Summary of Contents for TransTank TrailPro Deluxe
- Page 1 OPERATOR’S HANDBOOK w w w . t t i . c o m . a u TrailPro Deluxe ™ with 6m boom and 30m Hose Reel Manufacturer of The Safest Tanks in Motion...
-
Page 2: Table Of Contents
TTi’s TrailPro Deluxe HandBook ™ Table of Contents Introduction Risk Assesment Operating Instructions Mixing and Filling Calibration Calibration Procedures Spraying Guide Spraying Consideration After Season Care STT Models Spray Lance Spare Parts List Spare Parts List Warranty Warranty Limitations Warranty Registration Card www.tti.com.au Call 1800 816 277... -
Page 3: Introduction
TTi’s TrailPro Deluxe HandBook ™ Introduction Please read your operators handbook carefully before mounting and using your SpotPro Deluxe sprayer. Keep your handbook in a safe place. Congratulations on your purchase of a TTi SpotPro Sprayer which is complete and ready to attach to an ATV. -
Page 4: Risk Assesment
TTi’s TrailPro Deluxe HandBook ™ Risk Assesment Product Information Risk Assessment Sheet TTi - TrailPro Sprayer TASK HAZARDS RISK CONTROL MEASURES Concentrate on task; follow safe manual handling techniq ues: • Don’t lif t on your own if > 20kg; •... -
Page 5: Operating Instructions
TTi’s TrailPro Deluxe HandBook ™ Operating Instructions Check all hoses, connections and hose clamps to ensure that the unit has been delivered to you without transportation loss or damage. Before attempting any spraying with your new unit, operate it with water only to familiarize yourself with its features and capabilities and to ensure that your sprayer has arrived in a safe working condition. -
Page 6: Mixing And Filling
TTi’s TrailPro Deluxe HandBook ™ Mixing and Filling Sites for mixing and filling the sprayer should be carefully chosen to be away from any risk of spillages draining into water courses or into environmentally sensitive areas. Children and animals must always be kept way from mixing and filling operations. The following steps are given as a guide for mixing and filling the sprayer. -
Page 7: Calibration Procedures
TTi’s TrailPro Deluxe HandBook ™ Calibration Procedures Boom Sprayers Hydraulic Nozzles Example Spray VOLUME 200 litres/hectare Read the label Product Dose 50 litres/hectare Spray QUALITY Medium Measure TIME per Measure time in seconds over land similar to 41.9 seconds 100 Metres that to be sprayed SPEED(km/h) = 360 divided by TIME (sec) Calcute SPEED... -
Page 8: Spraying Guide
TTi’s TrailPro Deluxe HandBook ™ Spraying Guide The following steps are given as a guide for spraying with your trailer unit. • Before commencing spraying, plan the work effectively to reduce potential contamination to a minimum. • Wind Direction and speed must be taken into account. Avoid spraying on hot and sunny days or when wind speed exceeds 6.5km/h •... -
Page 9: Spraying Consideration
e applied TTi’s TrailPro Deluxe HandBook ™ e applied Spraying Consideration For effective spraying ensure you have taken the following factors into account. TTi - Operators Handbook Spray Decontamination oom height 1. Work Rates boom height till warm days as convection currents may cause drift in unpredictable •... -
Page 10: After Season Care
TTi’s TrailPro Deluxe HandBook ™ After Season Care NOTE: It is important that when cleaning the sprayer one wears proper safety equipment. See your chemical or fertilizer package for this information. • After spraying chemicals run water through the tank, pump, and all hose hookups. If wettable powder dries out in the system it is very difficult to put back into suspension and can cause malfunction, damage or injury. -
Page 11: Stt Models
TTi’s TrailPro Deluxe HandBook ™ STT Models 22 L/min Pump Item Code Description STA31 1 ¼” MBSP Poly Tank Fitting with Gasket STAHS25 25mm Suction Hose STAB031 1 ¼” Suction Filter Complete 4HP Honda Motor GC135 STAP31 Bertonini Pump & Gearbox 22l/m, 20Bar, - 20RT4 BE 80.3060.00.2 O’Ring 1.78 x 12.42mm BE 84.0521.00.2... -
Page 12: Spray Lance
TTi - Operators Handbook TTi’s TrailPro Deluxe HandBook ™ Spray Lance Spray Lance 29.17.02.26 29.1003.24 23.602.34 23.1310.8 23.602.29 23.1603.14 23.1304.29 23.601.25 29.1101.1 30.208.130 23.602.34 23.1003.16 29.507.10 29.801.40 29.1607.3 29.902.8 30.1903.8 w w w. t t i . c o m . a u C a l l 1 8 0 0 8 1 6 2 7 7 www.tti.com.au Call 1800 816 277... -
Page 13: Spare Parts List
TTi - Operators Handboo Spare Parts List TTi’s TrailPro Deluxe HandBook ™ Spare Parts List (Pump Series VF - STAP30) 22L/min (Pump Series VF - STAP30) 22L/min (PA 330 VF - STAP36) 34L/min (PA 330 VF - STAP36) 34L/min Spare Kits Spare Kits STAP101 STAP102... -
Page 14: Spare Parts List
TTi’s TrailPro Deluxe HandBook ™ Spare Parts List Karin STAP77 (15bar) + STAP78 (40bar) Code Description 24.0310.32.2 Valve Housing 83.0080.00.2 Pressure Gauge 0-100 Bar 83.0010.00.2 Pressure Gauge 0-24 Bar 80.3060.00.2 O-Ring 1.78 x 12.42 54.0521.00.2 90° Elbow Connector Dia. 20 82.0042.10.2 Wing Nut G. -
Page 15: Warranty
TTi’s TrailPro Deluxe HandBook ™ Warranty Warranty Policy Your TrailPro is guaranteed free from defect in materials, workmanship or manufacture for 12 months from the date of purchase. Any parts which appear to us to be defective either in material or workmanship will be replaced or repaired at no cost to the purchaser, subject to the following conditions: 1. -
Page 16: Warranty Limitations
TTi’s TrailPro Deluxe HandBook ™ Warranty Limitations a] There is no other express warranty. Any warranty that may be implied from this purchase including merchantibility and finess for a particular purpose is hereby limited to the duration of this warranty and to the extent permitted by law. Any and all implied warranties are excluded. -
Page 17: Warranty Registration Card
TTi’s TrailPro Deluxe HandBook ™ Warranty Registration Card To validate your warranty, please complete registration on-line at: www.tti.com.au/warranty-registration Alternatively if you are unable to register on-line fill in all the details below, copy and email to warranty@tti.com.au or post to the address on the back cover. I have read and understood the instructions in this booklet. - Page 20 w w w. t t i . c o m . a u 1800 816 277 sal es@t ti.co m .au PO Box 137, N a t ha l i a , V I C , 3 6 3 8 M ur ra y Valley Hw y, N a t h a l i a , VI C 3 63 8...
