settings. 01) In Settings menu, press the buttons to select Reset Function and press the button to open the menu. 02) Press the buttons to choose one of the 2 options: ...

  • Page 19: Test Menu

    Infinity iB-715 5. Test Menu With this menu you can set your desired mode. 01) Press the button or press the buttons to select 02) Press the button to enter the menu. 03) Press the buttons to choose one of the 2 modes: ...

  • Page 20: System Information

    Infinity iB-715 6. System information With this menu you can set your desired mode. 01) Press the button or press the buttons to select 02) Press the button to enter the menu. 03) The following screen will pop up: 04) You can now monitor the device’s current software version, current active mode, current DMX starting address, total operation time counter and time counter.
  • Page 21 Infinity iB-715 Channel 9 – Green CH20 and CH21 must be open 0-255 Gradual adjustment Green, from dark to brightest Channel 10 – Blue CH20 and CH21 must be open 0-255 Gradual adjustment Blue, from dark to brightest Channel 11 – White...
  • Page 22 Infinity iB-715 Channel 14 – Individual LED control CH8-11 and CH20-21 must be open. LED # ● ● ● ● ● ● ● ● ○ ○ ○ ○ ○ ○ 10-11 ○ ● ○ ○ ○ ○ ○ 12-13 ○...
  • Page 23 Infinity iB-715 ○ ● ○ ○ ○ ● ● 100-101 ● ● ● ● ○ ○ ○ 102-103 ○ ● ● ● ● ○ ○ 104-105 ○ ○ ● ● ● ● ○ 106-107 ● ○ ○ ● ● ●...
  • Page 24 Infinity iB-715 ● ● ● ● ○ ● ● 196-197 ● ● ● ● ● ● ● 198-255 Channel 15 – Color programs CH8-11 and CH20-21 must be open 0-15 Not functional 16-135 Built-in programs Channel 15 – Color programs (fixed color)
  • Page 25 Infinity iB-715 105-109 Shutter open 110-124 Strobe effect 4 (random strobe), from fast to slow 125-129 Shutter open 130-144 Strobe effect 5 (random strobe fast on and slow off), from fast to slow 145-149 Shutter open 150-164 Strobe effect 6 (random strobe slow on and fast off), from fast to slow...

  • Page 26: Channels

    Infinity iB-715 51 channels Channel 1 – Horizontal movement (Pan) Push the slider up, in order to move head horizontally (PAN). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The head can be turned by 540° and stopped at any position you wish.
  • Page 27 Infinity iB-715 Channel 13 – Green 1 CH48 and CH49 must be open 0-255 Gradual adjustment Green, from dark to brightest Channel 14 – Blue 1 CH48 and CH49 must be open 0-255 Gradual adjustment Blue, from dark to brightest Channel 15 –...
  • Page 28 Infinity iB-715 Channel 41 – Color temperature Not functional White 2700K White 3200K White 4200K White 5600K 9-10 White 8000K Blue (R=0, G=0, B=255, W=0) 12-48 R=0, G=0, B=255, W=0 Cyan (R=0, G=255, B=255, W=0) 50-86 R=0, G=255, B-, W=0...
  • Page 29 Infinity iB-715 ○ ○ ○ ○ ○ ● ● 60-61 ● ○ ○ ● ○ ○ ○ 62-63 ○ ● ○ ○ ● ○ ○ 64-65 ○ ○ ● ○ ○ ● ○ 66-67 ● ● ● ○ ○ ○...
  • Page 30 Infinity iB-715 ○ ● ● ● ● ● ○ 156-157 ● ○ ● ● ● ● ○ 158-159 ● ● ○ ● ● ● ○ 160-161 ● ● ● ○ ● ● ○ 162-163 ● ● ● ● ○ ●...
  • Page 31 Infinity iB-715 Channel 46 – Color reverse Not functional White 2700K White 3200K White 4200K White 5600K 9-10 White 8000K Blue (R=0, G=0, B=255, W=0) 12-48 R=0, G=0, B=255, W=0 Cyan (R=0, G=255, B=255, W=0) 50-86 R=0, G=255, B-, W=0...
  • Page 32 Infinity iB-715 Channel 50 – Functions Not functional 10-14 Pan/Tilt blackout 15-19 Not functional 20-24 RGBW color mixing, after 5 seconds 25-29 CMY color mixing, after 5 seconds 30-49 Not functional 50-54 Pan reset, after 5 seconds 55-59 Tilt reset, after 5 seconds...

  • Page 33: Maintenance

    Infinity iB-715 Maintenance The operator has to make sure that safety-related and machine-technical installations are to be inspected by an expert after every year in the course of an acceptance test. The operator has to make sure that safety-related and machine-technical installations are to be inspected by a skilled person once a year.

  • Page 34: No Response To Dmx

    Infinity iB-715 No Response to DMX Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 01) Check the DMX setting. Make sure that DMX addresses are correct. 02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.

  • Page 35: Product Specifications

    Infinity iB-715 Product Specifications Model: Infinity iB-715 Input Voltage: 100-240 VAC, 60/50Hz Power consumption: 165W (full output) DMX linking: 30pcs Fuse: F3AL/250V Dimensions: 305 x 200 x 405 mm (LxWxH) Weight: 9 kg Operating and Programming: Signal pin OUT: Pin 1 (earth), pin 2 (-), pin 3 (+)

  • Page 36: Dimensions

    Infinity iB-715 Dimensions Ordercode: 41540...

  • Page 37: Notes

    Infinity iB-715 Notes Ordercode: 41540...
  • Page 38 Infinity iB-715 Ordercode: 41540...
  • Page 39 Infinity iB-715 Ordercode: 41540...
  • Page 40 ©2016 Infinity...
